Home Decorators Collection WINDWARD 68000 Use And Care Manual page 10

Assembly - Attaching the Fan Blades
1
Attaching the fan blades
□
Attach a blade (G) to the fan motor housing (E) by first
inserting the blade (G) into the slot in the side of the fan
motor housing (E).
□
Align the holes of support plate (K) to the blade (G) holes
and insert the screw (AA) into the blade. Repeat for the two
remaining screws.
□
Tighten each screw (AA) securely.
□
Repeat these steps for the remaining blades (G).
Assembly - Attaching the Accessories
1
Installing the light kit pan
□
Remove one screw (RR) from the black bracket below the fan
motor assembly (E), and loosen but do not remove the other
two screws.
□
Push the light kit pan (F) up to the fan motor assembly (E) so
that the two loosened screw heads fit into the keyhole slots.
Turn the light kit pan (F) clockwise.
□
Re-install the screw (RR) that was removed in the first step.
□
Make sure all the screws are firmly tightened.
10
E
K
G
AA
E
F
RR
