Model 412177
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Here's one for
the books.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-9
Français pg 10-12
Español pg 13-15
Lot # 360888
03/11/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sauder Library 412177
Summary of Contents for Sauder Library 412177
- Page 1 Model 412177 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987. English pg 1-9 Français pg 10-12...
-
Page 2: Table Of Contents
Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps Hammer Not actual size Français 10-12 Español 13-15 Safety 16-18 Warranty Page 2 412177 www.sauder.com/services... -
Page 3: Part Identifi Cation
Use this part identifi cation to help identify similar parts. RIGHT END (1) BOTTOM (1) BASE (1) LEFT END (1) ADJUSTABLE SHELF (3) TOP MOLDING (1) TOP (1) BACK (1) SHELF (1) www.sauder.com/services 412177 Page 3... -
Page 4: Hardware Identifi Cation
HOLE PLUG - 3 SAFETY BRACKET - 1 METAL PIN - 12 BLACK 9/16" LARGE HEAD SCREW - 11 NAIL - 54 BLACK 1-5/8" PAN HEAD SCREW - 3 BLACK 1-7/8" PAN HEAD SCREW - 1 Page 4 412177 www.sauder.com/services... -
Page 5: Assembly Steps
fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1736 To begin assembly, push a SAUDER TWIST-LOCK® å to watch a video on how to assemble your unit. FASTENER (J) into the large holes in the ENDS (A and B). - Page 6 Step 2 Fasten the LEFT END (B) to the TOP (C). Tighten two å How to use the SAUDER TWIST-LOCK ® FASTENER TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the Fasten the BOTTOM (D) and SHELF (I) to the LEFT å...
- Page 7 å through the ANGLE BRACKETS and into the BASE. Curved edge BLACK 1-5/8" PAN HEAD SCREW (3 used for the TOP) Finished edge Curved edge BLACK 9/16" LARGE HEAD SCREW (10 used for the ANGLE BRACKETS) www.sauder.com/services 412177 Page 7...
- Page 8 Fasten the BACK (F) to your unit using the NAILS (P). å NOTE: Be sure to tap NAILS into the holes that line up over å the SHELF (I). NAIL (54 used in this step) These holes must line up over the SHELF (I). Page 8 412177 www.sauder.com/services...
- Page 9 (1 used into a stud in your wall) BLACK 9/16" LARGE HEAD SCREW (1 used into the top of your unit) No load (3 used) 35 lbs. 35 lbs. 40 lbs. 35 lbs. 50 lbs. (12 used) www.sauder.com/services 412177 Page 9...
-
Page 10: Français
élément et conserver le livret FIXATION TWIST-LOCK® ........12 pour future référence. EXTRÉMITÉ DROITE ..........1 Pour contacter Sauder CONSOLE À ÉQUERRE .........5 EXTRÉMITÉ GAUCHE ..........1 en ce qui concerne cet MANCHON EN CAOUTCHOUC ....12 DESSUS ................1 élément, faire référence... - Page 11 VIS TÊTE GOUTTE DE SUIF 41 mm (Q) NOIRES. Pour commencer l'assemblage, enfoncer une FIXATION TWIST- LOCK® SAUDER (J) dans les gros trous des EXTRÉMITÉS (A et B). Fixer cinq CONSOLES À ÉQUERRE (K) aux EXTRÉMITÉS (A et B) et au DESSOUS (D). Utiliser cinq VIS TÊTE Répéter cette étape pour le DESSOUS (D) et la TABLETTE (I).
- Page 12 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. Page 12 412177 www.sauder.com/services...
-
Page 13: Español
EXTREMO DERECHO ..........1 SUJETADOR TWIST-LOCK® ......12 et conserver le livret pour future référence. EXTREMO IZQUIERDO ..........1 SOPORTE ANGULAR ..........5 Pour contacter Sauder PANEL SUPERIOR ............1 MANGUITO DE GOMA .........12 en ce qui concerne cet FONDO .................1 ESPIGA DE METAL ..........12 élément, faire référence... - Page 14 Fije la MOLDURA DE PANEL SUPERIOR (H) al PANEL Para comenzar el ensamblaje, empuje un SUJETADOR SUPERIOR (C). Utilice tres TORNILLOS NEGROS DE CABEZA TWIST-LOCK® SAUDER (J) en los agujeros grandes de REDONDA de 41 mm (Q). los EXTREMOS (A y B).
- Page 15 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. www.sauder.com/services 412177 Page 15...
-
Page 16: Safety
• This product is not designed to support a not designed to support a television is heavy. Plus the weight and location of the television. hazardous. picture tube tends to make TVs unbalanced and prone to tipping forward. Page 16 412177 www.sauder.com/services... - Page 17 Les téléviseurs peuvent être un téléviseur. cet eff et. particulièrement lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 412177 Page 17...
- Page 18 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 18 412177 www.sauder.com/services...
-
Page 19: Warranty
à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder. - Page 20 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
