Desk
Registry Row Collection | 412267
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
The original desktop.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-28
Français pg 29-32
Español pg 33-36
Lot # 372657
05/13/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the Registry Row Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sauder Registry Row Series

Summary of Contents for Sauder Registry Row Series

  • Page 1 Registry Row Collection | 412267 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 SMALL DRAWER LEFT SIDE (1) BACK (1) M67 DRAWER BRACE (1) FILE DRAWER RIGHT SIDE (1) BRACE (1) END MOLDING (1) FILE DRAWER LEFT SIDE (1) UPPER DRAWER FRONT (1) SMALL DRAWER BACK (1) LOWER DRAWER FRONT (1) Page 2 412267 www.sauder.com/services...
  • Page 3 Now you know Part Identifi cation our ABCs. D716 D121 D991 D716 www.sauder.com/services 412267 Page 3...
  • Page 4 BRACKET - 1 PENCIL DRAWER FILE GLIDE - 2 WOOD DOWEL - 9 FOOT - 5 PULL - 2 FRONT BRACKET - 1 WW BACKPLATE - 2 METAL BRACE - 1 KNOB - 2 CORNER ACCENT - 3 Page 4 412267 www.sauder.com/services...
  • Page 5 GOLD 1" MACHINE SCREW - 2 BLACK 9/16" FLAT HEAD SCREW - 2 BROWN 9/16" LARGE HEAD SCREW - 14 SILVER 1/2" MACHINE SCREW - 5 GOLD 5/16" FLAT HEAD SCREW - 24 NAIL - 20 www.sauder.com/services 412267 Page 5...
  • Page 6 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty carton å to avoid scratching your unit or the fl oor. Push twenty-four HIDDEN CAMS (1F) into the ENDS (A and C), å...
  • Page 7 Step 2 Turn thirteen CAM SCREWS (8F) into the LEGS (U, V, X, and Y). å Remember: NOTE: Be sure to use the exact holes shown. å Righty tighty. Lefty loosey. (13 used) www.sauder.com/services 412267 Page 7...
  • Page 8 SCREWS (BBB) through the FRONT LEGS (U and Y). Use a SILVER 1/2" MACHINE SCREW (EEE) through the LEFT FRONT LEG (V). BLACK 7/8" MACHINE SCREW (2 used in this step) SILVER 1/2" MACHINE SCREW (1 used in this step) Angled edge Page 8 412267 www.sauder.com/services...
  • Page 9 Step 4 Fasten the RIGHT FRONT LEG (U) to the RIGHT END (A) å and the CENTER LEG (Y) to the UPRIGHT (D). Tighten six HIDDEN CAMS. Edge with CAM DOWELS Angled edge Angled edge www.sauder.com/services 412267 Page 9...
  • Page 10 Apply pressure with your hands as you guide the MOLDINGS over the SCREWS and onto the END. BLACK 9/16" FLAT HEAD SCREW (2 used in this step) Angled edge BLACK 2-1/4" FLAT HEAD SCREW (3 used in this step) Shoulder Page 10 412267 www.sauder.com/services...
  • Page 11 (2 used in this step) parts is extremely diffi cult. Edge with HIDDEN CAMS (8 used) If the UPPER LEFT END (B) has an unfi nished surface, it should be facing up. The holes should be closer to this edge. www.sauder.com/services 412267 Page 11...
  • Page 12 BRACE (I). Tighten two HIDDEN CAMS. Repeat this step for the LEFT FRONT LEG (V) making sure all å HIDDEN CAMS are tight. Fill the holes 1/4 to 1/2 full with GLUE. Angled edge Angled edge Page 12 412267 www.sauder.com/services...
  • Page 13 LEFTS (40CB) to the RIGHT END (A) and UPRIGHT (D). Use eight GOLD 5/16" FLAT HEAD SCREWS (FFF) through holes #1 and #3. GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Roller end Edge with CAM DOWELS Angled edge Roller end Angled edge www.sauder.com/services 412267 Page 13...
  • Page 14 #1 and #3. SILVER 2" FLAT HEAD SCREW (2 used for the EXTENSION BLOCK) GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Roller end Edge with CAM DOWELS Roller end Angled edge Angled edge Page 14 412267 www.sauder.com/services...
  • Page 15 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 412267 Page 15...
  • Page 16 Fasten the METAL BRACE (TT) to the LEFT LEGS (V and X). 190 degrees å Use four BROWN 9/16" LARGE HEAD SCREWS (DDD). BROWN 9/16" LARGE HEAD SCREW (4 used for the METAL BRACE) SILVER 2" FLAT HEAD SCREW (2 used in this step) Page 16 412267 www.sauder.com/services...
  • Page 17 Fasten the BOTTOM (F) to the UPRIGHT (D). Tighten two å HIDDEN CAMS. Maximum Arrow 210 degrees Fasten the RIGHT END (A) to the BOTTOM (F) and TOP (E). å Tighten four HIDDEN CAMS. Minimum 190 degrees Angled edge Finished edge www.sauder.com/services 412267 Page 17...
  • Page 18 Push a FOOT (QQ) over the bottom edge of each LEG (U, V, W, X, and Y). å With a hammer, tap a TACK GLIDE (LL) through the holes of the FEET (QQ). å (5 used) Page 18 412267 www.sauder.com/services...
  • Page 19 NOTE: Be sure the BACK is not hanging over the top å surface of the TOP. NAIL (20 used in this step) The edge of the BACK should be even with the BOTTOM and UPRIGHT surfaces. www.sauder.com/services 412267 Page 19...
  • Page 20 DRAWER BOTTOM down into the groove. Groove f a c s u r n i s h U n fi D991 D238 Be sure the DRAWER BOTTOM inserts into the DRAWER FRONT groove. Page 20 412267 www.sauder.com/services...
  • Page 21 190 degrees Start each screw a few turns before completely tightening any of them. BLACK 1-9/16" FLAT HEAD SCREW (5 used in this step) D121 Be sure the DRAWER BOTTOM inserts into the DRAWER BACK groove. www.sauder.com/services 412267 Page 21...
  • Page 22 Fasten the BACKPLATES (WW) and KNOBS (VV) to the PENCIL å DRAWER FRONT (R2). Use two GOLD 1" MACHINE SCREWS (AAA). Roller end GOLD 1" MACHINE SCREW (2 used in this step) Roller end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Page 22 412267 www.sauder.com/services...
  • Page 23 (4 used for the BRACKETS) With the palm of your hand, tap the DRAWER BOTTOM down into the groove. fi n i s h r f a D716 Be sure the DRAWER BOTTOM inserts into the DRAWER FRONT groove. www.sauder.com/services 412267 Page 23...
  • Page 24 BLACK 1-9/16" FLAT HEAD SCREWS (30S). Start each screw a few turns before completely tightening any of them. BLACK 1-9/16" FLAT HEAD SCREW (4 used in this step) Be sure the DRAWER BOTTOM inserts into the DRAWER BACK groove. Page 24 412267 www.sauder.com/services...
  • Page 25 (4 used in this step) Be sure the DRAWER BOTTOM inserts into the DRAWER BACK groove. Fasten the SMALL DRAWER BACK (D77) to the SMALL DRAWER SIDES (D36 and D37). Use four BLACK 1-9/16" FLAT å HEAD SCREWS (30S). www.sauder.com/services 412267 Page 25...
  • Page 26 FILE DRAWER SIDES (D48 and D49). Use four GOLD 5/16" FLAT HEAD SCREWS (FFF) through holes #2 and #4. Repeat this step for the other drawer. å Roller end Roller end GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Page 26 412267 www.sauder.com/services...
  • Page 27 Push the FILE GLIDES (4B) onto the top edges of the FILE å DRAWER SIDES (D48 and D49). Fasten the PULLS (SS) to the DRAWER FRONTS (J and N). å Use four SILVER 1/2" MACHINE SCREWS (EEE). SILVER 1/2" MACHINE SCREW (4 used for the PULLS) www.sauder.com/services 412267 Page 27...
  • Page 28 Pro Tip: Lift with your legs. And, you know, your arms. 70 lbs. 5 lbs. 25 lbs. 30 lbs. (4 used) To cover HIDDEN CAMS Place the roller on the SLIDE behind the roller on the RAIL. Page 28 412267 www.sauder.com/services...
