Diverter1 : Turn LEFT
to DIVERTER 2, Turn
RIGHT to seat BJ
ACP 1: Opens/Closes;
Air inlet to all jets in the
seat A, B
ACP 3: Opens/Closes;
Air inlet to seats C, D.
A = 26.42" (67.10cm)
B = 20.76" (52.73cm)
JACUZZI – J19 POWER PRO
Massage Selector/Air Control Diagram
A
B
C
D
Seat Depth
C = 28.44" (72.23cm)
D = 21.88" (55.57cm)
LISTED DIMENSIONS REPRESENT DISTANCE FROM THE TOP
OF ACRYLIC TO LOWEST POINT IN THE SEAT. TOLERANCE
±1/16'' (0.158CM)
Diveter2: Turn jets
ON/OFF in seats A, B,
C, D.
A
B
C
ACP 4: Opens/Closes;
Air inlet to all BJ
(Buoyancy jet)
CHF: To turn ON/OFF
Cascading Hydro fall
ACP- Air controller Pump
BJ- Buoyancy Jet
CHF- Cascading Hydro Falls
D
