CAUTION: Never step or sit on a speaker enclosure! This type of misuse
will damage the speaker enclosure latching and track mechanism. Always
retract speakers prior to covering spa.
Optional Stereo Receiver - Basic Operation
VOL
Open
AS/PS
VOL
W/B
BAND
SEL/
A. On/Off
Press red PWR button once to turn stereo on.
Press a second time to turn off.
B. Select Mode
Press blue SEL button to select
volume, treble, bass, balance,
and fader functions as shown.
Use blue VOL
buttons to adjust selected
mode. Note: when mode
has not been adjusted for
3-seconds, display returns to
standard radio or CD display.
C. Volume
Press blue VOL
VOL
volume to desired listening level.
JENSEN
ST
8 x OVERSAMPLING • 4 X 40 WATTS
or VOL
or VOL
1
2
W1
W2
LOUD
3
4
W3
RPT
CH
5
6
SHF
SCN
MCD-9424RC
SEL/
(Fader)
SEL/
(Balance)
button to adjust
Note: an exter-
nal antenna may
be required in
DISP
certain regions
PWR
to enhance
stereo reception!
VOL
SEL/
(Volume)
(Treble)
(Bass)
SEL/
VOL
PWR
SEL/
VOL

Advertisement

loading
Need help?

Need help?

Do you have a question about the ProTech LCD and is the answer not in the manual?

Questions and answers

Summary of Contents for Jacuzzi ProTech LCD

  • Page 1 CAUTION: Never step or sit on a speaker enclosure! This type of misuse will damage the speaker enclosure latching and track mechanism. Always retract speakers prior to covering spa. Optional Stereo Receiver - Basic Operation Note: an exter- nal antenna may LOUD JENSEN Open...
  • Page 2 SEL/ SEL/ D. Adjust Treble Press blue SEL button two times to select treble mode. Then press blue or VOL button to adjust treble range from -7 to +7. E. Adjust Bass SEL/ SEL/ Press blue SEL button three SEL/ times to select bass mode.
  • Page 3 H. Bass Boost LOUD Press grey LOUD button to increase the bass output. LOUD appears on the display. I. Set Clock DISP Press and hold grey DISP button for 3-seconds until time display flashes. Within 3 seconds, press blue + or - button to set displayed hours and minutes.
  • Page 4 B. Select a Radio Station BAND 1. Slow Scan: Press blue + button or - button for less than one second to advance radio frequency up or down one step. 2. Quick Scan: Press blue + button or - button for more than one second to quickly scan radio frequencies.
  • Page 5 BAND D. Recall a Station Preset 1. Press grey BAND button to select desired radio band, if necessary. 2. Press green PRESET button to recall station preset. E. Automatically Store Stations Function selects 6 strongest stations and stores them in current band.
  • Page 6 Optional Stereo Receiver - CD Player Operation A. Insert and Eject CD 1. Press orange OPEN OPEN button on front flip-over panel. Gently push a CD into slot and flip panel up to close. The CD will begin to play. 2.
  • Page 7 E. Shuffle Play All Tracks Press green SHF button to play all tracks on CD in random order one time. Press again to stop shuffle play. F. Scan (Preview) All Tracks Press green SCN button to play first ten seconds of each track on current CD.
  • Page 8 Stereo Receiver Specifications Optional Stereo Receiver Specifications CD Player Signal/noise ratio ........>86 dB Frequency response .
