Winplus JUMP STARTER PRO User Manual page 7

JUMP STARTING CONT.:
3. Connect the
the car battery. The POSITIVE battery post will be slightly
larger than the NEGATIVE post, and will be marked with a
PLUS (+) sign. There may also be a
cover over the positive battery post.
4. Connect the BLACK clamp to the NEGATIVE (-) post
on the car battery. The NEGATIVE will be marked with
a MINUS (-) sign. There may also be a BLACK plastic
protective cover over the negative battery post.
NOTE: Do not connect the
clamp (-) at the same time. Connect the
the BLACK clamp.
CAUTION: DO NOT lean directly over the battery while making
jumper connections.
5. Check the LED status on the indicator
light box located on the jumper cable.
Proceed to the next step unless the light
is flashing
Please reference the LED status chart
on page 9 if needed.
RED clamp to the POSITIVE (+) post on
RED
RED and BEEPING.
RED
Black
Red
clamp (+) and the BLACK
RED
Indicator Box
7
plastic protective
clamp first, then
