3.3 Breakout Pads

Most pins of the EFR32 are routed from the radio board to breakout pads at the top and bottom edges of the Wireless STK Mainboard.
A 2.54 mm pitch pin header can be soldered on for easy access to the pins. The figure below shows you how the pins of the EFR32
maps to the pin numbers printed on the breakout pads. To see the available functions on each, please refer to the data sheet for
EFR32FG14P233F256GM48.
silabs.com | Building a more connected world.
UG317: EFR32FG14 2400/915 MHz 19 dBm Dual Band Radio Board and Wireless Starter Kit User's Guide
VMCU
GND
VCOM_CTS / EXP3 / PA2 / P0
VCOM_RTS / EXP5 / PA3 / P2
BTN0 / EXP7 / PF6 / P4
BTN1 / EXP9 / PF7 / P6
LED0 / EXP11 / PF4 / P8
DBG_TDI / EXP13 / PF3 / P10
I2C_SCL / EXP15 / PC10 / P12
FLASH_SCS / PA4 / P14
VCOM_ENABLE / PA5 / P16
PTI_CLK / PB11 / P18
PTI_DATA / PB12 / P20
PTI_SYNC / PB13 / P22
GND
VRF
5V
GND
DBG_TCK_SWCLK / PF0 / P24
DBG_TMS_SWDIO / PF1 / P26
DBG_TDO_SWO / PF2 / P28
NC / P30
LED1 / PF5 / P32
NC / P34
NC / P36
NC / P38
NC / P40
NC / P42
NC / P44
NC
GND
3V3
Figure 3.2. Radio Board Pin Mapping on Breakout Pads
J101
VMCU
GND
P1 / PC6 / EXP4 / FLASH_MOSI / DISP_SI
P3 / PC7 / EXP6 / FLASH_MISO
P5 / PC8 / EXP8 / FLASH_SCLK / DISP_SCLK
P7 / PC9 / EXP10
P9 / PA0 / EXP12 / VCOM_TX
P11 / PA1 / EXP14 / VCOM_RX
P13 / PC11 / EXP16 / I2C_SDA
P15 / NC
P17 / NC
P19 / NC
P21 / NC
P23 / NC
GND
VRF
J102
5V
GND
P25 / NC
P27 / NC
P29 / NC
P31 / PD13 / DISP_EXTCOMIN
P33 / PD14 / DISP_SCS
P35 / PD15 / DISP_ENABLE / SENSOR_ENABLE
P37 / PD15 / DISP_ENABLE / SENSOR_ENABLE
P39 / NC
P41 / NC
P43 / NC
P45 / NC
NC
GND
3V3
