- Page 1 Linear iSteam3 Control PUR100514 07-17 Linear SteamHead PUR100561-1 05-17 SteamLinx Mobile App PUR100518 01-18 AudioSteam3 System PUR100516 01-18 Square Speakers PUR100401SQ 05-13 ChromaSteam3 System PUR100515 01-18 AromaSteam System PUR100402 08-18 AutoFlush PUR100200E 10-15 Condensation Pan PUR100445 10-09...
- Page 2 steam Linear Steam Head ® ® –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Installation Instructions Model 104216 R E A D M E F I R S T ! CAUTION This signals a situation where injury or property damage may occur if you do not follow instructions. As you follow these instructions, you will notice warning and caution symbols.
- Page 3 steam Linear Steam Head ® ® ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Installation Instructions: Model 104216 R E A D M E F I R S T ! (cont.) CAUTION result in a leak within the wall cavity and cause problems • Do not modify or alter the steam head. Do not cover, associated with leaks, moisture and property damage block or insert any product that is not a MrSteam from leaks.
- Page 4 steam Linear Steam Head ® ® ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Installation Instructions: Model 104216 INSTALLATION STEPS STEAM EMISSION Because steam emissions are very hot, CAUTION locate the steam head where incidental contact by the bather with direct steam emission cannot occur. Steam Do not locate the steam head in any location where head the steam emission zone is near a seat, bench or any space occupied by any persons.
- Page 5 steam Linear Steam Head ® ® ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Installation Instructions: Model 104216 STEP 5. Plumb rigid copper tubing or brass pipe from the steam generator to the steam head. Plumbing must not form traps or valleys. Thread sealant must be used as STUD required to ensure a leak free joint.
- Page 6 I N S TA L L AT I O N I N S T R U C T I O N S Package Contents: SteamLinx Module and Mobile App allows for seamless • SteamLinx A with Integral Cable control of time and temperature using your smart phone •...
- Page 7 Connecting SteamLinx B to the Home Router Home Router • Plug the blue ethernet cable provided, into an ethernet slot on the back of the home router. Power • Plug the power Supply supply into a 120V outlet. 3’ Cable Ethernet Cable (3’) Connecting SteamLinx to the Internet...
- Page 8 Installation, Operation and Maintenance Manual Installation, Operation, and Maintenance Manual AudioSteam ® steam ® Feel Good Inc. ®...
- Page 9 IMPORTANT SAFETY INFORMATION READ ME FIRST: 1. Read and follow all instructions within this technical manual. 2. Heed all warnings, cautions, notices, and important notes. 3. Save this technical manual and leave with the homeowner. ABOUT WARNINGS, CAUTIONS, NOTICES, AND IMPORTANT NOTES: As you follow the instructions in this technical manual, you will see four types of callouts: WARNINGS, CAUTIONS, NOTICES, and IMPORTANT NOTES.
- Page 10 IMPORTANT SAFETY INFORMATION (cont.) WARNING Before installing or connecting the AudioSteam, please read the following: • To prevent a shock hazard, do not disassemble or alter the AudioSteam. • To prevent overtemperature shutoff and equipment damage, do not use foam to insulate the AudioSteam.
-
Page 11: Table Of Contents
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE TABlE OF CONTENTS INSTAllER INSTRUCTIONS 1. General information ..........5 Box Contents ..............5 AudioSteam General installation ......5-6 2. Installing AudioSteam ..........7 AudioSteam Dimensions ..........7 Locating and Installing AudioSteam ......7 3. Connecting AudioSteam ......... 8 Connecting AudioSteam ..........8 Removing the AudioSteam Cover .......8 Connecting the FM Antenna and Auxiliary Cord ..9... -
Page 12: Installer Instructions
mr . steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE I N S TA L L E R I N S T R U C T I O N S 1. General Information Box Contents AudioSteam FM antenna Control cable AudioSteam General Installation Figure 1 shows how the AudioSteam interconnects with the IMPORTANT NOTE... - Page 13 steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Speaker wire (100 ft max) Antenna (4 ft) Speakers AudioSteam Grounded wall outlet Power cord (6 ft) iSteam3 AudioSteam control cable (30/60 ft) In-room control cable (30/60 ft) S T E A M R O O M Steam ( d r y ) ( w e t )
-
Page 14: Installing Audiosteam
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 2. Installing AudioSteam AudioSteam Dimensions Figure 3 shows the face-on dimensions of AudioSteam. Figure 4 shows the side-view dimensions of AudioSteam. WARNING Shock hazard. Do not place the control box in a location where it can get wet. -
Page 15: Connecting Audiosteam
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 3. Connecting AudioSteam Connecting AudioSteam WARNING To connect AudioSteam to the steam generator, per- • To reduce the risk of electric shock, do not form one or more of the following connections: remove the screws on the back of AudioSteam. -
Page 16: Connecting The Fm Antenna And Auxiliary Cord
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Connecting the FM Antenna Replace Foam and Auxiliary Cord Blocks Plug the included FM antenna into the antenna Auxiliary output and route the wire through the strain relief Cord channel as illustrated (Figure 9). For best recep- tion, fully deploy the antenna in a vertical orienta- tion outside of the AudioSteam housing. -
Page 17: Connecting Audiosteam To The Steam Generator
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Connecting AudioSteam to the Steam Generator Power Cord To operate the AudioSteam via iSteam3, you must connect the to 120V AudioSteam (Figure 12) to an internal connector in the steam generator. Grounded Outlet Control Cable Connection Port... -
Page 18: Pairing A Bluetooth-Enabled Device
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Pairing a Bluetooth-Enabled Device Before playing a Bluetooth-enabled device via iSteam3 (see “Operating AudioSteam” on Page 17), you must pair your device to AudioSteam. To pair a Bluetooth-enabled device to AudioSteam: 1. Ensure that the mobile device is in range of AudioSteam, and that it is powered on and Bluetooth is turned on. -
Page 19: Audiosteam Specifications
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 4. AudioSteam Specifications ENVIRONMENTAl RATINGS FM RECEIVER Frequency band: 87.5 MHz to 107.9 MHz Operating temperature: -4 °F (-20 °C) to 140 °F (60 °C) RF sensitivity: 2.2 μV Storage temperature: -22 °F (-30 °C) to 185 °F (85 °C) Harmonic distortion: 0.1% à... -
Page 20: Regulatory Statements
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 5. Regulatory Statements FCC Compliance Statement Contains Transmitter Module FCC ID: A8TBM23SPKXYC2A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 21: Homeowner/End-User Instructions
mr . steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE H O M E O W N E R / E N D - U S E R I N S T R U C T I O N S 6. -
Page 22: Audiosteam Warranty
steam ® AudioSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 7. Operating AudioSteam (cont.) To Operate AudioSteam using iSteam3: 1. Boot iSteam3 and wait for the iSteam3 home screen to appear. 2. To turn on AudioSteam (Figure 14), tap the icon (A), and then tap the MUSIC button (B). music 3. - Page 23 steam ® Connecting Multiple Accessories to the Steam Generator To operate the SteamLinx, AudioSteam3 and ChromaSteam3 via iSteam3, you must connect the accessories to an internal connector in the steam generator. Shock hazard. Power must be disconnected at the main electri- cal supply before removing the steam generator cover.
-
Page 25: Sussman-Automatic Corporation
steam ® Feel Good Inc. ® www.mrsteam.com Products, information and specifications are subject to change without notice. Call Sales & Support at 1 800 76 STEAM (East Coast) or 1 800 72 STEAM (West Coast) for more information. steam ® Sussman-Automatic Corporation •... - Page 26 10. Let the silicone cure per manufacture's instructions before using steam room. WARRANTY: To view or download the Mr. Steam IMPORTANT: Do not place speakers in contact with Controls & Accessories Warranty and register your direct water or steam emission. Speakers may be product go to: blog.mrsteam.com/wr...
- Page 27 steam ® S Q U A R E S P E A K E R T E M P L AT E ⁄ ” ⁄ ” steam ® Sussman-Automatic Corporation® • www.mrsteam.com • hello@mrsteam.com 43-20 34th Street, Long Island City, NY 11101 : 1-800-76-STEAM : (718) 472-3256 9410 S.
- Page 28 steam ® S Q U A R E S P E A K E R T E M P L AT E ⁄ ” ⁄ ” steam ® Sussman-Automatic Corporation® • www.mrsteam.com • hello@mrsteam.com 43-20 34th Street, Long Island City, NY 11101 : 1-800-76-STEAM : (718) 472-3256 9410 S.
- Page 29 Installation, Operation and Maintenance Manual Installation, Operation, and Maintenance Manual ChromaSteam3 ® steam ® Feel Good Inc. ®...
- Page 30 IMPORTANT SAFETY INFORMATION READ ME FIRST: 1. Read and follow all instructions within this technical manual. 2. Heed all warnings, cautions, notices, and important notes. 3. Save this technical manual and leave with the homeowner. ABOUT WARNINGS, CAUTIONS, NOTICES, AND IMPORTANT NOTES: As you follow the instructions in this technical manual, you will see four types of callouts: WARNINGS, CAUTIONS, NOTICES, and IMPORTANT NOTES.
- Page 31 steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE TABLE OF CONTENTS INSTALLER INSTRUCTIONS 1. General information ..................4 Box contents ....................... 4 ChromaSteam3 general installation ..............5 2. Installing the ChromaSteam3 control box ..........6 Control box dimensions ..................6 Locating the control box ..................7 Installing the control box ..................
-
Page 32: Installer Instructions
mr . steam steam ® ® ChromaSteam ChromaSteam ® ® INSTALLATION, OPERATION, AND MAINTENANCE INSTALLATION, OPERATION, AND MAINTENANCE I N S T A L L E R I N S T R U C T I O N S 1. General information Box contents Junction box ChromaSteam3... -
Page 33: Chromasteam3 General Installation
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE ChromaSteam3 general installation Figure 3 shows how the ChromaSteam3 fixture and control box interconnect with each other, and with the steam generator and iSteam3. IMPORTANT NOTES • The included ChromaSteam3 control cable is 30 feet long. Ensure that the ChromaSteam3 fixture and control box are located accordingly. -
Page 34: Installing The Chromasteam3 Control Box
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 2. Installing the ChromaSteam3 control box Control box dimensions NOTICE • To prevent product or property damage, do not expose control box to temperatures above 140 °F (60 °C). Do not locate control box in an attic or any location where ambi- ent temperatures may exceed 140 °F (60 °C). -
Page 35: Locating The Control Box
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Locating the control box Determine the desired location of the ChromaSteam3 con- trol box outside the steam room in a dry location. WARNING Shock hazard. Do not place the control box in a loca- tion where it can get wet. -
Page 36: Installing The Chromasteam3 Xture
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 3. Installing the ChromaSteam3 fixture Fixture dimensions Figure 5 P O R T I O N I N C E I L I N G P O R T I O N I N S T E A M Figure 6 R O O M... -
Page 37: Installing The Junction Box
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Installing the junction box WARNING • Installation to be performed by Functions of the junction box: a qualified and licensed electri- Allows precisely location of the ChromaSteam3 fixture within the steam cian. room ceiling. - Page 38 steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Ceiling joist Knockouts Junction box tabs Figure 7 Figure 8 End of 30-foot control cable Figure 9 Figure 10 All drawings are for illustrative purposes only.
-
Page 39: Installing The Xture
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE Installing the fixture To install the fixture: Connect the ChromaSteam3 fixture’s pigtail to the 30-foot control cable in the junction box (Figure 11). IMPORTANT NOTE Test that the fixture operates correctly prior to continuing with the following steps. - Page 40 steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 4. Connecting the ChromaSteam3 fixture to the ChromaSteam3 control box WARNING • Shock hazard. Ensure that power is turned off during installation. Turn off power at breaker panel. • Shock hazard. To prevent electric shock, do not remove the screws on the back of the con- trol box.
-
Page 41: Connecting The Chromasteam3 Control Box To The Steam Generator
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 5. Connecting the ChromaSteam3 Control Box to the Steam Generator The nal connection is made from the ChromaSteam control box (Figure 21) to an internal connector in the steam generator. WARNING 30-foot Shock hazard. -
Page 42: Chromasteam3 Speci Cations
steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE 6. ChromaSteam3 specifications ENVIRONMENTAL RATINGS CONTROL BOX FIXTURE Operating temperature: -4 °F (-20 °C) to 140 °F (60 °C) -4 °F (-20 °C) to 140 °F (60 °C) Storage temperature: -22 °F (-30 °C) to 185 °F (85 °C) -22 °F (-30 °C) to 185 °F (85 °C) Humidity: 70% max... -
Page 43: Homeowner/End-User Instructions
mr . steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE H O M E O W N E R / E N D - U S E R I N S T R U C T I O N S 7. - Page 44 steam ® Auxiliary Board Installation ________________________________________________________________________ IMPORT NT NOTE: FOR SAFE AND TROUBLE FREE INSTALLATION visit mrsteam.com before installation to download the Installation, Operation and Maintenance Manual or refer to the manual provided with the CHROMASTEAM3. Control Cable W RNING Shock hazard.
- Page 45 steam ® Connecting Multiple Accessories to the Steam Generator To operate the SteamLinx, AudioSteam3 and ChromaSteam3 via iSteam3, you must connect the accessories to an internal connector in the steam generator. Shock hazard. Power must be disconnected at the main electri- cal supply before removing the steam generator cover.
- Page 46 steam ® ® Feel Good Inc. www.mrsteam.com Products, information and specifications are subject to change without notice. Call Sales & Support at 1 800 76 STEAM (East Coast) or 1 800 72 STEAM (West Coast) for more information. steam ® ®...
- Page 47 Installation, Operation & Maintenance Manual AromaSteam ® steam Feel Good Inc. ® ®...
- Page 48 steam ® AromaSteam Operation and Installation Instructions ______________________________________________________________________________________________ WARNING RISk OF ELECTRIC SHOCk - This pump is supplied with MS Aroma a grounding conductor and grounding-type attachment plug. To reduce the risk of electric shock, be certain that it is connected only to a properly Table of Contents grounded, grounding-type receptacle.
-
Page 49: Box Contents
steam ® AromaSteam Operation and Installation Instructions ______________________________________________________________________________________________ BOx CONTENTS 8 ft. Pressure 1/4 x 1/2 NPT Hose Atomizing Nozzle Injector AromaSteam System Installation & Operation Manual (with integrated 6 ft. power cord, 8 ft. request cable) with Peel-off Warning Label Additional Items Included but Not Shown: Foot Valve •... - Page 50 steam ® AromaSteam Operation and Installation Instructions ______________________________________________________________________________________________ GENERAl INSTAllATION (cont.) Tubing Figure 1 Clearance to Heat Sources • Do not install the AromaSteam system directly below or above the MrSteam Tightening Nut steam generator where it is subject to heat. •...
- Page 51 steam ® AromaSteam Operation and Installation Instructions ______________________________________________________________________________________________ Installation of Suction Hose to Pressure Hose AromaSteam System Repeat the suction hose installation steps on the pressure side of the pump. 1. unscrew the suction end nut from the pump head. MrSteam recommends installing the AromaSteam 2.
-
Page 52: Start-Up
steam ® AromaSteam Operation and Installation Instructions ______________________________________________________________________________________________ AromaSteam Electrical Connection of AromaSteam Wiring Schematic AromaSteam System Plug CAUTION This AromaSteam system is factory wired. If the 120 VAC power cord of the Aroma Steam system is damaged it must be Outlet replaced by the Sussman-Automatic service department or simi- (grounded receptacle... -
Page 53: Operation
steam ® AromaSteam Operation and Installation Instructions ______________________________________________________________________________________________ OPERATION Powering Up the Pump Aromatic IMPORTANT NOTE: This step only needs to be performed Setting knob during installation. Power Button 1. The pump needs to be turned on before it can be used 2. -
Page 54: Troubleshooting
steam ® AromaSteam Operation and Installation Instructions ______________________________________________________________________________________________ TROUBlESHOOTING TECHNICAl SPECIFICATIONS lIST OF SPARE PARTS To AVoID ELECTrIC SHoCK, WARNING Description Part No. DISCoNNECT PoWEr To PuMP BEForE SErVICING Pump Head 104239 Metering pump does not prime Pressure/Suction Hose 104255 (ordered by the foot) 1. - Page 55 mr . steam ® Optional Autoflush ® System ____________________________________________________________________________________________________________________________________________ INSTA LLAT ION INS TRUCTI ONS BOX CONTENTS: • AutoFlush System Valve with Cord • Installation Instructions. ® ASSEMBLY OF OPTIONAL AUTOFLUSH SYSTEM 3 Pin Connector for AutoFlush AutoFlush Cord Connector AutoFlush Cord AutoFlush Valve Steam Generator...
- Page 56 AutoFlush to the white wire from the circuit board using a wire nut. Repeat for the black wire. WARRANTY: To view or download the Mr. Steam IMPORTANT NOTE: Contact the Mr.Steam Technical Service Department for installation of any equipment not Controls &...
- Page 57 Technical Specifications Drain Pan MS 103867 Mr. Steam strongly recommends the use of a drain pan in the unlikely event of a plumbing leak. Locate the drain pan on a solid level surface and place the steam generator inside the drain pan.
