Summary of Contents for mr. steam ChromaSteam3
- Page 1 Installation, Operation, and Maintenance Manual ChromaSteam ® steam Feel Good Inc. ® ®...
- Page 2 • Do not disassemble or alter the ChromaSteam3 fixture or controller in any way. • Clean the ChromaSteam3 fixture and controller with a dry cloth only. Beware of the application of some products commonly used against corrosion (such as WD-40 family products), as some industrial oils can have negative ®...
-
Page 3: Table Of Contents
Fixture Dimensions ................7 Installing the Junction Box ............... 8-9 Installing the Fixture ................10 Connecting the ChromaSteam3 Fixture to the Control Box ..11 Connecting the ChromaSteam3 Control Box to the Generator ..12 Connecting Multiple Accessories to the Generator ......12 ChromaSteam3 Specifications ............ -
Page 4: General Information Box Contents
(Figure 1), and all accessory connectors/ports have been color-coded with adhesive dots (Figure 2). When connecting cables and accessory connectors, ensure that their respective flags and/or adhesive dots match in color. Figure 3 shows the colors (purple, white, blue, red, and yellow) used between each ChromaSteam3 connection. Cable to accessory connector:... -
Page 5: General Installation
INSTALLATION, OPERATION, AND MAINTENANCE ______________________________________________________________________________________ General Installation Figure 3 shows how the ChromaSteam3 fixture and control box interconnect with each other, and with the steam generator and iSteam3. MPORTANT NOTES • The included ChromaSteam3 control cable is 30 feet long. Ensure that the ChromaSteam3 fixture and con- trol box are located accordingly. -
Page 6: Installing The Chromasteam3 Control Box
IMPORTANT NOTE: The ChromaSteam3 control cable is 30 feet long. Ensure that the ChromaSteam3 fixture and control box are located accord- ingly. Contact MrSteam to purchase an optional 60-foot cable (PN104268-60). -
Page 7: Installing The Chromasteam3 Fixture
® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE ______________________________________________________________________________________ Installing the ChromaSteam3 Fixture Fixture Dimensions Figure 5 P O R T I O N I N C E I L I N G P O R T I O N... -
Page 8: Installing The Junction Box
ChromaSteam3 fix- enclosure. ture falling and causing injury. 2. ChromaSteam3 is for mood lighting only. Not to be used as a primary lighting source. NOTICE 3. Do not locate the fixture in direct shower spray, near direct steam •... - Page 9 steam ® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE ______________________________________________________________________________________ Ceiling joist Knockouts Junction box tabs Figure 7 Figure 8 End of 30-foot control cable or one of the longer ends of Duo cable Figure 9 Figure 10 All drawings are for illustrative purposes only.
-
Page 10: Installing The Fixture
Installing the Fixture To Install the Fixture: 1. Connect the ChromaSteam3 fixture’s pigtail to the 30-foot control cable or Duo cable in the junction box (Figure 11). IMPORTANT NOTE: Test that the fixture operates correctly prior to continuing with the following steps. -
Page 11: Connecting The Chromasteam3 Fixture To The Control Box
• For installation with two ChromaSteam3, the longer end of Duo cable (with a yellow flag stating “To fixture”) has been routed through conduit, the ChromaSteam3 fixture’s pigtail has been connected to the longer end of Duo cable (with a yellow flag stating “To Fixture”), one end of 30-foot control cable has been located for connection... -
Page 12: Connecting The Chromasteam3 Control Box To The Generator
2. Connect the controller cord directly to the steam generator’s Power Cord to 120V circuit board, Figure 20. Grounded Outlet 3. Plug the ChromaSteam3 control box power cord into a 120V Figure 19 grounded electrical outlet. Connecting Multiple Accessories to the Steam Generator To operate the SteamLinx, AudioSteam3 and ChromaSteam3 via iSteam3, you must connect the accessories to an internal connector in the steam generator. -
Page 13: Chromasteam3 Specifications
® ChromaSteam ® INSTALLATION, OPERATION, AND MAINTENANCE ______________________________________________________________________________________ ChromaSteam3 Specifications ENVIRONMENTAl RATINGS CONTROl BOx FIxTURE Operating temperature: -4 °F (-20 °C) to 140 °F (60 °C) -4 °F (-20 °C) to 140 °F (60 °C) Storage temperature: -22 °F (-30 °C) to 185 °F (85 °C) -22 °F (-30 °C) to 185 °F (85 °C) -
Page 14: Homeowner/End-User Instructions
3 system integrates light with steam, ® creating chromatherapy environments rich with color, mood, and warmth: • ChromaSteam3 suffuses the steam shower with a spectrum of color from airy blue to sensual red. • Vapor-sealed, low voltage LED module yield long-lasting high performance and cool operation. -
Page 15: Operating Chromasteam3
INSTALLATION, OPERATION, AND MAINTENANCE Operating ChromaSteam3 CAUTION You can control the ChromaSteam3 LED module from within your steam room Note that ChromaSteam3 is using the iSteam3 control. Select from 78,000 different colors — and control for mood lighting only, and does not substitute for gen- the brightness of the light —... - Page 16 steam ® Feel Good Inc. ® FOR MORE INFORMATION PLEASE CALL S a l e s & S u p p o r t 1.800.76.STEAM EAST COAST 1.800.72.STEAM WEST COAST www.mrsteam.com steam ® Sussman-Automatic Corporation • www.mrsteam.com • hello@mrsteam.com ® Products, information and 43-20 34th Street, Long Island City NY 11101 9410 S.
