User Manual
Thank you for purchasing our product. If there are any
questions, or requests, do not hesitate to contact the
dealer.
This manual applies to the model listed below.
Model
DS-2CE5AD0T-VPIT3F
This manual may contain several technically incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to the
new version of this manual. We will readily improve or
update the products or procedures described in the
manual.
2 MP Dome Camera
TURBO HD
User Manual
0300001080504

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TURBO HD DS-2CE5AD0T-VPIT3F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HIKVISION TURBO HD DS-2CE5AD0T-VPIT3F

Summary of Contents for HIKVISION TURBO HD DS-2CE5AD0T-VPIT3F

  • Page 1 TURBO HD 2 MP Dome Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, do not hesitate to contact the dealer. This manual applies to the model listed below. Model DS-2CE5AD0T-VPIT3F This manual may contain several technically incorrect places or printing errors, and the content is subject to change without notice.

  • Page 2: Regulatory Information

    Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.

  • Page 4: Installation

    While in delivery, the camera shall be packed in its  original packing, or packing of the same texture. Mark Description Table 0-1 Mark Description Mark Description DC Voltage 1 Introduction 1.1 Product Features The camera is applicable for both indoor and outdoor conditions, and the application scenarios include road, warehouse, parking lot, office, campus, etc..
  • Page 5 If the wall is cement, insert expansion bolts before  installing the camera. If the wall is wooden, use self- tapping screws to secure the camera. If the product does not function properly, contact your  dealer or the nearest service center. Do NOT disassemble the camera for repair or maintenance by yourself.
  • Page 6 Note: The supplied screw package contains self-tapping  screws, and expansion bolts. For cement ceiling, expansion bolts are required to  fix the camera. For wooden ceiling, self-tapping screws are required. 5. Route the cables through the cable hole, or the side opening.
  • Page 7 2. Attach the mount to the wall by aligning the four screw holes of the mount with expansion screws on the wall. 3. Secure the mount with four hex nuts, and washers. Figure 2-7 Install Wall Mount 4. Refer to step 3 of 2.1 Ceiling Mounting to remove dome camera’s bubble and the black liner.

  • Page 8: Menu Description

    Figure 2-10 Fix the Inclined Base 4. Route the cables through the cable hole, or the side opening of the inclined ceiling mount. 5. Fix the camera to the inclined ceiling mount with the supplied screws. Figure 2-11 Fix the Camera to the Mount 6.

  • Page 9: Video Format

    BRIGHTNESS EXPOSURE MODE DWDR RETURN FORMAT MODE RETURN MODE LANGUAGE INFRARED DAY-NIGHT SMART IR RETURN IMAGE MODE MAIN MENU CONTRAST SHARPNESS VIDEO SETTINGS COLOR GAIN MIRROR RETURN RESET SAVE & EXIT Figure 3-2 Main Menu Overview 5. Click the direction arrow to control the camera. 1).

  • Page 10: Exposure Mode

    Figure 3-3 EXPOSURE BRIGHTNESS Brightness refers to the brightness of the image. You can set the brightness value from 1 to 10 to darken or brighten the image. The greater the value is, the brighter the image is. EXPOSURE MODE You can set the EXPOSURE MODE as GLOBAL, or BLC.

  • Page 11: Image Mode

    3.3.3 DAY/NIGHT COLOR, B/W (Black White), and SMART are selectable for DAY and NIGHT switches. COLOR The image is colored in day mode all the time. The image is black and white all the time. SMART You can turn on/off the INFRARED, and set the value of SMART IR in this menu.

  • Page 12: Color Gain

    SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce. You can set the SHARPNESS value from 1 to 10. COLOR GAIN Adjust this feature to change the gain of the color. The value ranges from 1 to 10. DNR (Digital Noise Reduction) The DNR function can decrease the noise effect, especially when capturing moving images in poor light...
