  • Page 1 Hardware Identifier MD-8850 Assembly Instruction Parts List Warranty Ordering Parts Model MD-8850 Retain This Manual for Reference 07-27-09 OWNER'S MANUAL ® IMPEX INC. 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com...

  • Page 2: Table Of Contents

    BENCH EXPLODED DIAGRAM...............……. 23 BENCH PARTS LIST……………………………………………………………….. 24 WARRANTY....................… 25 ORDERING PARTS..................25 BEFORE YOU BEGIN Thank you for selecting the MARCY DIAMOND ELITE MD-8850 Olympic ® Cage by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notices

    OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT. SAVE THESE INSTRUCTIONS.
  • Page 4 WARNING LABEL PLACEMENT The warning labels shown here have been placed on the Rear Base Frame, Rear Stabilizer, and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.

  • Page 5: Cage Hardware Pack

    CAGE HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 CAGE HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

  • Page 7: Cage Assembly Instructions

    CAGE ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach a Ø 2 ½” Rubber Bumper (#29) and the Weight Storage Post (#14) to Right Stabilizer (#3).
  • Page 8 DIAGRAM 1...
  • Page 9 STEP 2 (See Diagram 2) A.) Insert two Guide Rods (#13) into the holes on the Weight Gliding Base (#7). Secure each Guide Rod with one M10 x ¾” Allen Bolt (#50) and Ø ¾” Washer (#52). B.) Slide two Ø 2 ½” Rubber Bumpers (#29) onto the two Guide Rods to the bottom. Slide the Sliding Frame (#8) onto the two Guide Rods.
  • Page 10 DIAGRAM 2...
  • Page 11 STEP 3 (See Diagram 3) A.) Attach the Sliding Weight Post (#15) to the Sliding Frame (#8). Secure it with two M8 x 1 3/8” Carriage Bolts (#44), two Ø 5/8” Washers (#53), and two M8 Aircraft Nut (#55). Make sure the triangular cable connecting bracket faces up.
  • Page 12 DIAGRAM 3...
  • Page 13 STEP 4 (See Diagram 4) A.) Attach the 128” Cable (#24) to the open Pulley bracket on Rear Base Frame (#4). B.) Attach a Pulley to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#48), two Ø ¾” Washers (#52), and one M10 Aircraft Nut (#54).
  • Page 14 STEP 5 (See Diagram 5) A.) Slide two Olympic Sleeves (#35) to the Weight Sliding Post (#8). Attach two Spring Clips (#59) to the Sleeves. B.) Attach the Left and Right Bar Catches (#11 & #12), Left and Right Safety Catches (#9 &...

  • Page 15: Cage Exploded Diagram

    CAGE EXPLODED DIAGRAM...

  • Page 16: Cage Parts List

    CAGE PART LIST KEY NO. DESCRIPTION Q’ty Upright Beam ST3.8 Philips Screw Left Stabilizer Ø ¾” Washer Right Stabilizer Ø 5/8” Washer Rear Base Frame M10 Aircraft Nut Top Beam M8 Aircraft Nut Upper Frame Hook Weight Glide Base 10-link Chain Sliding Frame 15-link Chain Left Safety Catch...

  • Page 17: Bench Hardware Pack

    BENCH HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 18 BENCH HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

  • Page 19: Bench Assembly Instructions

    BENCH ASSEMBLY INSTRUCTION STEP 1 (See Diagram 1) A.) Attach the Bench Base Frame (#6) to the Rear Stabilizer (#7). Secure the side-holes with two M10 x 4” Carriage Bolts (#41), two Ø ¾” Washers (#31), and two M10 Aircraft Nuts (#33). Secure the top hole with one M10 x 5/8” Allen Bolt (#36) and one Ø...
  • Page 20 STEP 2 (See Diagram 2) A.) Attach the Main Seat Support (#1) to the Bench Base Frame (#6). Secure it with three M10 x 4” Carriage Bolts (#41), three Ø ¾” Washers (#31), and three M10 Aircraft Nuts (#33). B.) Attach the Front & Rear Seat Bracket (#4 & #5) to Main Seat Support. Secure each Bracket with one M10 x 4”...
  • Page 21 STEP 3 (See Diagram 3) A.) Align the bracket on the Backrest Adjustment Support (#8) in between the two Backrest Supports (#3). Secure it with four M8 x 1 5/8” Allen Bolts (#34), eight Ø 5/8” Washers (#30), and four M8 Aircraft Nuts (#32). Do not tighten the Nuts and Bolts yet. B.) Insert the Backrest Adjustment Support into the opening on the Main Seat Support (#1).
  • Page 22 STEP 4 (See Diagram 4) A.) Attach the Backrest Board (#13) to the Backrest Supports (#3). Secure it with four M8 x 1 5/8” Allen Bolts (#34) and four Ø 5/8” Washers (#30). B.) Attach the Seat Pad (#12) to Front & Rear Seat Bracket (#4 & #5). Secure them with four M8 x 1 5/8”...
  • Page 23 STEP 5 (See Diagram 5) A.) Attach the Leg Developer (#2) to Main Seat Support (#1). Secure it with one M10 x 3 1/8” Allen Bolt (#38), two Ø ¾” Washers (#31), and one M10 Aircraft Nut (#33). B.) Insert two Foam Tubes (#10) halfway through the holes on Leg Developer. Push four Foam Rolls (#16) onto the Tubes from both ends.

  • Page 25: Bench Parts List

    BENCH PARTS LIST KEY NO. DESCRIPTION Q’ty Main Seat Support Leg Developer Backrest Support Front Seat Bracket Rear Seat Bracket Bench Base Frame Rear Stabilizer Backrest Adjustment Support 1 Backrest Adjustment Lever Foam Tube Spring Seat Pad Backrest Board 2 ¾” Grip 2”...

  • Page 26: Warranty
