NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Exploded Diagram
Parts List
Warranty
Ordering Parts
Model
MD-860
Retain This
Manual for
Reference
07/10/09
OWNER'S
MANUAL
MARCY DIAMOND
WEIGHT BENCH
14777 Don Julian Rd., City of Industry, CA 91746
Tel: (800) 999-8899 Fax (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
ELITE
MD-860
®
IMPEX
INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-860 and is the answer not in the manual?

Questions and answers

Related Manuals for Impex MD-860

Summary of Contents for Impex MD-860

  • Page 1 NOTE: Please read all instructions carefully before using this product MARCY DIAMOND Table of Contents ELITE Safety Notice Hardware Pack WEIGHT BENCH Assembly Instruction MD-860 Exploded Diagram Parts List Warranty Ordering Parts Model MD-860 Retain This Manual for Reference 07/10/09...

  • Page 2: Table Of Contents

    EXPLODED DIAGRAM..................PARTS LIST..................... WARRANTY..................... ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the MARCY DIAMOND WEIGHT BENCH MD-860 by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notice

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.

  • Page 4: Warning Label Placement

    WARNING LABEL PLACEMENT The Warning Labels shown here have been placed on the Cross Brace and Rear Stabilizer. If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the labels in location shown...

  • Page 5: Hardware Pack

    HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

  • Page 7: Assembly Instruction

    ASSEMBLY INSTRUCTION Tools Required For Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended for two or more people to assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Do not tighten Nuts and Bolts until instructed to do so. B.) Attach an Upright Beam (#1) onto a Rear Base Frame (#2).
  • Page 8 STEP 2 (See Diagram 2) A.) Do not tighten Nuts and Bolts until instructed to do so. B.) Attach the Main Seat Support (#6) to the Rear Stabilizer (#8). Secure it with two M10 x 3 ¾” Carriage Bolts (#35), one 5 ½” Curved Bracket (#13), two Ø ¾” Washers (#43), and two M10 Aircraft Nuts (#46).
  • Page 9 STEP 3 (See Diagram 3) A.) Attach two Incline Support Frames (#15) to the Main Seat Support (#6) from both sides. Align the holes. Secure the Incline Support Frames to the Main Seat Support with three M10 x 3 ½” Allen Bolts (#38), six Ø ¾” Washers (#43), and three M10 Aircraft Nuts (#46). B.) Attach the Incline Support (#11) to the side-holes on the two Backrest Supports (#9).
  • Page 10 STEP 4 (See Diagram 4) A.) Attach the Backrest Board (#20) to the Backrest Supports (#9). Secure it with four M8 x 1 5/8” Allen Bolts (#40) and four Ø 5/8” Washers (#44). B.) Place the Seat Pad (#19) onto the seat bracket on Main Seat Support (#6). Secure it with four M8 x 1 5/8”...
  • Page 11 STEP 5 (See Diagram 5) A.) Attach the Leg Developer (#7) to the open bracket on the Front Post (#5). Secure it with one Leg Developer Axle (#16), two M10 x ¾” Allen Bolts (#39), and two Ø ¾” Washers (#43). B.) Insert three Foam Tubes (#12) halfway through the holes on the Leg Developer and Front Post.

  • Page 13: Parts List

    PARTS LIST KEY NO. DESCRIPTION QUANTITY Upright Beam Rear Base Frame Cross Brace Crutch Front Post Main Seat Support Leg Developer Rear Stabilizer Backrest Support Arm Curl Stand Incline Support Foam Tube 5 ½” Curved Bracket 3 ½” Curved Bracket Incline Support Frame Leg Developer Axle Foam Roll...

  • Page 14: Impex Inc

    IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser.
