  • Page 1 Resistance Chart Warranty Ordering Parts Model MD-2109 Retain This Manual for Reference 06-30-08 OWNER'S MANUAL Marcy Diamond Home Gym MD-2109 IMPEX 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 Tel: (800) 999-8899 Fax: (626) 961-9966 www.impex-fitness.com info@impex-fitness.com ® INC.

  • Page 2: Table Of Contents

    RESISTANCE CHART…………...………. 20 WARRANTY...…………. 21 ORDERING PARTS...………… 21 BEFORE YOU BEGIN Thank you for selecting the Marcy Diamond MD-2109 HOME GYM by ® IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notice

    PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

  • Page 4: Warning Label Replacement

    WARNING LABEL REPLACEMENT The warning labels shown here have been placed on the Rear Base and Upper Frame. If the labels are missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.

  • Page 5: Hardware Pack

    HARDWARE PACK...
  • Page 6 HARDWARE PACK...
  • Page 7 HARDWARE PACK...

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches, two Allen Wrenches, and one Philips Screwdriver. NOTE: It is strongly recommended this machine to be assembled by two or more people to avoid possible injury. STEP 1 (See Diagram 1) A.) Connect two Lower Guide Rods (23) and two Upper Guide Rods (#24) with two M10 Stud Bolts (#80).
  • Page 9 DIAGRAM 1...
  • Page 10 STEP 2 (See Diagram 2) A.) Slide two Ø2 ½” x 1” Rubber Bumpers (#65) onto the Guide Rods. B.) Slide 9 Weight Plates (#33) onto the Guide Rods. Make sure the deep groove on the Weight Plates all facing the back of the machine and downward. Insert the Selector Rod (#17) through the center hole on the Weight Plates.
  • Page 11 DIAGRAM 2...
  • Page 12 STEP 3 (See Diagram 3) A.) Attach the Front Press Base (#11) to the Upper Frame (#4). Secure it with one Long Axle (#46), two Ø ¾” Washers (#83), and two M10 Aircraft Nuts (#85). B.) Attach the Right Butterfly (#6) to the Front Press Base (#11). Secure it with one Ø 1 ½” Washer (#82), one M6 x 1 ¼”...
  • Page 13 STEP 4 (See Diagram 4) A.) Attach the Leg Developer (#7) to the bracket on the Leg Developer Holder (#1). Secure it with a Leg Developer Axle (#47), two M10 x 5/8” Allen Bolts (#74), and two Ø ¾” Washers (#83).

  • Page 14: Cable Loop Diagram

    CABLE LOOP DIAGRAM...
  • Page 15 STEP 5 (See Diagram 5 & Cable Loop Diagram) A.) Attach the 142” Upper Cable (#35) to the opening at the front of the Upper Frame (#4). Note: The Ball Stopper on the cable should be underneath the Frame. B.) Attach a Pulley (#63) to the opening. Secure it with one M10 x 2 3/8” Allen Bolt (#71), two Pulley Bushings (#50), and one M10 Aircraft Nut (#85).
  • Page 16 DIAGRAM 5...
  • Page 17 STEP 6 (See Diagram 6 & Cable Loop Diagram) A.) Attach one end of the 119” Butterfly Cable (#37) to the hook on the Right Butterfly (#6). B.) Draw the Cable to the right Swivel Pulley Bracket (#21). C.) Attach a Pulley to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#72), two Ø ¾” Washers (#83), and one M10 Aircraft Nut (#85).
  • Page 18 STEP 7 (See Diagram 7 & Cable Loop Diagram) A.) Attach the 128” Lower Cable (#36) to the open bracket on the bottom of the Leg Developer (#7). B.) Attach a Pulley to the bracket. Secure it with one M10 x 1 ¾” Allen Bolt (#72), two Ø ¾”...
  • Page 19 DIAGRAM 7...

  • Page 20: Parts List

    PARTS LIST KEY NO. DESCRIPTION Leg Developer Holder Rear Base Frame Lower Vertical Frame Upper Frame Left Butterfly Right Butterfly Leg Developer Main Base Frame Butterfly Pulley Bracket Lat Bar Warning Label Front Press Base Left Front Press Handle Right Front Press Handle Upper Vertical Frame Front Base Plate Seat Support...

  • Page 22: Warranty

    IMPEX Customer Service Department at 1-800-999-8899. All freights on products returned to IMPEX must be prepaid by the customer. This warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse, misuse, improper or abnormal usage or repairs not provided by an IMPEX authorized service center or for products used for commercial or rental purposes.
