Table Of Contents - SubSurface Instruments PL-VF10 User Manual

Table of Contents ............................................... 03
Introduction ....................................................... 04
Disclaimer of Liability ......................................... 04
Important Notices .............................................. 04
Compliance ....................................................... 05
Prepare for Use ................................................. 06
Register Extended Warranty ............................... 06
Programming Frequencies .................................. 07
PL-VF3 Transmitter Controls and Indicators .......... 08
PL-VF10 Transmitter Controls and Indicators ......... 09
Direct Connect ................................................... 10
Hard Coupler Connection ................................... 10
Inductive Connection .......................................... 11
Blind Search ...................................................... 11
Selecting the Tracing Signal ................................ 12
Receiver Controls & Indicators ............................ 13
Remote Controls ................................................ 14
Selecting the Locating Mode .............................. 15
Peak Locating Mode .......................................... 15 - 16
Null Locating Mode ........................................... 16
Left/Right Auto-Gain Mode ................................ 17
Absolute Signal Strength .................................... 17
www.ssilocators.com
t C
able of ontents
G I
eneral nformatIon
Gain Level Indication ......................................... 17
Passive 50/60 Hz Locating ................................. 18
Passive Radio Frequency Locating ....................... 18
Passive Rectifier CP Locating ............................... 18
Push Button Depth .............................................. 19
Depth Measurement 45º Angle Method .............. 20
Current Measurement ......................................... 21
Tilted Magnetic Field Identification ...................... 21
Locating a Sonde or Camera Head ..................... 22
Attaching a Push Device to the Sonde ................. 22
Locating a Sonde ............................................... 23
Depth Measurement Camera Head or Sonde ...... 24
A-Frame Controls & Indicators ............................ 25
Fault Locating with A-Frame .............................. 26 - 27
Fault Beneath Paved Surface ............................. 28
PL-VF3 Transmitter & Receiver Specifications ........ 29
PL-VF10 Transmitter & Receiver Specifications ...... 30
Factory Service .................................................. 31
Warranty........................................................... 31
Click on any t
Click on the f
t
he
B
rowsing
to go to that page or
itle
to go back to
ooter
t C
able of ontents
T
ip
03
SERIES
