Table Of Contents - SubSurface Instruments PL-VF Series User Manual

Table of Contents ............................................... 03
Introduction ....................................................... 04
Disclaimer of Liability ......................................... 04
Important Notices .............................................. 04
Prepare for Use ................................................. 05
Register Extended Warranty ............................... 05
Programming Frequencies .................................. 06
Transmitter Controls and Indicators ..................... 07
Direct Connect ................................................... 08
FlexiCoupler Connection .................................... 08
Inductive Connection .......................................... 09
Blind Search ...................................................... 09
Selecting the Tracing Signal ................................ 10
Receiver Controls & Indicators ............................ 11
PathLink Controls ............................................... 12
Selecting the Locating Mode .............................. 13
Peak Locating Mode .......................................... 13 - 14
Null Locating Mode ........................................... 14
Left/Right Auto-Gain Mode ................................ 15
Absolute Signal Strength .................................... 15
Gain Level Indication ......................................... 15
Passive 50/60 Hz Locating ................................. 16
www.ssilocators.com
t C
able of ontents
G I
eneral nformatIon
Passive Radio Frequency Locating ....................... 16
Passive Rectifier CP Locating ............................... 16
Push Button Depth .............................................. 17
Depth Measurement 45º Angle Method .............. 18
Current Measurement ......................................... 19
Tilted Magnetic Field Identification ...................... 19
Locating a Sonde or Camera Head ..................... 20
Attaching a Push Device to the Sonde ................. 20
Locating a Sonde ............................................... 21
Sonde or Camera Head Depth Measurement ...... 22
STAFF Fault Finder Controls & Indicators ............. 23
Fault Locating with a Frame or Staff .................. 24 - 25
Fault Beneath Paved Surface ............................. 26
PL-VF Transmitter & Receiver Specifications .......... 27
Factory Service .................................................. 28
Warranty........................................................... 28
03
SERIES
