Zones; Controller Settings; Time Settings; Screen Settings - Tech Controllers EU-M-12 User Manual

4. ZONES

The function is used to enable/disable individual zones in the controllers. If a zone is blank and cannot be marked, it means
that no sensor or room controller has been registered in it.
Zones 1-8 are assigned to the main controller (EU-L-12), while zones 9-40 are assigned to EU-ML-12 in the order in which they
were registered.

5. CONTROLLER SETTINGS

5.1. TIME SETTINGS

The function is used to set the current date and time, which will be displayed on the main screen.

5.2. SCREEN SETTINGS

•
-
Screen Saver By pressing the
saver option (No screen
Clock – a clock visible on the blank screen
Screen fading – after the idle time has elapsed, the screen will be faded completely
The user can also set the
•
Screen brightness - the function allows you to set the screen brightness while the controller is working
•
Brightness blanking - the function allows you to set the brightness of the screen at the time of fading.
•
Screen dimming time - The function allows you to set the time that must elapse for the screen to fade completely
after the work is completed.

5.3. PROTECTIONS

•
Autoblock off – the function allows you to turn on/off the parental lock.
•
Autoblock PIN – if autoblock is enabled, it is possible to set a pin code to secure the controller settings.

5.4. SOUND THE BUTTONS

The function is used to enable/disable the key tones.

5.5. ALARM SOUND

The function is used to enable/disable the alarm sound. When the alarm sound is off, the alarm message will appear on the
display screen. When the alarm sound is on, in addition to the message on the display screen, the user will also hear an
audible signal informing about the alarm.

6. SOFTWARE VERSION

When this option is activated, the manufacturer's logo will appear on the display, along with the controller software
version.
Screen Saver Selection
saver) or set the screen saver in the form of:
Idle Time, after which the screen saver will start.
icon, we go to the panel that allows you to disable the screen
13
