➢ Schedule settings – the option to edit the schedule settings.
•
Local schedule – Schedule settings that only apply to this zone
•
Global Schedule 1-5 – These schedule settings apply to all zones.
The user can assign days of the week to 2 groups (marked in blue and gray). In each group, it is possible to edit separate pre-
set temperatures for 3 time intervals. In addition to the designated time intervals, the general pre-set temperature will apply,
the value of which can also be edited.
2
1
1. The overall pre-set temperature in the first group of days (days highlighted in blue, in the example above these are
working days: Monday - Friday). This temperature will apply in the zone outside the designated time periods.
2. Time intervals for the first group of days - pre-set temperature and time frame. Clicking in the area of the selected
time period will take you to the editing screen of its settings.
3. The general pre-set temperature in the second group of days (days highlighted in gray, in the example above it is
Saturday and Sunday).
4. Time intervals for the second group of days - pre-set temperature and time frame. Clicking in the area of the selected
time period will take you to the editing screen of its settings.
5. Groups of days: the first - Mon-Fri and the second – Sat-Sun
•
To assign a given day to a specific group, just click in the area of the selected day
•
To add time intervals, click in the area of the "+" sign.
CAUTION
The pre-set temperature can be set to within 15 minutes. In the event that the time intervals set by us overlap,
they will be highlighted in red. Such settings cannot be approved.
