Draytek Vigor2500V Series Quick Start Manual page 13

1.3.4 Vigor2510Vi
LED Status
on
VPN/E-mail
blinking
on
ISDN
blinking
ADSL on
green
VoIP
orange
ACT on
orange
green
LAN
)
(P1, P2, P3, P4
blinking
Interface Description
PWR Connect the included power adapter to the power outlet.
Line Connect to the analog phone line for PSTN life line.
Phone Connect to the analog phone for VoIP communication.
ADSL
Connect the ADSL line for accessing the Internet.
Restore the default settings. Usage: Turn on the router (ACT LED is
blinking), press the hole and keep for more than 5 seconds. When the ACT
Factory Reset
LED begins to blink rapidly, release the button. Then the router will restart
with the factory default configuration.
P1, P2, P3, P4 Connect to the local network devices.
ISDN Connect to external NT1(or NT1+) box provided by ISDN service provider.
Explanation
The VPN tunnel is launched.
Blinking when detecting e-mail arriving on any user-defined
mail server.
When the ISDN network is correctly setup.
When the ISDN BRI B1/B2 channels are connected to remote
side successfully.
The ADSL line is showtime.
Solid light when the handset of phone is picked up (off
hooked).
Blinking per 2 seconds when phone is connected through
VoIP.
Blinking per 0.3 seconds when phone is connected through
ISDN loop through.
Solid light when phone call is via PSTN life line.
The router is powered on and running properly.
A normal 10Mbps connection is through its corresponding port.
A normal 100Mbps connection is through its corresponding
port.
Ethernet packets are transmitting.
7
