Summary of Contents for Draytek Vigor2500V Series
- Page 2 Vigor2500V Series Quick Start Guide Copyright Information Copyright Copyright 2005 All rights reserved. This publication contains Declarations information that is protected by copyright. No part may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language without written permission from the copyright holders.
- Page 3 Firmware & Due to the continuous evolution of DrayTek ADSL & Router Tools Updates technology, all routers will be regularly upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and documents.
- Page 4 Address: No. 26, Fu Shing Road, HuKou County, HsinChu Industrial Park, Hsin-Chu, Taiwan 303 Product: Vigor2500 Series ADSL VoIP Routers DrayTek Corp. declares that Vigor2500 series of routers are in compliance with the following essential requirements and other relevant provisions of R&TTE Directive 1999/5/EEC.
- Page 5 Regulatory Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 6: Table Of Contents
1.1 Brief Overview…………………………………………………………..…… 1.2 Specifications……………………………………………………..…………. 1.3 Front Panel LEDs and Rear Panel Interfaces………………..……….… 1.4 Package Contains…………………………………………………..……….. 2. Quick Install Your Vigor2500V Series Router…………………… 2.1 Hardware Installation……………………………….……………..……….. 2.2 Configure Your Router via Quick Start Wizard…………………..…….. 10 Automatic QoS for VoIP………………………………………..…………..… 12 3. -
Page 7: Introduction
1. Introduction Easy Internet-sharing of your broadband connection. Robust Firewall to help protect your network from external attacks. Making regular phone calls over your broadband connection by simply plugging in your phone. QoS-assured VoIP facilities to deliver superior quality. Automatic failover for your Public Switched Telephone Network (PSTN) during power cuts. -
Page 8: Brief Overview
PSTN (regular analogue) line. The option can be used to set an alternate telephone number for your contact on the PSTN, which the Vigor2500V series will dial instead of the SIP account if you lose ADSL access or power to the Vigor ADSL VoIP routers. -
Page 9: Specifications
1.2 Specifications For Vigor25100V/Vi For Vigor2500Vi/2510Vi ISDN Up to 2 simultaneous VPN tunnels Euro ISDN compatible Dial-in or dial-out, LAN-to-LAN or Automatic ISDN backup Teleworker-to-LAN 64/128Kbps(multilink-PPP) Supported Protocol: PPTP, IPSec, /BoD(Bandwidth on Demand) L2TP, L2TP over IPSec Remote Dial-In/LAN-to-LAN Encryption: AES, MPPE, and connection hardware- based DES/3DES Remote activation... -
Page 10: Front Panel Leds And Rear Panel Interfaces
1.3 Front Panel LEDs and Rear Panel Interfaces 1.3.1 Vigor2500V Status Explanation The router is powered on and running properly. Blinking when detecting e-mail arriving on any user-defined E-mail green mail server. ADSL The ADSL line is showtime. Solid light when the handset of phone is picked up (off hooked). - Page 11 1.3.2 Vigor2500Vi Status Explanation The router is powered on and running properly. When the ISDN network is correctly setup. ISDN When the ISDN BRI B1/B2 channels are connected to remote blinking side successfully. ADSL The ADSL line is showtime. Solid light when the handset of phone is picked up (off hooked).
- Page 12 1.3.3 Vigor2510V Status Explanation The VPN tunnel is launched. Blinking when detecting e-mail arriving on any user-defined E-mail green mail server. ADSL The ADSL line is showtime. Solid light when the handset of phone is picked up (off hooked). green Blinking per 2 seconds when phone is connected through VoIP VoIP.
- Page 13 1.3.4 Vigor2510Vi Status Explanation The VPN tunnel is launched. VPN/E-mail Blinking when detecting e-mail arriving on any user-defined blinking mail server. When the ISDN network is correctly setup. ISDN When the ISDN BRI B1/B2 channels are connected to remote blinking side successfully.
-
Page 14: Package Contains
1.4 Package Contains Quick Start Guide UK-type power adapter EU-type power adapter USA/Taiwan-type power AU/NZ-type power adapter adapter RJ-11 Cable (Annex A / B) RJ-45 Cable (Ethernet) RJ-11 Cable (PSTN line) RJ-11 to RJ-45 (Annex B) RJ-45 to RJ-45 (ISDN) -
Page 15: Quick Install Your Vigor2500V Series Router
2. Quick Install Your Vigor2500V / 2510V Series Router 2.1 Hardware Installation Before starting to configure the router, you have to connect your devices correctly. 1. Connect the ADSL interface to the external splitter with a RJ-11 cable. 2. Connect one port of 4-port switch to your computer with a RJ-45 cable. 3. -
Page 16: Configure Your Router Via Quick Start Wizard
2.2 Configure Your Router via Quick Start Wizard Introduction The Quick Start Wizard is designed for you to easily set up your broadband Internet access. You can directly access the Quick Start Wizard via Web Configurator. Configure Your Router via Quick Start Wizard Step 1. - Page 17 Step 3. Now Quick Start Wizard is switched on. Enter login password. Then click Next to continue. Step 4 Select the appropriate Internet access type (PPPoE/PPPoA, MPoA) to your ISP. Or Clicking “Auto detect” button also offers the related DSL parameters automatically.
-
Page 18: Automatic Qos For Voip
Step 6 Review the summary of settings. The Vigor ADSL VoIP routers apply efficient voice codecs designed to make the best use of available bandwidth. They also equip with automatic QoS assurance. QoS Assurance assists to assign higher priority to voice traffic via Internet for better talking/hearing enjoyment. -
Page 19: Voip Settings
3. VoIP Settings Hardware Connection The Vigor2500V/2510V series have one FXS port, the “Phone” port on the rear panel. As mentioned in previous section 2.1 Hardware Installation, you will have to connect it to a conventional analog telephone, either corded or wireless (DECT). -
Page 20: Dialplan Setup
The major benefit of this mode is that you don’t have to memorize your friend’s IP address, which might change very frequently if it’s dynamic. Instead of that, you will only have to using dialplan or directly dial your friend’s account name if you are with the same SIP Registrar. - Page 21 For each Dial Plan, you will see the settings below: The detail explanation of the index window: Enable Tick this to enable this entry. Phone Number The “Speed-dial” number of this index. This can be any number you choose, using digits 0-9 and* SIP Address Enter your friend’s SIP URL Loop Through...
-
Page 22: Sip Related Function Setup
3.2 SIP Related Function Setup In this section, you set up your own SIP settings. When you apply for an account, your SIP service provider will give you an Username, and SIP Registrar. Then you can tell your folks your SIP Address as in Username @ SIP Registrar Please set each field in the SIP and Ports Settings accordingly. -
Page 24: Calling Scenario
3.3 Calling Scenario Calling via SIP Sever Example 1 John and David both have a SIP Address from different service providers. John’s SIP Address: 1234@draytel.org David’s SIP Address: 4321@iptel.org John’s settings David’s settings DialPlan index 1 DialPlan index 1 Phone Number: 1111 Phone Number:2222 SIP Address: 4321@iptel.org SIP Address:1234@draytel.org... - Page 25 Example 2 John and David both have a SIP Address from the same service provider. John’s SIP Address: 1234@draytel.org David’s SIP Address: 4321@draytel.org John’s settings David’s settings DialPlan index 1 DialPlan index 1 Phone Number: 1111 Phone Number:2222 SIP Address: 4321@draytel.org SIP Address:1234@draytel.org SIP Related Function SIP Related Function...
-
Page 26: Peer To Peer
Peer-to-Peer Calling Example 3 Arnor and Paulin each have a Vigor2500V router, they can call each other without SIP Registrar. First they will have each other’s IP address and assign an Account Name for the port used for calling. Arnor’s SIP Address: 1234@214.61.172.53 Paulin’s SIP Address: 4321@ 203.69.175.24 Arnor’s settings Paulin’s settings... -
Page 27: Trouble Shooting
Are the Network Connection Settings on Your PC OK? The following example is based on Windows XP case. Regarding to the examples of other OSs, please refer to the similar steps or find support notes in www.draytek.com. 1. Go to Control Panel and then double-click on Network Connections. - Page 28 2. Right-click on Local Area Connection and click on Properties. 3. Select on Internet Protocol (TCP/IP) and then click Properties.
-
Page 29: Can You Ping The Router From Pc
4. Select Obtain an IP address automatically and Obtain DNS server address automatically. Step 3 Can You Ping the Router from PC? The default gateway IP address of the router is 192.168.1.1. Please check that if you can ping the router correctly. A. -
Page 30: Are The Isp Settings Ok
B. For Mac (Terminal) The important thing is that the computer receives a reply from 192.168.1.1. If not, please check the IP address of your PC. We suggest you set the network connection as get IP automatically. (Please refer to the Step 2) Step 4 Are the ISP Settings OK? Click Internet Access Setup group and then check whether the... -
Page 31: Back To Factory Default Setting
B. For MPoA (RFC1483/2684) Users (refer to the following figure) 1. Check that if the Enable option is selected. 2. Verify if all parameters of DSL Modem Settings are entered with correct value which given by your ISP. 3. Verify if IP Address, Subnet Mask and Gateway are set correctly, or that your ISP requires using DHCP clients to obtain IP automatically. - Page 32 After restore the factory default setting, please repeat Step 1 to Step 4 to reinstall the router. Configure the router according to your recorded settings. If the router does not work correctly, please contact your dealer for help. For any further questions, please send e-mail to support@draytek.com...
