HAMPSTEAD FIRE COLUMN
ASSEMBLY INSTRUCTIONS
CSA Model YB20YL
SKU: 272-2286
Factory Model:
BRK01700K01
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, leave the area
immediately.
• After leaving the area, call your gas
supplier or fire
department.
Failure to follow these instructions
could result in fire or
explosion, which could cause property
damage, personal injury, or death.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
DANGER
CARBON MONOXIDE HAZARD
This appliance can produce carbon
monoxide which has no odor.
Using it in an enclosed space can kill
you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
Questions, Problems, Missing Parts? Before returning to
your retailer, call our customer service department in the
US and Canada at 1-800-416-3511, Monday-Friday, 9 a.m.–
5 p.m. Eastern Time.
JUL-01-2021
Installer: Leave these instructions with consumer.
Consumer: Keep these instructions for future reference
WARNING:
Improper installation, adjustment alteration,
service or maintenance can cause injury or
property damage. Read the installation,
operating and maintenance instructions
thoroughly before installing or servicing this
equipment.
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury, or loss of life.
WARNING: For Outdoor Use Only.
Installation and service must be performed
by a qualified
installer, service agency, or the gas supplier.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
FOR USE ONLY WITH A 16.4 oz (465 g).
PROPANE CYLINDER (NOT SUPPLIED)
WARNING:
USE FACTORY APPROVED
REPLACEMENT PARTS AND
ACCESSORIES ONLY. USE
OF UNAPPROVED PARTS
OR ACCESSORIES CAN
VOID THE WARRANTY ON
THIS PRODUCT AND
RESULT IN A HAZARDOUS
CONDITION. PLEASE
CONTACT US FOR
INFORMATION REGARDING
REPLACEMENT PARTS.
1
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Backyard Creations YB20YL
Summary of Contents for Backyard Creations YB20YL
- Page 1 ASSEMBLY INSTRUCTIONS Installer: Leave these instructions with consumer. Consumer: Keep these instructions for future reference WARNING: Improper installation, adjustment alteration, CSA Model YB20YL SKU: 272-2286 service or maintenance can cause injury or Factory Model: property damage. Read the installation, BRK01700K01...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information………………………......3 Important About Propane …………………………………………...4 Specification…………………………………………………………..4 Parts Identification List………………………………….……………5 Installation……………………………………………………………6-7 Lighting Instructions…………………………………………………..8 Replacing Fuel Cylinders…………………………………………….9 Maintenance…………………………………………………………...9 Warranty……………………………………………………………..10... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION The appliance area must be kept clear and free from combustible materials, gasoline, and other flammable vapors and liquids. Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control which has been under water. -
Page 4: Important About Propane
IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS A self contained Propane gas cylinder for use with this appliance must have a capacity of 16.4 oz (465g) and must be arranged to provide for proper fuel withdrawal from the operating cylinder. The LP-gas supply cylinder to be used must be constructed and marked in accordance with the specification for LP-gas cylinders of the U.S. -
Page 5: Parts Identification List
PARTS IDENTIFICATION LIST PART DESCRIPTION PART# FIRE ICE(TOTAL:8KG) FP3574 CONTROL KNOB FP3794 KNOB EXTENSION FP3795 M4 SCREW HW0898 1/4” X20 MM BOLT HW0036 WASHERS HW0594 HEX BOLT DRIVER HW0006 CROSS POINT HW0900 SCREWDRIVER BURNER PAN PROTECTIVE FP3796 RING FIREPAN/BURNER FP3797 ASSEMBLY FIREPIT BASE FP3798... -
Page 6: Installation
INSTALLATION 1. Carefully unpack all items from the box. Place the base in the final position. There must be a minimum of 12 in./30.5 cm of clearance from the side of the table top to any combustible walls. 2. Place the firepit tabletop onto the firepit base. Secure the tabletop to the firepit base by using the 1/4 x 20 mm bolts and washers that are provided. - Page 7 4.Make sure the control knob is turned all the way clockwise in the OFF position. 5.Screw the Propane Cylinder clockwise onto the valve. Hand tighten only. Do not cross thread. Use only a 16.4 oz (465g) cylinder with a NO.600 connection. Do Not use a 14.1 oz (400g) cylinder.
-
Page 8: Lighting Instructions
LIGHTING INSTRUCTIONS 1.Hold a lit match to the surface of the fire ice. 2.While holding the lit match to the fire ice, press the control knob in slightly and turn it counterclockwise to the HIGH position. After the burner is lit, the flame height can be adjusted from HIGH to LOW. -
Page 9: Replacing Fuel Cylinders
REPLACING FUEL CYLINDERS Screw the Propane Cylinder clockwise into the valve. Hand tighten only. Do not cross thread. Use only a 16.4 oz (465g) cylinder with a No.600 connection. Do not use a 14.1 oz (400g) cylinder. Apply a soapy water solution to the connection. If bubbles form, the connection has a leak. -
Page 10: Warranty
ONE-YEAR LIMITED WARRANTY What is Covered Under This Warranty? The item you have purchased is warranted against defects in material and workmanship for the following parts from the date of purchase for the period of warranty as outlined below, but only when the unit is installed and operated in accordance with the instructions in this Owner’s Manual and in compliance with local building and fire codes: Limited 1 Year...
