INSTALLATION AND CARE GUIDE
AIR AND WHIRLPOOL HEATED BATHTUB
BJ100
Certified to the following Codes & Standard:
• UL 1795 Safety Standard for Hydromassage Bathtubs
• ASME A112.19.7 / CSA B45.10) – Hydromassage Bathtub Systems
• CSA B45.5/IAPMO Z124 – Plastic Plumbing Fixtures
• International Plumbing Code
• International Residential Code
• Uniform Plumbing Code
•
National Plumbing Code of Canada
READ ALL INSTRUCTIONS BEFORE UNPACKING THE PRODUCT
INSTRUCTIONS THAT, IF IGNORED COULD RESULT IN DEATH OR SERIOUS INJURY CAUSED BY INCORRECT HANDLING
OR INSTALLATION OF THE PRODUCT. THESE INSTRUCTIONS MUST BE OBSERVED FOR SAFE INSTALLATION.
This products must be installed by a fully insured and licensed plumber only. Installation of any our product by anyone other
than fully insured and licensed plumber shall void limited warranty. We recommends that such licensed plumber has experience
in the installation of products.
We are not responsible for local code compliance for this product. Building and plumbing codes may vary from state-to-state in
accordance to your location. We are not responsible for providing any compliance certifications.
Under no circumstances we shall not be liable for any incidental damages sustained in connection with this product
Neither manufacture, nor distributor, nor retailer is responsible for water damage or flood caused due to use of this product.
Under no circumstances We shall not be liable for any and all fees, cost of installation/reinstallation/removal, subsequent
damage or transportation in case of the product defect
Customer Service Phone: 562-229-0088. (Monday - Friday 9 AM - 5 PM Pacific Time)
WOODBRIDGE
BJ400
® (IPC)
® (IRC)
® (UPC)
® (NPC)
2 PEOPLE ARE REQUIRED TO LIFT AND DURING
ENTIRE INSTALLATION OF THIS PRODUCT
Or Email: help@woodbridgebath.com
R
BJ500
(UL1795)
20230518 REV. 2
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Woodbridge BJ500
Summary of Contents for Woodbridge BJ500
- Page 1 INSTALLATION AND CARE GUIDE WOODBRIDGE AIR AND WHIRLPOOL HEATED BATHTUB BJ100 BJ400 BJ500 Certified to the following Codes & Standard: (UL1795) • UL 1795 Safety Standard for Hydromassage Bathtubs • ASME A112.19.7 / CSA B45.10) – Hydromassage Bathtub Systems • CSA B45.5/IAPMO Z124 – Plastic Plumbing Fixtures ®...
-
Page 2: Before You Begin
• All information is based on the latest product information available at the time of publication. WOODBRIDGE ® reserves the right to make changes in product characteristics, packaging, or availability at any time without notice. -
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS A. Tools Required B. Materials Required: • Adjustable pipe • Plumbers putty • wrench • Wall coverings, as necessary • Ruler • Silicone sealant • Level • Gypsum cement (optional) • Safety shoes • Construction adhesive • Safety glasses •... - Page 4 6) The unit must be connected only to a supply circuit that is protected by a Ground-Fault Circuit Interrupter (GFCI). Such a GFCI should be provided by the installer and should be tested on a routine basis. WOODBRIDGE WHIRLPOOL & AIR BATHTUB HEATED AIR MASSAGE TUB, HEATED WHIRLPOOL TUB...
- Page 5 Air Blower NEUTRAL GROUND THE LEAKAGE SWITCH Each Power cord Requires a Dedicated 120V 30AMP GFCI Breaker. WOODBRIDGE WHIRLPOOL & AIR BATHTUB HEATED AIR MASSAGE TUB, HEATED WHIRLPOOL TUB BJ500 Heater NEUTRAL GROUND Air Blower Hydromassage Pump 120V 30AMP Dedicated GFCI Breaker 5-10mm(02"to 0.4")
- Page 6 T O HE AT E R L I G H T G ND HE AT E R P UMP B L OWE R 2. Control Panel lcons BJ100 BJ500 display window Power Function Right/Up Left/Down OK button Chromo Theraphy light...
- Page 7 3. Operating Instruction on Control Panel (1) POWER ON/OFF: Press and hold the power button for 2 seconds to turn it on. Repeat the same operation to turn off the power. (2) CHROMO THERAPHY LIGHT ON/OFF: When power is on keep touching the Left and Right buttons until the cursor on the LCD is on the Chromo Therapy light position , press the OK...
- Page 8 4. Schematic diagram of the panel BJ400 Display Window Wave Massage ON/OFF Air Blower ON/OFF Bottom light ON/OFF Power ON/OFF switch Thermostate (1) Press the Power switch , to turn on the power. (2) Press the Bottom Light , switch to turn on and off the lights. (3) Press the Air Blower , to turn on and off...
-
Page 9: Operating Environment
5. Operating Environment (1) Power: AC 110V (2) Bottom Lights: AC 12V (3) Wave massage, Air Blower: AC 110V (4) Heater: AC 110V 6. Caution 1. Carefully read this user manual before you operate this unit and keep this user manual for future reference. 2. -
Page 10: Installer Information
NOTES NOTES INSTALLER INFORMATION INSTALLER INFORMATION DATE OF INSTALL: DATE OF INSTALL: INSTALLER’S NAME: INSTALLER’S NAME: PLUMBER: PLUMBER: CONTRACTOR: CONTRACTOR: LICENSE #: LICENSE #:... -
Page 11: Warranty
Improper care and use of abrasive cleaners and will void the warranty. During this limited warranty period if a malfunction occurs and after inspection it is determined that a defect developed during normal use, Woodbridge will as at... - Page 12 Abrasive sponges or cloth. Never use steel, wool, or wired brushes that will permanently scratch the Retain these installation instructions for future reference! Thank you for using WoodBridge products! Please don't hesitate to contact us if you have any questions or concerns.
