Mac Plus 48V Models – User and Installation Manual
DIP switch 2
0
1
DIP switch
3 4 5
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 1 1
DIP switch
6 7 8
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 0 1
1 1 0
* For a 24 V battery charger, multiply the voltages by two. For a 36 V charger, multiply by three. For
a 48 V charger, multiply by four.
DIP switch 9
0
1
DIP switch 10 is reserved for future use.
MasterBus communication
Smart on; no MasterBus communication in sleep mode (no load <2Ma)
MasterBus communication always on, provided there is enough input power.
In Sleep mode, no communication <1mA
In Standy, but still communicating <10mA
Battery type
Follow MasterBus setting, see chapter 9. Default setting: Flooded battery
Flooded
AGM
Gel
Lithium-Ion (MLI)
Constant voltage (13.25 V*)
Charger on conditions
MasterBus settings apply, see chapter 9.
Default setting: Remote switch input 'active
high' and input voltage greater than enable
voltage setpoint (12.50 V*)
Always on (Remote switch input not used)
Remote switch input 'active low'
Remote switch input 'active high'
Remote switch input 'active low' and input
voltage greater than enable voltage setpoint
(12.50 V*)
Remote switch input 'active high' and input
voltage greater than enable voltage setpoint
(12.50 V*)
Input voltage greater than enable voltage
setpoint (13.50 V*)
(Remote switch input not used)
High side behavior
High side is nominal 48 V (default)
High side is nominal 36 V
Typical use
Default setting.
Recommended setting for
vehicle with proper engine
run signal
When the battery charger
must be always active
Enable the battery charger
by external operating signal
Enable the battery charger
by external operating signal
Recommended setting for
vehicle with proper engine
run signal
Recommended setting for
vehicle with proper engine
run signal
Higher enable voltage
setpoint. Setting for vehicle
without engine run signal
