Installer manual
01945-01946
By-me Web server

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the by-me 01945 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vimar by-me 01945

Summary of Contents for Vimar by-me 01945

  • Page 1 Installer manual 01945-01946 By-me Web server...
  • Page 2 VIMAR SPA shall not be held liable for any damage caused by improper use of the aforementioned software, in particular for direct or indirect damage to persons, property, and/or animals due to economic loss that may occur as a result of the use of the software.

  • Page 3: Table Of Contents

    INDEX Prerequisites …………………………………………………………………………………………………………………………………………………………… 6 P.1 WEB BROWSER COMPATIBILITY …………………………………………………………………………………………………………………………… 6 P.2 OPERATING SYSTEM COMPATIBILITY ……………………………………………………………………………………………………………………… 6 P.3 BY-ME SYSTEM COMPATIBILITY ……………………………………………………………………………………………………………………………… 6 P.3.1 Minimum web software version Weather station KNX management server (Art. 01546) ………………………………………………………… 6 P.4 REQUIREMENTS FOR REMOTE ACCESS …………………………………………………………………………………………………………………… 6 P.5 COMPATIBILITY WITH THE BY-ALARM SYSTEM ……………………………………………………………………………………………………………...
  • Page 4 10.1 Add To Home ………………………………………………………………………………………………………………………………………………… 74 11. VOIP ………………………………………………………………………………………………………………………………………………………………… 75 11.1 Requirements ………………………………………………………………………………………………………………………………………………… 75 11.2 Configuration ………………………………………………………………………………………………………………………………………………… 75 12. ByWeb Tools by Vimar ………………………………………………………………………………………………………………………………………… 76 12.1 Introduction …………………………………………………………………………………………………………………………………………………… 76 12.2 Requirements ………………………………………………………………………………………………………………………………………………… 76 12.3 Installation …………………………………………………………………………………………………………………………………………………… 76 13. Integration of KNX devices in the By-me system ………………………………………………………………………………………………………… 77 13.1 Introduction ……………………………………………………………………………………………………………………………………………………...

  • Page 6: Prerequisites

    • Apple Safari (version 5.1 or above) • Google Chrome (version 14 or above) The Vimar By-Web Web Server is not compatible with browser Microsoft Internet Explorer. P.2 OPERATING SYSTEM COMPATIBILITY Full compatibility with various Linux distributions is not guaranteed.

  • Page 7: Installation

    Installation 1. Installation 1.1 Mounting and connections The Web Server is designed to be mounted on standard DIN rail. For the correct operation of the Web Server it is necessary to provide the follow- ing connections: • 12V DC power supply by connecting, through a special terminal provided, the power supply art. 01830. •...

  • Page 8: Reset Button

    Installation 1.1.2 RESET button The RESET button allows you to do the following: • Restore the network settings to default • Fully restore the factory settings: network settings and configuration. 1.1.2.1 Restoring the network settings to default This setting resets to factory defaults the following data on the network configuration of the web server. IP Address: 192.168.0.110 Gateway: 192.168.0.4 Netmask: 255.255.255.0...

  • Page 9: Connecting Via Network

    Installation 1.2 Connecting via Network The configuration and use of the Web Server include a link to your home or business. The network parameters of the Web Server will be set according to the configuration of the LAN which must host it. For the initial configuration of the Web Server, as well as in the absence of a network during installation, you must proceed as follows: •...
  • Page 10 Installation If the network configuration is correct, you will see the following welcome page: If the default network settings of the Web Server are not compatible with the configuration of the LAN which must host it, after accessing it as described above: 1.

  • Page 11: Access

    Installation 1.3 Access The Web Server has the following users preset by default: USER PASSWORD DESCRIPTION Administrator admin Home automation system administrator user. User dedicated to installing and configuring the Web Server. He has the rights to perform any Installer poweruser operation on the system, but cannot edit the rights of other users.

  • Page 12: General Settings

    General settings 2. General settings 2.1 Introduction The Web Server can be configured and customized through a special section of GENERAL SETTINGS, accessible by selecting "General Settings" from the popup menu displayed by pressing the button on bottom right of the page. The following page is displayed: The available menu on the left provides access to the following sections: SETUP General settings on the Web Server, and maintenance.

  • Page 13: Language

    General settings Within the specific configuration pages of the various aspects of the Web Server, it is always available at the bottom a button panel containing one or more of the following buttons: BACK Allows you to return to the previous page or the settings main menu SCROLL UP Allows you to scroll up the page, if it exceeds the available height SCROLL DOWN...

  • Page 14: Configuration

    IP addresses: DNS (Domain Name System) For example: IP Address: 213.178.196.136 DNS Name: www.vimar.com • Obviously, for access to an IP node, you must know the address or DNS name associated with it • Assigning an IP address to a host can be: - static: the address is assigned permanently - dynamic: the address assigned is not always the same.
  • Page 15 General settings Enter the following information in the appropriate fields: Address assigned to the Web Server, characterized by 4 numbers separated by periods. IP ADDRESS The address must be valid and unique within the LAN, otherwise unable to communicate with the Web Server. NETWORK MASK Enter the network mask used by your LAN;...
  • Page 16 General settings EXAMPLE OF ROUTER SETTING. The following example illustrates the steps for setting up the router (opening ports, setting the port forwarding, etc..) Obviously, the screens will be different depending on the router but the options and parameters used are typically always the same or very similar. •...
  • Page 17 General settings • LAN CONFIGURATION This image shows the router screen with the LAN settings ("internal" network interface of the router, the one of the user's local network); these set- tings depend on the structure of the LAN of the user and MUST NOT BE CHANGED!! In this example, the router has the (LAN) IP address: 192.168.0.1.
  • Page 18 General settings • DYNDNS This image shows the screen of the router on the DNS settings and the possible use of dynamic DNS services (e.g. DynDNS). NOTE: The values entered in DNS and Alternate DNS are purely indicative and not binding. The data for the management of DynDNS are indicative only and represent the data provided by the user when registering on DynDNS.

  • Page 19: Updates

    • PORT FORWARDING This image shows the screen of the router with the port forwarding settings, where a rule for remote access to Vimar web server has been created (the name of the "By-Web" rule is indicative and not binding): - address of the web server (here the default address is used): 192.168.0.110...

  • Page 20: Database

    General settings 2.5 Database This page allows you to operate on the Web Server database, which contains the configuration of the supervising project; you can do the following by selecting the corresponding item from the list: It allows you to export a backup of the database and save it on your PC in order to load it later on the same or EXPORT a different Web Server.
