Philco PLDI 138 CQTL Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Washing Machine
OWNER'S MANUAL
PLD 127 D QTL
PLDI 138 CQTL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLDI 138 CQTL and is the answer not in the manual?

Questions and answers

Related Manuals for Philco PLDI 138 CQTL

Summary of Contents for Philco PLDI 138 CQTL

  • Page 1 Washing Machine OWNER’S MANUAL PLD 127 D QTL PLDI 138 CQTL...
  • Page 2 Dear customer, Thank you for buying a PHILCO brand product. So that your appliance serves you well, please read all the instructions in this user’s manual. Copyright © 2020, Fast ČR, a. s. Revision 12/2020...

  • Page 3: Table Of Contents

    PART 3: OPERATIONS ............................12 Quick Start ......................................12 Before Each Washing ..................................13 Detergent Dispenser ..................................14 Control Panel (PLD 127 D QTL) ..............................15 Control Panel (PLDI 138 CQTL) ..............................16 Option ........................................17 Other Functions ....................................18 Programmes .......................................20 Washing Programmes Table .................................21 Washing Programmes Table .................................22 PART 4: MAINTENANCES ..........................23...

  • Page 4: Part 1: Safety Instructions

    PART 1: SAFETY INSTRUCTIONS p Safety Instructions For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. Explanation of the symbols: Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in death or serious injuries...
  • Page 5 • The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused. • Before any maintenance the device, unplug the appliance from the mains. • Always unplug the machine and turn off the water supply after use. The max. inlet water pressure, in pascals. The min. inlet water pressure, in pascals. • To ensure your safety, power plug must be inserted into an earthed three-pole socket. Check carefully and make sure that your socket is properly and reliably earthed. • Make sure that the water and electrical devices must be connected by a qualified technician in accordance with the manufacturer’s instructions and local safety regulations.
  • Page 6 • Remove all packages and transport bolts before using the appliance. Otherwise, serious damage may result. • Plug must be accessible after installation. Risk of explosion! • Do not wash or dry articles that have been cleaned in, washed in, soaked in, or dabbed with combustible or explosive substances (such as wax, oil, paint, gasoline, degreasers, dry-cleaning solvents, kerosene, etc.) This may result in fire or explosion. • Before hand thoroughly rinse items of washing by hand. Caution! Installing the product! • This washing machine is for indoor use only.
  • Page 7 Risk of damaging appliance! • Your product is only for home use and is only designed for the textiles suitable for machine washing. • Do not climb up and sit on top cover of the machine. • Do not lean against machine door. • Cautions during Handling Machine: 1. Transport bolts shall be reinstalled to the machine by a specialized person. 2. The accumulated water shall be drained out of the machine. 3. Handle the machine carefully. Never hold each protruded part on the machine while lifting. Machine door can not be used as the handle during the conveyance.
  • Page 8 • Please check whether the water inside the drum has been drained before opening its door. Please do not open the door if there is any water visible. • Be careful of burning when the product drains hot washing water. • Never refill the water by hand during washing. • After the program is completed, Please wait for two minutes to open the door. Packaging/Old appliance This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material...

  • Page 9: Part 2: Installation

    PART 2: INSTALLATION p Product Description Power supply cord Door Detergent dispenser Drum Control panel Drain hose Service filter Note! • The product line chart is for reference only, please refer to real product as standard. Accessories Transport hole Supply hose cold Drain hose Owner’s manual water support plug (optional) EN - 7 Copyright © 2020, Fast ČR, a. s. Revision 12/2020...

  • Page 10: Installation

    p Installation Installation area Warning! • Stability is important to prevent the product from wandering! • Make sure that the product should not stand on the power cord. Before installing the machine, the location characterized as follows shall be selected: 1. Rigid, dry, and level surface 2. Avoid direct sunlight 3. Sufficient ventilation 4. Room temperature is above 0°C 5.
  • Page 11 Levelling the washing machine Warning! • The lock nuts on all four feet must be screwed tightly against the housing. 1. Check if the legs are closely attached to the cabinet. If not, please turn them to their original positions tighten the nuts. 2. Loosen the lock nut turn the feet until it closely contacts with the floor. 3.
  • Page 12 2. Connection between screw tap and inlet hose. slide bushing Tap with threads and inlet hose Special tap for washing machine Connect the other end of inlet pipe to the inlet valve at the backside of product and fasten the pipe tightly clockwise.
  • Page 13 Trough Hose Retainer Max.100cm Min.60cm Warning! • When installing drain hose, fix it properly with a rope. • If drain hose is too long, do not force it into washing machine as it will cause abnormal noises. EN - 11 Copyright © 2020, Fast ČR, a. s. Revision 12/2020...

  • Page 14: Part 3: Operations

    PART 3: OPERATIONS p Quick Start Caution! • Before washing, please make sure it’s installed properly. • Before washing at first time, the washing machine shall be operated in one round of the whole procedures without clothes in as follows. 1. Before Washing Plug in Open tap Load Prewash Main wash Softener Add detergent Close drum Close machine door door Note! • Detergent need to be added in “case I“ after selecting pre-washing for machines with this function. • Make sure that the drum flaps are properly locked. • All metal hooks must be properly hooked inside the rear door flap.

  • Page 15: Before Each Washing

    2. Washing Select Select function or Start up Programme default Note! • If default is selected, step 2 can be skipped. 3. After Washing “End” on display. p Before Each Washing • The working condition of the washer should be(0-40) °C. If used under 0 °C, the inlet valve and draining system may be damaged. If the machine is placed under condition of 0 °C or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use.

  • Page 16: Detergent Dispenser

    p Detergent Dispenser Pre Wash detergent Main Wash detergent Softener Prewash Softener Main wash Pull out the dispenser Caution! • Detergent only need to be added in “case I “after selecting pre-washing for machines with this function. • Do not exceed the “MAX”level mark when filling in detergent,additives or softener. Programme Programme Cotton Spin Only    Synthetic Rinse & Spin     Wool    ...
  • Page 19 p Option Pre Wash Pre Wash The Prewash function can get an extra wash before main wash,it is suitable for washing the dust rises to surface of the clothes; You need to put detergent into the Case (I) when select it. Extra Rinse Extra Rinse The laundry will undergo extra rinse once after you select it. Delay Delay Set the Delay function: 1.

  • Page 20: Other Functions

    p Other Functions Temp. Temp. Press the button to regulate the temperature (Cold,20 °C, 40 °C, 60 °C, 90 °C). Spin Spin Press the button to change the speed. 1200: 0-600-800-1000-1200 1300: 0-600-800-1000-1300 Programme Default Speed (rpm) Programme Default Speed (rpm) 1200 1300 1200 1300 Cotton 1200 1300 Drum Clean Quick 15’ Baby Care Rapid 45’ Sportswear 1200 1300...
  • Page 21 Mute the buzzer Spin Choose the Programme Press the [Spin]button for 3sec., the buzzer is mute. To act the buzzer function, press the button again for 3 seconds. The setting will be kept until the next reset. Caution! • After Muting the buzzer function, the sounds will not be activated any more. My Cycle To memory the frequently used programme.

  • Page 22: Programmes

    p Programmes Programmes are available according to the laundry type. Programmes Cotton Hard-wearing textiles, heat-resistant textiles made of cotton or linen. Synthetic Wash synthetic articles, for example: shirts, coats, blending. While washing the knitting textiles, detergent quantity shall be reduced due to its loose string construction and easily forming bubbles. Baby Care Washing the baby’s clothes, it can make the baby’s wear cleaner and make the rinse performance better to protect the baby skin.

  • Page 23: Washing Programmes Table

    p Washing Programmes Table Model: PLD 127 D QTL Programme Load (kg) Temp. (°C) Default Time Cotton 2:40 Synthetic 2:20 1:37 Jeans 1:45 Sportswear 1:31 20 °C 1:01 Baby Care 1:42 Drum Clean 1:18 Spin Only 0:12 Rinse & Spin 0:20 Wool 1:07 Intensive 3:48 3:25 ECO 40-60...

  • Page 24: Washing Programmes Table

    p Washing Programmes Table Model: PLDI 138 CQTL Programme Load (kg) Temp. (°C) Default Time Cotton 3:39 Synthetic 3:17 1:37 Jeans 1:45 Sportswear 1:31 20 °C 1:01 Baby Care 1:42 Drum Clean 1:18 Spin Only 0:12 Rinse & Spin 0:20 Wool 1:07 Intensive 3:48 3:32 ECO 40-60...

  • Page 25: Part 4: Maintenances

    PART 4: MAINTENANCES p Cleaning And Care Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning The Cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. If there is any water overflow, use the wet cloth to wipe it off immediately. No sharp items are allowed. Note! • Formic acid and its diluted solvents or equivalent are forbidden, such as alcohol, solvents or chemical products, etc. Cleaning The Drum The rusts left inside the drum by the metal articles shall be removed immediately with chlorine-free detergents.

  • Page 26: Cleaning The Drain Pump Filter

    Note! • If the brush is not clean, you can pull out the filter washed separately; • Reconnect, turn on the tap. Clean The Detergent Dispenser 1. Press down the arrow location on softener cover inside the dispenser drawer. 2. Lift the clip up and take out softener cover and wash all grooves with water. 3. Restore the softener cover and push the drawer onto position. Pull out the dispenser Clean the dispenser Insert the dispenser...
  • Page 27 Remove extraneous matter Close the lower cover cap Caution! • Make sure that valve cap and emergency drain hose are reinstalled properly, cap plates should be inserted aligning to hole plates otherwise water may leak. • When the appliance is in use and depending on the programme selected there can be hot water in the pump. Never remove the pump cover during a wash cycle, always wait until the appliance has finished the cycle, and is empty. When replacing the cover, ensure it is securely re-tightened. EN - 25 Copyright © 2020, Fast ČR, a. s. Revision 12/2020...

  • Page 28: Trouble Shooting

    p Trouble Shooting The start of the appliance does not work or it stops during operation. First try to find a solution to the problem, If not, contact the service centre. Description Reason Solution Washing machine Restart after the door is closed. Door is not closed properly.

  • Page 29: Technical Specifications

    MAX. Current Standard Water Pressure 0.1 MPa - 1MPa Washing Dimension Rated Power Model Net Weight Capacity (W/D/H) mm PLD 127 D QTL 7.0kg 400/610/875 56kg 2100W PLDI 138 CQTL 8.0kg 400/610/875 56kg 2000W EN - 27 Copyright © 2020, Fast ČR, a. s. Revision 12/2020...

  • Page 30: Part 5: Product Information Sheet

    PART 5: PRODUCT INFORMATION SHEET Product Information Sheet COMMISSION DELEGATED REGULATION (EU) 2019/2016 Supplier's name or trademark: PHILCO Supplier's address: U Sanitasu 1621, Říčany 251 01, CZ Model identifier: PLD 127 D QTL General product parameters: Top loader washmachine Parameter Parameter Value Value Height Rated capacity...
  • Page 31 Minimum duration of the guarantee offered by the supplier: 24 months This product has been designed to release silver ions during the washing cycle Additional information: Weblink to the supplier’s website, where the information in point 9 of Annex II to Commission Regulation (EU) 2019/2023 is found: www.philco.cz * A (highest efficiency) to G (lowest efficiency) EN - 29 Copyright © 2020, Fast ČR, a. s. Revision 12/2020...
  • Page 32 Product Information Sheet COMMISSION DELEGATED REGULATION (EU) 2019/2016 Supplier's name or trademark: PHILCO Supplier's address: U Sanitasu 1621, Říčany 251 01, CZ Model identifier: PLDI 138 CQTL General product parameters: Top loader washmachine Parameter Parameter Value Value Height Rated capacity Dimensions in cm Width (kg)
  • Page 33 Minimum duration of the guarantee offered by the supplier: 24 months This product has been designed to release silver ions during the washing cycle Additional information: Weblink to the supplier’s website, where the information in point 9 of Annex II to Commission Regulation (EU) 2019/2023 is found: www.philco.cz * A (highest efficiency) to G (lowest efficiency) Note! • Programme setting for testing in accordance with applicable standard En60456. • When using the test programmes, wash the specified load using the maximum spin speed.
  • Page 34 INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS Dispose of packaging material at a public waste disposal site. DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES The meaning of the symbol on the product, its accessory or packaging indicates that this product shall not be treated as household waste.
  • Page 35 When contacting our authorized service, have the model designation, serial number and defect description available. To download documents, visit www.philco.cz. To report a defect and obtain additional service information, visit https://philco.cz/podpora-a-servis. Subject to change without notice.
