Anleitung zur Verfügung . Wenn Sie das Gerät verkaufen, gehört diese Anleitung zum Gerät und muss mitgeliefert werden . Zeichenerklärung Die folgenden Symbole werden in dieser Bedienungsanleitung, auf dem Rollei Pissarro DPF-880 oder auf der Verpackung verwendet . Mit diesem Symbol gekennzeichnete Produkte erfüllen alle maßgeblichen Gemeinschaftsvorschriften des Europäischen Wirtschaftsraums .
Sicherheitshinweise – Schließen Sie das Produkt nur dann an, wenn die Netzspannung des Eingangs oder Netzteils mit den Angaben auf dem Typenschild auf der Rückseite des Produkts übereinstimmt . – Verwenden Sie das Produkt nicht, wenn es sichtbar beschädigt ist oder wenn das Stromkabel defekt ist .
– Wenn Sie das Produkt an eine andere Person veräußern, geben Sie auch diese Be- dienungsanleitung an diese Person weiter . Hinweis: Das Gerät ist nur für die private und nicht zur gewerblichen Nutzung bestimmt . Lieferumfang – Rollei Pissarro DPF-880 – Fernbedienung – Batterie Typ CR2025 – Netzadapter mit Stromkabel – Standfuß...
Montage – Um den digitalen Bilderrahmen auf einen flachen Untergrund zu stellen, schrauben Sie den Standfuß in die Standfuß-Halterung . Einrichtung – Schließen Sie eine SD-/MMC-Speicherkarte oder ein USB-Speichermedium mit USB- A- oder Mini-USB-Anschluss an den digitalen Bilderrahmen an . –...
Hauptmenü „Foto“ – Hier haben Sie eine Galerieübersicht über die anzeigbaren Fotos . „Musik“ – Hier haben Sie eine Übersicht über die abspielbaren Musiktitel . „Video“ – Hier haben Sie eine Übersicht über die abspielbaren Videos . „Kalender“ – Hier haben Sie eine Übersicht über den aktuellen Kalender . „Browser“...
10 mit bis zu 32 GB oder externer Speicher mit USB- A-/Mini-USB-Anschluss Stromversorgung Pissarro DPF-880: Eingang DC 5,0 V / 2,0 A Netzadapter für Pissarro DPF-880: Eingang 100 – 240 V / 50 – 60 Hz / 0,3 A, Ausgang AC 5,0 V / 2,0 A / 10,0 W...
Page 11
Technische Daten Anschluss Strom-Anschluss, USB-A-Anschluss, Mini-USB- Anschluss, SD-/MMC-Speicherkarten-Slot, Klinken- Anschluss, Standfuß-Anschluss Betriebstemperatur 0 – 40 °C Montage Horizontal mit Standfuß Maße 20,3 x 13,8 x 2,4 cm Gewicht 252 g Lieferumfang Digitaler Bilderrahmen, Fernbedienung, Batterie Typ CR2025, Netzadapter mit Stromkabel, Standfuß, Bedienungsanleitung Änderungen von Design und technischen Daten bleiben vorbehalten und bedürfen keiner Ankündigung .
Entsorgung Entsorgen Sie die Verpackung sortenrein. Nutzen Sie dafür die örtlichen Möglichkeiten zum Sammeln von Papier, Pappe und leichten Verpackungen (anwendbar in der Europäischen Union und anderen europäischen Staaten mit Systemen zur getrennten Sammlung von Wertstoffen) . Geräte, die mit diesem Symbol gekennzeichnet sind, dürfen nicht mit dem Hausmüll entsorgt werden! Sie sind gesetzlich dazu verpflichtet, Altgeräte getrennt vom Hausmüll zu entsorgen .
Konformität Hiermit erklärt die Rollei GmbH & Co . KG, dass der Funkanlagentyp „Rollei Pissarro DPF-880“ den folgenden Richtlinien entspricht: 2014/30/EU EMV-Richtlinie 2014/35/EU Niederspannungsrichtlinie 2009/125/EG ERP-Richtlinie 2011/65/EU RoHs-Richtlinie Der vollständige Text der EU-Konformitätserklärung ist unter der folgenden Internetadresse verfügbar: www .rollei .de/egk/pissarrodpf-880 Rollei GmbH &...
. Explanation of Symbols The following symbols are used in these operating instructions, on the Rollei Pissarro DPF-880 or on the packaging . Products marked with this symbol comply with all relevant community regu- lations of the European Economic Area .
Safety Instructions – Only connect the product if the mains voltage of the input or power supply matches the specifications on the type plate on the back of the product . – Do not use the product if it is visibly damaged or if the power cable is defective . –...
. Note: The product is intended for private use only and not for commercial use . What’s in the Box – Rollei Pissarro DPF-880 – Remote control – Battery Type CR2025 – Power adapter with power cable –...
Product Overview Display Speaker Power on / off button SD/MMC memory card slot Jack connection USB-A connection Mini-USB connection Power connection Arrow buttons Menu button Selection button Holder stand connection 9 10 11...
Mounting – To place the digital photo frame on a flat surface, screw the holder stand into the holder stand connection . Setup – Connect an SD/MMC memory card or USB storage device with USB-A or mini-USB connection to the digital photo frame . –...
Main Menu ”Photo“ – Here you have a gallery overview of the displayable photos . ”Music“ – Here you have an overview of the playable music tracks . ”Video“ – Here you have an overview of the playable videos . ”Calendar“...
32 GB or external memory with USB-A / mini-USB connection Power supply Pissarro DPF-880: Input DC 5.0 V / 2.0 A Power supply for Pissarro DPF-880: Input 100 – 240 V / 50 – 60 Hz / 0.3 A, output AC 5.0 V / 2.0 A / 10.0 W...
Page 21
Technical Data Connection Power connection, USB-A connection, mini-USB con- nection, SD/MMC memory card slot, jack connection, stand connection Operating temperature 0 – 40 °C Mounting Horizontally with holder stand Dimensions 20.3 x 13.8 x 2.4 cm Weight 252 g What’s in the box Digital photo frame, remote control, battery type CR2025, power adapter with power cable, stand, user manual...
Disposal Dispose of the packaging according to its type. Use the local possi- bilities for collecting paper, cardboard and other materials (applicable in the European Union and other European countries with systems for the separate collection of recyclable materials) . Devices that are marked with this symbol must not be disposed of with household waste! You are legally obliged to dispose of old devices separately from to dispose of household waste .
Conformity Rollei GmbH & Co . KG herewith declares that the radio system type “Rollei Pissarro DPF-880“ complies with the following directives: 2014/30/EU EMC Directive 2014/35/EU LVD Directive 2009/125/EG EuP Directive 2011/65/EC RoHs-Directive The full text of the EU declaration of conformity is available at the following Internet address: www .rollei .com/egk/pissarrodpf-880...
Page 24
Rollei GmbH & Co. KG In de Tarpen 42 D-22848 Norder stedt Service Hotline: +49 40 270750277 /rollei.foto.de @rollei_de Item No.: 30281 www.rollei.com...
