Figure 1-7

WARNING

Chapter 1

removing the workstation cover

1. Switch off the display and computer. Disconnect all power cables and

any LAN or telecommunications cables.

2. Unlock the cover lock at the back of the workstation, if required. See

Figure 1-1.

3. Pull outward on the cover latch, grasp the edges of the cover and lift

the cover upward to remove it. See Figure 1-7.

Removing the Cover

Cover Latch

Workstation

Cover

Parts inside the computer may be hot, wait for them to cool

before touching them.

setting up and using your workstation

removing and replacing the cover and front bezel
