Cornelius P/N 620043511 Installation Instructions

INSTALLATION INSTRUCTIONS

F ED/DF 150-8 "K" S
OR
These "K" style kits apply to the following ice makers:
Manitowoc Q320 and Q420
Item No. Part No.
620043511
1
620043512
2 620046012
3 22127
4 70217
5 50904
6 90221
7 620919518
8 620701902
9 620701901
10 620037007
11 620701903
!
WARNING:
Disconnect power to the unit before installing the adaptor following all lockout/tag out procedures established by the
user. Verify that all the power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All ice baffle plates and bin stats, if included or recommended in this kit, must be installed as directed in this manual or
the equipment manufacturer's instructions.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All of the attachment screws and plates must be installed as directed in this manual.
Failure to comply could result in serious injury, death or damage to the equipment.
Perform the following procedure to install the adapter kit.
1. Unpack and inspect the kit.
2. Insert baffle assembly into the adapter lid.
3. Place (2) sealing washers (item 9) over studs and (2) flat washers (item 11), then fasten in place with (2) plastic
acorn nuts (item 8).
4. Set ice maker lid on the top of the dispenser.
Release Date: November 12, 2010
© 2000-2010, IMI Cornelius Inc.
ED/DF 150-8 "K" Style Lid Kit Installation Instructions
L K , P/N 629087910 AND 629087911
TYLE ID ITS
Table 1
Ice Maker
Table 2
Table 1. Loose–Shipped Parts
Cover, Gray (629087911)
Cover, Black – (629087910)
Lid Assembly
Bracket
#8 Screw
RTV
Label
Installation Instruction
Acorn Nut, 8-32 Nylon
Sealing Washer
Ice Baffle ED2XX
#8 Nylon Washer
www.cornelius.com
- 1 -
Name
Publication Number: 620919518
Width
22"
Qty.
1
1
1
2
6
1
1
1
2
2
1
2
Revision: B
