Cornelius Universal 750 Pre-Mix Installation Instructions Manual

COPPER EVAPORATOR COIL KIT (P/N 185216000)
UNIVERSAL 750 PRE-MIX DISPENSER
IMPORTANT: Only qualified Personnel should install this Kit.

INTRODUCTION

The purpose of this kit is to replace the original expanded aluminum evaporator, which also doubles as the wa-
ter bath tank, with a new copper tube style evaporator. The old aluminum evaporator remains in place as the
water bath tank only.
A new anode and refrigeration system dual inlet strainer/dryer are also included with the kit and must be instal-
led.
Retain these instructions as part of your equipment manual.

UNPACKING THE KIT

Unpack and inspect the kit. Make sure Loose-Shipped Parts are present and in good condition (see Figure 1).
Item
No. Part No.
1 319238088 Suction Line Ass'y
2 186843000 Anode
3 187969000 Sheet Metal Screw, Phil Pan Hd, Type ''A'' Alum; No. 10 by 1/2-in.
4 185215000 Copper Evaporator Coil
5 319225000 Coil Spacer
6 320389000 Thread Rolling Screw, Phil Pan Hd, No. 6-32 by 1/4-in.
7 960050 Rubatex Insulation, 6-ft. long
8 2601 Strainer Dryer, Dual Inlet
9 189159001 Instructions

REQUIRED SUPPLIES AND EQUIPMENT

Supplies required are as follows:
Brazing alloy ''Phos-Copper'', ''Silfos'' or equivalent is required for copper-to-copper connections. These alloys
contain about 15% silver.
Brazing alloy. ''Easy-flow'' or equivalent is required for copper-to-steel connections. This alloy contains about
50% silver.
