Cornelius P/N 620024406 Installation Instructions

INSTALLATION INSTRUCTIONS

These "K" style kits apply to the following ice makers and are for use with DF/ED 200/250 dispensers:
Manitowoc Q200/450/600/800
Item No. Part No.
1 620024406
2 22127
3 50904
4 620701601
5 620910101
!
WARNING:
Disconnect power to the unit before installing the adaptor following all lockout/tag out procedures established by the
user. Verify that all the power is off to the unit before performing any work.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All ice baffle plates and bin stats, if included or recommended in this kit, must be installed as directed in this manual or
the equipment manufacturer's instructions.
Failure to comply could result in serious injury, death or damage to the equipment.
!
WARNING:
All of the attachment screws and plates must be installed as directed in this manual.
Failure to comply could result in serious injury, death or damage to the equipment.
1. Set Ice maker lid on the top of the dispenser and position it flush with the back and sides of the dispenser.
2. Using the slotted holes in the lid as a template, drill four (4) 0.147" diameter holes at the bottom of the slots (see
detail A). Use extreme care not to drill into the hopper. Fasten the lid to the dispenser with four (4) #10 sheet
metal screws, two on each side.
3. Seal the ice maker to the top of the dispenser as follows:
A. Apply beads of RTV around the opening in the lid and inside the perimeter of the ice maker outline so
that the ice maker will set on the RTV.
B. Set the ice maker onto the lid and position it as required, front flush with rear of lid.
C. Wipe away any excess RTV.
4. Install Mounting Brackets (Item 2) by drilling 0.147" diameter holes into the adapter lid and ice maker cabinet
using brackets as templates. Use extreme caution not to drill into any ice maker components (condenser, tubing,
etc.). Secure the brackets using the screws provided.
5. Follow the ice maker manufacturers instruction to complete the installation of the ice maker including the bin ther-
mostat if so equipped or required.
Release Date: November 8, 2010
© 1998-2010, IMI Cornelius Inc.
"K" S L K
TYLE ID
R
EAR
Table 1. Applicable Models
Ice Maker
Table 2. Loose Shipped Parts
Lid Assembly, "K" Style
Bracket, Mounting
RTV, Clear, 732, 3 oz. Tube
#10 Sheet Metal Screw
Installation Instruction
www.cornelius.com
"K" Style Lid Kit Installation Instructions
, P/N 629083501
IT
M
OUNT
Name
- 1 -
Size
30"
Qty.
1
2
1
12
1
Revision: B
Publication Number: 620910101
