- Page 1 User MANUAL 802.11 b/g/n, 1T1R 2.4GHz WLAN Module Model Name: WN4649L Brand: LITE-ON Page 1/9 2020/6/15...
-
Page 2: Table Of Contents
ONTENT WARNING STATEMENTS ......................3 PRODUCT FEATURES ........................5 PRODUCT SPECIFICATIONS......................5 ............................5 HIPSET .......................5 UNCTIONAL PECIFICATIONS PIN DEFINIITON ..........................7 MECHANICAL ..........................8 MAC LABEL ............................8 ENVIRONMENTAL ..........................9 ............................9 PERATING ..............................9 TORAGE Page 2/9 2020/6/15... -
Page 3: Warning Statements
WARNING STATEMENTS FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 4 20 cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied. Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment.
-
Page 5: Product Features
document. 5. The OEM integrator will ensure the Module is programmed in the factory with compliant transmit power not exceeding the levels specified in this document. LITE-ON requests that the OEM integrator acknowledge its receipt of this document and the above instructions. You may contact LITE-ON with any questions concerning this document or the responsibilities of the OEM integrator RODUCT... - Page 6 11: (Ch. 1-11) – United States 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan 802.11bg Frequency Range 2.412 ~ 2.462 GHz 802.11b: 17dBm Transmit Output Power – 1x1 802.11g: (Tolerance: +-1.5dBm) 15dBm 802.11n: 14dBm 802.11b: (IEEE Standard <-76dBm) typical: -88dBM(1M) 802.11g: (IEEE Standard <-65dBm) Receive Sensitivity...
-
Page 7: Pin Definiiton
EFINIITON J4 : Header 1*9 (Pitch=1.27mm) Name Type Details GPIOA_4 GPIOA_16 I/O GPIOA_15 I/O CHIP_EN GPIOA_1 GPIOA_0 J1 : Connector (SM06B-GHS-TB(LF)(SN)) Name Type Details 0V : Resets WLAN module 5V : Release reset WLAN module UART_RXD (0V-5V / 19.2kbps) UART_TXD (0V-5V / 19.2kbps) WALN Power supply Page 7/9 2020/6/15... -
Page 8: Mechanical
ECHANICAL MAC Label Page 8/9 2020/6/15... -
Page 9: Environmental
NVIRONMENTAL Operating Operating Temperature: -20 to 85 C Relevant Humidity: 5-90% (non-condensing) Storage Temperature: -40 to 85 C Relevant Humidity: 5-95% (non-condensing) Page 9/9 2020/6/15...
