- Page 1 User Manual 802.11a/b/g/n/ac 2Tx2R + BT V4.2 LE USB Combo Module WCBN4508M User Manual Page 1/10...
-
Page 2: Table Of Contents
ONTENT PRODUCT FEATURES ........................6 BT F EATURE ................................... EATURE ..................................OMMON EATURE ................................PRODUCT SPECIFICATIONS ......................7 HIPSET ..................................UNCTIONAL PECIFICATIONS ............................RECOMMENDED OPERATION CONDITIONS ................9 PIN ASSIGNMENT ..........................9 EEPROM INFORMATION ......................10 BT ..................................10 I ...................................... ENVIRONMENTAL ........................ - Page 3 FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 The final end product must be labeled in a visible area with the following " Contains TX FCC ID: PPQ- WCBN4508M". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be available on the label: This device complies with Part 15 of FCC rules.
- Page 5 The OEM integrator will ensure the antenna placement inside the host system will maintain the required spacing to end user for RF Exposure compliance, as specified in this document. If other radios are integrated inside the host with the LITE-ON Module, the OEM integrator will contact its test lab, TCB or LITE-ON to determine if additional FCC compliance evaluation is required to meet FCC collocation rules.
-
Page 6: Product Features
RODUCT EATURES BT F EATURE Bluetooth V4.2 LE system Backwards compatible with BT version of 1.1, 1.2, 2.0, 2.1, 3.0+HS and 4.0 Support Dual-mode Bluetooth BT using USB interface BT transmission speed including 1M (GFSK), 2M (π/4-DQPSK) and 3Mbps (8DPSK) EDR and up to 54Mbps (Physical Rate) High Speed operations ... -
Page 7: Product Specifications
RODUCT PECIFICATIONS HIPSET Marvell 88w8997 UNCTIONAL PECIFICATIONS BT Function Bluetooth V4.2 LE Standard Bus Interface Data Rate 1 Mbps, 2Mbps and Up to 3Mbps GFSK, π/4-DQPSK and 8-DPSK Modulation Scheme Frequency Range 2.402~2.480 GHz Receiver Sensitivity < 0.1% BER at -80dBm Wi-Fi Function IEEE802.11a;... - Page 8 Network Architecture Infrastructure mode 2.4GHz 11: (Ch. 1-11) – United States 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan Operation Channel 5GHz 12: United States 19: Europe 8: Japan 802.11bg 2.412 ~ 2.462 GHz Frequency Range 802.11a 5.15 ~ 5.825 GHz 802.11a: -86 dBm@6Mbps -70 dBm@54Mbps...
-
Page 9: Recommended Operation Conditions
Common Function Operating Voltage 5 V ±10% I/O supply voltage OS Supported Linux Based PCB antenna Antenna Type ECOMMENDED PERATION ONDITIONS For Module Symbol Rating Units 5V Supply Voltage For IC Symbol Parameter Units AVDD33 3.3V analog power supply 2.97 3.63 AVDD18 1.8V analog power supply... -
Page 10: Eeprom Information
EEPROM I NFORMATION Vendor ID 0x1286 0x2052 Product ID FCC SKU 2.4G: CH1-11 Region Code 5G: U-NII-1, U-NII-2A, U-NII-2C, U-NII-3 0x1286 Vendor ID Device ID 0x204E NVIRONMENTAL PERATING Operating Temperature: 0 to 70 °C (32 to 158°F) Relative Humidity: 5-90% (non-condensing) TORAGE Temperature: -40 to 80 °C (-40 to 176 °F) Relative Humidity: 5-95% (non-condensing)
