PRODUCT SPECIFICATION
802.11n, 2.4G 1T1R Wireless LAN USB Module
WN4629R
MediaTek MT7601U
Version 1.0
User Manual
* This document contains confidential proprietary information and is property of LTC. The contents of
this document should not be disclosed to unauthorized persons without the written consent of LTC
Page 1/10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LiteOn WN4629R
Summary of Contents for LiteOn WN4629R
- Page 1 PRODUCT SPECIFICATION 802.11n, 2.4G 1T1R Wireless LAN USB Module WN4629R MediaTek MT7601U Version 1.0 User Manual * This document contains confidential proprietary information and is property of LTC. The contents of this document should not be disclosed to unauthorized persons without the written consent of LTC...
- Page 2 PRODUCT SPECIFICATION 802.11n, 2.4G 1T1R Wireless LAN USB Module WN4629R MediaTek MT7601U Version 1.0 Networking B.U. Lite-on Technology Corporation 4F, No. 90, Chien I Rd., Chung Ho, New Taipei City 235, Taiwan, R.O.C. Phone: +886-2-2222-6181 Fax: +886-2-2221-5288 Contact: Product Marketing Mr.
-
Page 3: Table Of Contents
ONTENT FCC WARING STATEMENT ......................4 PRODUCT FEATURES ........................5 PRODUCT SPECIFICATIONS ......................6 ............................6 HIPSET ....................... 6 UNCTIONAL PECIFICATIONS PIN ASSIGMENT ..........................8 RESET TIMING SPEC ........................8 USB CONNECTOR SPEC ......................... 9 MECHANICAL ..........................10 EEPROM INFORMATION ......................10 ENVIRONMENTAL ........................ -
Page 4: Fcc Waring Statement
FCC W ARING TATEMENT FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 5: Product Features
20cm may be maintained between the antenna and users. The final end product must be labeled in a visible area with the following: "Contains FCC ID: PPQ-WN4629R ” Information for the OEMs and Integrators The following statement must be included with all versions of this document supplied to an OEM or integrator, but should not be distributed to the end user. -
Page 6: Product Specifications
RODUCT PECIFICATIONS HIPSET MAC/ Baseband/ RF: MediaTek MT701U UNCTIONAL PECIFICATIONS Wi-Fi Function IEEE802.11b; IEEE 802.11g; IEEE 802.11n Standard USB2.0 Bus Interface 802.11b: 11, 5.5, 2, 1 Mbps 802.11g: Data Rate 54, 48, 36, 24, 18, 12, 9, 6 Mbps 802.11n: MCS 0 to 7 for HT20MHz MCS 0 to 7 for HT40MHz Media Access Control... - Page 7 WPA, WPA2, WPS, WEP 64b&128bit, IEEE 802.1X, Security IEEE 802.11i Operating Voltage 3.3V ± 5% I/O supply voltage OS Supported Microsoft Windows Win7/Win8; Linux based TX Mode: TBD mA RX Mode: TBD mA Power Consumption Idle Mode: TBD mA Sleep Mode: TBD mA PIFA Antenna Antenna Type...
-
Page 8: Pin Assigment
SSIGMENT Pin. Pin Define Status +3.3V USB_D- USB_D+ Reset# SPEC ESET IMING Page 8/10... -
Page 9: Usb Connector Spec
USB C SPEC ONNECTOR Page 9/10... -
Page 10: Mechanical
ECHANICAL EEPROM I NFORMATION Worldwide Channel 1~11 Active Scan Channel 12~14 Passive Scan Reg Domain Offset 0x38 for 5G: 0xFF Offset 0x39 for 2.4G: 0xFF 0x148F Vendor ID 0x7601 Product ID NVIRONMENTAL Operating Operating Temperature: 0 to 60 C (32 to 140 F) Relative Humidity: 5-90% (non-condensing) Storage Temperature: -20 to 70 C (-4 to 158 F)
