- Page 1 PRODUCT SPECIFICATION Wi-Fi (11a/b/g/n/ac 2Tx2R)+BT (V4.2LE) SDIO Combo Module WCBN3514A User Manual Page 1/19...
-
Page 2: Table Of Contents
ONTENT DESCRIPTION ........................... 9 PRODUCT FEATURES ........................9 PRODUCT SPECIFICATIONS ...................... 10 ............................. 10 HIPSET ......................10 UNCTIONAL PECIFICATIONS RECOMMENDED OPERATION CONDITIONS ................ 13 PIN ASSIGMENT ..........................13 MECHANICAL ..........................15 FOOTPRINT ............................. 15 MODULE PINOUT .......................... 16 BLOCK DIAGRAM ..................錯誤! 尚未定義書籤。 MHF4 CONNECTOR SPEC ...................... - Page 3 FCC Statement: Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 The final end product must be labeled in a visible area with the following " Contains TX FCC ID: PPQ- WCBN3514A ". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be available on the label: This device complies with Part 15 of FCC rules.
- Page 5 maintain the required spacing to end user for RF Exposure compliance, as specified in this document. 3. If other radios are integrated inside the host with the LITE-ON Module, the OEM integrator will contact its test lab, TCB or LITE-ON to determine if additional FCC compliance evaluation is required to meet FCC collocation rules.
- Page 6 potential for harmful interference to co-channel mobile satellite systems. les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux. The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with the e.i.r.p.
- Page 7 (2) this device must accept any interference received, including interference that may cause undesired operation. LABEL OF THE END PRODUCT: The final end product must be labeled in a visible area with the following " Contains TX IC: 4491A-WCBN3514A ". Antenna Information Group Project...
- Page 8 Group Project Brand Antenn Connecto a Type Shenzhen N12-4142-R0A (Sparro South Star N12-4143-R0A PIFA Technolog inch) N14-0595-R0A y Co., LTD EAA65404602 INPAQ EAA65404601 PIFA EAA65404701 N2420SDAR-T6-G120U4LI ( Rev B ) N2420DCB3-T10-G200U4L Airgain PIFA Mini i-Pex ( Rev B ) N2410MST-T-G85U4LI ( Rev G ) Gain (dBi) Group.
-
Page 9: Description
ESCRIPTION QCA9379-3 is a single-die wireless local area network(WLAN) and Bluetooth(BT) combo solution to support 2x2 MIMO with two spatial streams IEEE802.11 a/b/g/n/ac WLAN standards and BT 4.2+HS enabling seamless integration of WLAN/BT and Low Energy technology. RODUCT EATURES Bluetooth V4.2 LE system Backwards compatible with BT version of 1.1, 1.2, 2.0, 2.1, 3.0+HS and V4.0LE ... -
Page 10: Product Specifications
RODUCT PECIFICATIONS HIPSET Qualcomm Atheros QCA9379-3 UNCTIONAL PECIFICATIONS BT Function Bluetooth V4.2LE Standard UART Bus Interface 1 Mbps, 2Mbps and Up to 3.2Mbps Data Rate GFSK, π/4-DQPSK and 8-DPSK Modulation Scheme 2.402~2.480 GHz Frequency Range Transmit Output ≤ ≤ Output Power +10dBm;... - Page 11 Network Architecture Infrastructure mode 2.4GHz 11: (Ch. 1-11) – United States 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan Operation Channel 5GHz 21: USA 19: EU 8: Japan 802.11bg 2.400 ~ 2.4835 GHz Frequency Range 802.11a 5.15 ~ 5.85 GHz Transmit Output Power - single chain @ant;...
- Page 12 (dBm) MCS5 MCS6 MCS7 MCS8 MCS9 802.11ac MCS0 MCS1 MCS2 MCS3 MCS4 VHT80 13.5 13.5 13.5 Tgtpwr (dBm) MCS5 MCS6 MCS7 MCS8 MCS9 Receiver Sensitivity Frequency Rate Condition 1x1(1SS) 2x2(1SS) Band (dBm) (dBm) 11b-1M PER < 8% 11b-11M PER < 8% 11g-6M PER <...
-
Page 13: Recommended Operation Conditions
ECOMMENDED PERATION ONDITIONS Symbol Parameter Units VDD33 3.3V Supply Voltage 3.14 3.46 VDD33_SWREG_VIN Supply Voltage for internal PMU 3.14 3.46 VDDIO_GPIO0 1.71 1.89 VDDIO_GPIO1 Voltage supply for all IO signals VDDIO_GPIO2 3.14 3.46 VDDIO_AO_IN 1.1V supply from internal 1.1V AVDD11 1.05 SSIGMENT * The following signal type is defined:... - Page 14 SDOI_DATA2 SDIO Data Line2 for WLAN SDOI_DATA1 SDIO Data Line1 for WLAN SDOI_DATA0 SDIO Data Line0 for WLAN Analog 1.1V output AVDD11 (Host no need to connect) SDIO_CMD SDIO Command for WLAN WLAN_EN# Active low to reset WLAN BT_EN# Active low to reset BT Can be 1.8V or 3.3V to support always on circuit of QCA9379-3.
-
Page 15: Mechanical
ECHANICAL OOTPRINT Page 15/19... -
Page 16: Module Pinout
ODULE INOUT Page 16/19... -
Page 17: Mhf4 Connector Spec
MHF4 C SPEC ONNECTOR Page 17/19... -
Page 18: Power-Up Sequence Timing
OWER EQUENCE IMING Page 18/19... -
Page 19: Eeprom Information
EEPROM I NFORMATION Vendor ID 0x0271 0x0801 Product ID Reg Domain Vendor ID 0x0271 Product ID 0x0801 NVIRONMENTAL PERATING Operating Temperature: 0 to 50 C (32 to 122 F) Relative Humidity: 5-90% (non-condensing) TORAGE Temperature: -40 to 80 C (-40 to 176 F) Relative Humidity: 5-95% (non-condensing) Page 19/19...
