- Page 1 USER’S MANUAL 802.11a/b/g/n 2Tx2R + BT5.0 USB WLAN Module WCBN3509R(38BT) Page 1/13...
-
Page 2: Product Features
RODUCT EATURES BT F EATURE Bluetooth V5.0 system Backwards compatible with BT version of 1.1, 1.2, 2.0, 2.1, 3.0+HS and 4.0LE Bluetooth Class I transmission power Support for Simple Pairing (SP) and Enhanced Inquiry Response (EIR) function ... -
Page 3: Specifications
RODUCT PECIFICATIONS HIPSET MediaTek MT7638BU UNCTIONAL PECIFICATIONS BT Function Bluetooth V5.0LE Standard USB2.0 Bus Interface 1 Mbps, 2Mbps and Up to 3Mbps Data Rate GFSK, π/4-DQPSK and 8-DPSK Modulation Scheme 2.402~2.480 GHz Frequency Range Output Power +10dBm; Class I Device ≤... - Page 4 21: USA 19: EU 8: Japan 802.11bg 2.400 ~ 2.4835 GHz Frequency Range 802.11a 5.15 ~ 5.85 GHz CCK < 35% OFDM < -25dB MCS0(HT20/40MHz) < -5dB MCS7(HT20/40MHz) < -28dB MCS0(VHT20/40/80MHz) < -5dB MCS7(VHT 20/40/80MHz) < -27dB MCS8(VHT 20/40/80MHz) < -30dB MCS9(VHT 20/40/80MHz) <...
- Page 5 802.11n MCS0 MCS1 MCS2 MCS3 MCS4 HT40 Tgtpwr (dBm) MCS5 MCS6 MCS7 MCS8 MCS9 Receiver Sensitivity Frequency Rate Condition Typical (1SS) Band (dBm) 11b-1M PER < 8% 11b-11M PER < 8% 11g-6M PER < 10% 11g-54M PER < 10% 2.4G 11n-HT20MCS0 PER <...
-
Page 6: Recommended Operation Conditions
ECOMMENDED PERATION ONDITIONS Symbol Rating Units VDD33 3.3V Supply Voltage 2.97 3.63 VDD12 1.2V Supply Voltage 1.14 1.26 VDD15 1.5V Supply Voltage 1.425 1.575 DC C HARACTERISTICS Symbol Parameter Units Input Low Voltage -0.28 Input High Voltage 3.63 Output Low Voltage -0.28 Output High Voltage 3.63... -
Page 7: Pin Assigment
SSIGMENT Pin. Pin Define Description Status +3.3V 3.3V source +3.3V 3.3V source USB_D- USB Data- USB_D+ USB Data+ Ground RESET# System reset MT7668BU, low active WoWLAN# Wake up system via wifi, low active Ground WoBT Wake up system via BT, low active Ground Ground Ground... - Page 8 ECHANICAL Page 8/13...
- Page 9 EEPROM I NFORMATION World Wide 2.4G/5G Read from registry; Control by driver Reg Domain Offset 0x38 for 5G: 0xFF Offset 0x39 for 2.4G: 0xFF 0x0E8D Vendor ID 0x7638 Device ID NVIRONMENTAL PERATING Ambient Operating Temperature: 0 to 70 C (32 to 158 F) Ambient Relative Humidity: 5-90% (non-condensing) TORAGE Ambient Temperature: -40 to 80 C (-40 to 176 F)
- Page 10 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 11 This module is only FCC authorized for the specific rule parts 15.247, 15.407 listed on the grant, and the host product manufacturer is responsible for compliance to any other FCC rules that apply to the host product as being Part 15 Subpart B compliant. This module has been approved to operate with the antenna types listed below, with the maximum permissible gain indicated.
- Page 12 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 13 the device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de satellites mobiles utilisant les mêmes canaux;...
