- Page 1 WCBN814A User Manual PRODUCT SPECIFICATION Wi-Fi 6E BT 5.2 M.2 2230 Module WCBN814A User Manual Smart Application Solutions LITE-ON Technology Corporation 11F, 392, Ruey Kuang Road, Neihu, Taipei 11492, Taiwan, R.O.C. Page 1/21...
- Page 2 WCBN814A User Manual Federal Communication Commission Interference Statement FCC Statement: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 3: Important Note
WCBN814A User Manual IMPORTANT NOTE: FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. -
Page 4: Label Of The End Product
The final end product must be labeled in a visible area with the following " Contains FCC ID: PPQ- WCBN814A ". If the size of the end product is larger than 8x10cm, then the following FCC part 15.19 statement has to also be available on the label: This device complies with Part 15 of FCC rules. - Page 5 WCBN814A User Manual following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
- Page 6 WCBN814A User Manual 5470-5725 MHz doit se conformer à la limite de p.i.r.e. Users should also be advised that high power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE•LAN devices.
- Page 7 WCBN814A User Manual IMPORTANT NOTE: IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.
- Page 8 WCBN814A User Manual 1.1 P RODUCT EATURES Module feature includes: Bluetooth V5.2 system Backwards compatible with BT version of 1.1, 1.2, 2.0, 2.1, 3.0+HS, 4.0LE and 5.0 Support Bluetooth Class I and Class II power level transmission power without requiring an external PA ...
-
Page 9: Product Specifications
WCBN814A User Manual 1.2 P RODUCT PECIFICATIONS UNCTIONAL PECIFICATIONS BT Function Standard Bluetooth V5.2 Bus Interface UART Data Rate 1 Mbps, 2Mbps and Up to 3Mbps GFSK, π/4-DQPSK and 8-DPSK Modulation Scheme 2.402~2.480 GHz Frequency Range BR/EDR: 0~78 Operating Channel BLE: 0~39 ≤... - Page 10 WCBN814A User Manual 802.11n: 64QAM, 16QAM, QPSK, BPSK 802.11ac: 256QAM, 64QAM, 16QAM, QPSK, BPSK 802.11ax: 1024QAM, 256QAM, 64QAM, 16QAM, QPSK, BPSK Network Architecture Infrastructure mode 2.4GHz 13: (Ch. 1-13) – United States 13: (Ch. 1-13) – Europe 14: (Ch. 1-14) – Japan...
- Page 11 WCBN814A User Manual Tgtpwr 16.5 (dBm) MCS5 MCS6 MCS7 802.11n MCS0 MCS1 MCS2 MCS3 MCS4 HT40 Tgtpwr 15.5 14.5 14.5 14.5 (dBm) MCS5 MCS6 MCS7 802.11ax MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 HE20 Tgtpwr (dBm) MCS6 MCS7 MCS8 MCS9 MCS10 MCS11 802.11ax...
- Page 12 WCBN814A User Manual (dBm) MCS5 MCS6 MCS7 802.11ac MCS0 MCS1 MCS2 MCS3 MCS4 VHT20 Tgtpwr (dBm) MCS5 MCS6 MCS7 MCS8 802.11ac MCS0 MCS1 MCS2 MCS3 MCS4 VHT40 Tgtpwr (dBm) MCS5 MCS6 MCS7 MCS8 MCS9 802.11ac MCS0 MCS1 MCS2 MCS3 MCS4...
- Page 13 WCBN814A User Manual Tgtpwr (dBm) MCS6 MCS7 MCS8 MCS9 MCS10 MCS11 802.11ax MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 HE80 Tgtpwr (dBm) MCS6 MCS7 MCS8 MCS9 MCS10 MCS11 802.11ax MCS0 MCS1 MCS2 MCS3 MCS4 MCS5 HE160 Tgtpwr (dBm) MCS6 MCS7 MCS8...
- Page 14 WCBN814A User Manual 11g-6M PER < 10% 11g-54M PER < 10% 11n-HT20MCS0 PER < 10% 11n-HT20MCS7 PER < 10% 11n-HT40MCS0 PER < 10% 11n-HT40MCS7 PER < 10% 11a-6M PER < 10% 11a-54M PER < 10% 11n-HT20MCS0 PER < 10% 11n-HT20MCS7 PER <...
- Page 15 WCBN814A User Manual 1. M ODULE INOUT Table 2-1 Module pinout definition (M.2 Key E) * The following signal type is defined: I: Input; O: Output; I/O: Input/Output; G: Ground; P: Voltage Supply Pin. Pin Define Description Status Ground 3.3V 3.3V source...
- Page 16 WCBN814A User Manual Ground RESERVED PCIe TX differential signal shall be connected to PETp0 receiver differential pair on the system board RESERVED PCIe TX differential signal shall be connected to PETn0 receiver differential pair on the system board COEX0 Coexistence between WiFi+BT and WWAN...
-
Page 17: Electrical Specifications
WCBN814A User Manual 2. E LECTRICAL SPECIFICATIONS 3.1 Operation Conditions Table 3-1 Recommended Operation Conditions Symbol Rating Units 3.3V 3.3V Supply Voltage 2.97 3.63 Ambient operating temperature Storage temperature Table 3-2 DC Characteristics Symbol Parameter Units Input Low Voltage -0.3 0.99... - Page 18 WCBN814A User Manual 3.2 Power Sequence Timing Figure 3-1 Power sequence timing parameters Page 18/21...
-
Page 19: Module Dimension
WCBN814A User Manual 3. M ODULE IMENSION Page 19/21... - Page 20 WCBN814A User Manual 4. I-PEX C SPEC ONNECTOR Table 5-1 Specifications for MFH 4 connector on the module I-PEX Manufactuer Manufactuer part number 20449-001E Figure 5-1 Specifications for MFH4 connector Page 20/21...
-
Page 21: Module Photo
WCBN814A User Manual 5. M ODULE HOTO Front Back 6. EEPROM I NFORMATION Most of World SKU Reg Domain 0x006C Vendor ID 0x17CB Device ID 0x1103 SubDevice ID 0x3374 SubVendor ID 0x17CB Page 21/21...
