802.11n, dual band 2t2r wireless usb module

Advertisement

Quick Links

802.11n, Dual Band 2T2R Wireless USB Module
Change History
Revision
Date
Version 1.0
2012/03/29
Version 1.1
2012/06/05
* This document contains confidential proprietary information and is property of LTC. The contents of
this document should not be disclosed to unauthorized persons without the written consent of LTC.
User manual
WN4501L
Version 1.1
Author: Ben J. Chen
Editor: Ben J. Chen
Project Leader: Jason Chien
Approved by: Jason Chien
Author
Change List
Ben J. Chen
Preliminary
Update Power Consumption
Update Antenna Type
Update Label Drawing
Ben J. Chen
Update Module Photo
Update EEPROM information
Update Packing Drawing
Page 1/11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WN4501L and is the answer not in the manual?

Questions and answers

Summary of Contents for LiteOn WN4501L

  • Page 1 User manual 802.11n, Dual Band 2T2R Wireless USB Module WN4501L Version 1.1 Author: Ben J. Chen Editor: Ben J. Chen Project Leader: Jason Chien Approved by: Jason Chien Change History Revision Date Author Change List Version 1.0 2012/03/29 Ben J. Chen...
  • Page 2: Table Of Contents

    ONTENT PRODUCT FEATURES ........................4 ............................4 EATURE PRODUCT SPECIFICATIONS ......................5 ............................5 HIPSET ....................... 5 UNCTIONAL PECIFICATIONS PIN ASSIGNMENT ..........................7 MECHANICAL ..........................7 BLOCK DIAGRAM ........................... 8 LABEL DRAWING ..........................8 MODULE PHOTO ..........................9 EEPROM INFORMATION ......................10 ENVIRONMENTAL ........................
  • Page 3: Product Features

    Wi-Fi Feature  Operate at ISM frequency Band (2.4GHz/5GHz)  IEEE Standards Support, 802.11a, 802.11b, 802.11g and 802.11n  The WN4501L is developed using single-chip designed by Realtek Semiconductor Corp.  Complies with USB Specification 2.0, support Full-speed(12Mbps) and High-speed(480Mbps) ...
  • Page 4: Product Specifications

    RODUCT PECIFICATIONS HIPSET Realtek RTL8192DU UNCTIONAL PECIFICATIONS Wi-Fi Function IEEE802.11a; IEEE802.11b; IEEE 802.11g; IEEE 802.11n Standard USB Interface Bus Interface 802.11b: 11, 5.5, 2, 1 Mbps 802.11a/g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps Data Rate 802.11n: MCS 0 to 15 for HT20MHz MCS 0 to 15 for HT40MHz Media Access Control CSMA/CA with ACK...
  • Page 5 13 dBm@MCS0 13 dBm@MCS7 13 dBm@MCS15 802.11n(5GHz): 20MHz: 15 dBm@MCS0 11 dBm@MCS7 11 dBm@MCS15 40MHz: 15 dBm@MCS0 11 dBm@MCS7 11 dBm@MCS15 802.11a: -76 dBm@54Mbps 802.11b: -86 dBm@11Mbps 802.11g: -77 dBm@54Mbps 802.11n(2.4GHz): 20MHz -74 dBm@MCS7 -71 dBm@MCS15 Receiver Sensitivity 40MHz -70 dBm@MCS7 -67 dBm@MCS15 802.11n(5GHz): 20MHz...
  • Page 6: Pin Assignment

    SSIGNMENT Pin. Pin Define Status USB D- USB D+ Reset ECHANICAL Page 7/11...
  • Page 7: Eeprom Information

    EEPROM I NFORMATION World Wide 2.4GHz Channels 1-11 with active scan Channels 12,13 with passive scan Chanel 14 with no scan Reg Domain 5GHz: (all passive scan) 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149, 153, 157, 161, 165 0x13 0x00...
  • Page 8: Packing Drawing

    ACKING RAWING Page 11/11...
  • Page 9 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digi tal device, pursuant to part 15 of the FCC rules.
  • Page 10 1. To comply with IC RF exposure compliance requirements, the antenna used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co- located or operating in conjunction with any other antenna or transmitter, except in accordance with IC multi­transmitter product transmitter product procedures.
