Safety Precaution Read all documentations carefully before operating the equipment. Retain this manual for future reference. Follow all instructions printed on unit for proper operation. Do not opern cover (or back cover) to reduce the risk of electric shock or re. There are no User serviceable parts inside.
Page 26
Control & Layout Con guration 1. POWER SWITCH: Press to switch the power unit ON or OFF. 2. 3.5MM INPUT 1: To connect with other music sources with 3.5mm Jack 3. Headphone output: To connect with headphones 4. XLR MIC INPUT: 1/4” /XLR combo jack for microphone 5.
16. FM antenna: Adjust for better signal reception 17. RCA INPUTS: Connect the audio output jacks of DVD/CD, to these jacks 18. TAPE INPUT AND OUTPUT: Press TAPE monitor on the front panel to monitor the headphone or connect with another ampli er through REC INPUT. To connect with other audio input jacks to PLAY OUTPUT 19.
Page 28
Features: • Rack Mount Ampli er Sound Receiver System • Wireless BT Audio Streaming Ability • Unique Recording Mode Saves Audio via USB/SD Port • USB Flash & SD Memory Card Readers • Aux (3.5mm) Input Jack • Connect & Stream Audio from External Devices •...
Page 29
Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.com...
