07/23 MN048017EN

Manual

XV300
Manual


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XV300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Eaton XV300

Summary of Contents for Eaton XV300

  • Page 1: Xv300 Manual

    07/23 MN048017EN   Manual   XV300 Manual  ...

  • Page 2: Company Information

    No part of this manual may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, micro-filming, record- ing, or otherwise, without the prior written permission of Eaton Industries GmbH, Bonn. Subject to alteration.

  • Page 3: Before Starting With The Installation

    GEFAHR! Gefährliche elektrische Spannung! Before starting with the installation   Installation requires qualified electrician desktop devices and portable devices only when   the housing is closed. Disconnect the power supply of the device.     Measures should be taken to ensure the proper Secure against retriggering  ...

  • Page 5: Table Of Contents

    Table of Contents XV300 Manual Company information Before starting with the installation Table of Contents About this documentation 0.1.1 List of revisions 0.1.2 Target group 0.1.3 Legal disclaimer 0.1.4 Device designations and abbreviations 0.1.5 Writing conventions 0.1.5.1 Warning labels 0.1.5.2...
  • Page 6 Unpacking and checking the equipment supplied Mounting 3.3.1 Fixing and sealing 3.3.2 Front mounting XV-303 3.3.3 Rear (wall) mounting XV-313 Preparing the device for operation 3.4.1 Functional earthing XV300 3.4.2 Power supply - electrical connection Commissioning Initial commissioning Running the XV300 External connections XV300  07/23 MN048017EN  Eaton.com...
  • Page 7 COM1 RS-232 5.5.1.1 Wiring topic 5.5.2 COM2 RS-485 CAN1 interface for the CANopen protocol, J1939 protocol, etc. 67 Profibus Interfaces XV300 multi-touch display as a SmartWire-DT coordinator 5.8.1 SmartWire-DT powered via POW/AUX 5.8.1.1 SWD power supply voltages 5.8.2 SmartWire-DT interface 5.8.2.1...
  • Page 8 Port and interface specifications A.1.4.1 Front mounting A.1.4.2 Front mounting with SmartWire-DT connection A.1.4.3 Rear (panel) mounting A.1.4.4 Rear (panel) mounting with SmartWire-DT connection A.1.5 Information on the power supply A.1.6 Approvals and declarations Further usage information Alphabetical index XV300  07/23 MN048017EN  Eaton.com...

  • Page 9: About This Documentation

    0.1 About this documentation 0.1 About this documentation This Manual contains all the information you will need in order to use the XV300 safely and effectively. The Manual XV300 manual is considered an integral part of the devices and must always be readily available in the device's close proximity so that users have access to it.

  • Page 10: Target Group

    This Manual is intended for electricians and electrical engineers, as well as for the people who will be in charge of performing the electrical installation and people who will be using the XV300 as an operating and monitoring device or as an integrated operating and control device in their own applications.

  • Page 11: Legal Disclaimer

    It is assumed that the user of this manual is thoroughly familiar with the information found in the manuals for incorporating the XV300 into automation processes. Hazards posed by the XV300 cannot be eliminated if the safety instructions are not observed – especially if the XV300 is commissioned and maintained by unqualified personnel and/or the XV300 is used improperly.

  • Page 12: Writing Conventions

    Warns of the possibility of hazardous situations that could result in serious injury or even death. DANGER! Dangerous Electrical Voltage! CAUTION Warns of the possibility of hazardous situations that can cause injury. Property damage warning NOTICE Warns about the possibility of material damage. XV300  07/23 MN048017EN  Eaton.com...

  • Page 13: Additional Information For Use

    Documents (such as manuals) are listed after the icon together with the cor- responding name and Eaton number. Publication title For identifying the Eaton publication code External Internet addresses. They will be shown after the icon. Destination address XV300  07/23 MN048017EN  Eaton.com...

  • Page 14: Description

    With their compact and sleek design – featuring a heavy-duty, flat, anti-glare glass panel – XV300 multi-touch display are ideal for industrial applications in harsh envir- onments. 1.1.1 Features  ...

  • Page 15: Notes

    Eaton calls this concept "Lean Automation" and uses it to provide users in the machine building and plant engineering industries with unparalleled freedom so that they can design creative and prof- itable solutions.

  • Page 16: Use As Intended

    The XV300 multi-touch display are approved for use in closed spaces. The HMI-PLC must be used only in locations for which the XV300 is approved. Make sure to read and follow the information and labels on the nameplate for the HMI-PLC, as well as section Approvals and declarations in the appendix.

  • Page 17: Device Models - Versions And Part Nos

    Additional integrated interfaces   Second Ethernet port (10/100 Mbit/s) for use as a communication interface   PROFIBUS-DP, universal field bus interface for all typical protocols   SmartWire-DT for an efficient use of SmartWire-DT technology and its com- prehensive features XV300  07/23 MN048017EN  Eaton.com...
  • Page 18 Service side with optional interfaces XV-303-10-.. XV-303-10-CE2-A00-1C     Fig. 3: Front with plastic bezel Fig. 4: Service side with optional interfaces XV-303-70-.. XV-303-70-CE2-A00-1C     Front with plastic bezel Fig. 5: Service side with optional interfaces XV-303-15-.. XV-303-15-C00-A00-1C XV300  07/23 MN048017EN  Eaton.com...
  • Page 19 Tab. 3: Enclosure versions for rear (panel) mounting Fig. 6: Front side with aluminum mounting frame Fig. 7: Service side with optional interfaces XV-313-10-.. XV-313-10-...     Fig. 8: Front side with aluminum mounting frame Fig. 9: Service side with optional interfaces XV-313-70-.. XV-313-70-... XV300  07/23 MN048017EN  Eaton.com...

  • Page 20: Operating And Indication Elements

    Display, touch sensor Detects when the controls shown on the display are being actuated. Operation based on touch gestures. ② SD card slot Slot for SD card ③ CTRL button The specific function depends on the software being used XV300  07/23 MN048017EN  Eaton.com...

  • Page 21: Interfaces To Peripheral Devices

    1. Description 1.5 Interfaces to peripheral devices 1.5 Interfaces to peripheral devices The interfaces featured by your XV300 will depend on theXV version selected and cannot be modified. The nameplate will indicate which specific interfaces are included with the unit.

  • Page 22: What The Different Parts Of The Part Number Mean

    1.6 What the different parts of the part number mean The part number includes information that specifies the version and model of the spe- cific device being used. The nameplate on your XV300 multi-touch display will show the corresponding part number. Tab. 4: Part number - 3..
  • Page 23 For more information, or to order, contact your supplier or use the Eaton online catalog. Enter "XV300" into the search box and the catalog will take you directly to the cor- responding product group in the Automation, Control and visualization section. Eaton.com/ecat...

  • Page 24: Accessory Devices

    1. Description 1.7 Accessory devices 1.7 Accessory devices A variety of accessories are available for XV300 multi-touch displays.   SD card   Accessories NOTICE Only use original accessories. Order accessories through your supplier or through the EATON online catalog Eaton.eu/ecat Example: article no.

  • Page 25: Nameplate

    Manufacturer   Part number   Part-No.   Version   Date of manufacture   Required power supply   Serial-No.   Type approval and certification marks and information   Layout of ports/interfaces and controls Fig. 11: Example for a nameplate XV300  07/23 MN048017EN  Eaton.com...

  • Page 26: Support

    1. Description 1.9 Support 1.9 Support To get fast and effective support, make sure to always provide Customer Service with the following information from the nameplate:   Part-No.   Serial-No XV300  07/23 MN048017EN  Eaton.com...

  • Page 27: Conditions For Underwriters Laboratories Inc. (Ul) Listing

    The torque used to tighten the screw terminals on the plug-in connection for the sup- ply voltage must not exceed 0.6 ... 0.8 Nm (5 ... 7 lb-in). Required only for XV300 SmartWire-DT units with a XV-3.3-..-.E.-...-.. connection. The supply voltage U...

  • Page 28: Marine Approvals

    1. Description 1.11 Marine approvals 1.11 Marine approvals Type approval received XV300 multi-touch display 7.0" und 10.1" have been granted the required shipping clas- sification by Det Norsk Veritas / Germanischer Lloyd (DNV GL)   DNVGL-CG-0339 type approval, November 2015 edition, "Environmental test specification for electrical, electronic and programmable...

  • Page 29: Safety Regulations

    Follow the safety instructions for the XV300! The section on safety instructions must be read and understood by everyone who will be working with the XV300 before the actual work is performed HMI-PLC. NOTICE Pay attention to the hazard severity levels used throughout this doc- umentation whenever a hazard is indicated.

  • Page 30: Mandatory Requirements, Personnel Requirements

    2.2.3 Device documentation This manual is considered an integral part of the XV300 and must always be readily available in the device's close proximity so that users have access to it. Make sure that every person who will be working with the XV300, regardless of the lifecycle stage involved, has read and understood the relevant parts of the doc- umentation for the XV300.

  • Page 31: Prerequisites For Proper Operation

    Dispose of recyclables as required by your local recycling reg- ulations. HMI-PLC XV300 no longer being used must be professionally disposed of as per local standards or returned to the manufacturer or relevant sales department. 2.2.5 Prerequisites for proper operation...

  • Page 32: Device-Specific Hazards

    The lithium battery inside the XV300 may explode if handled incor- rectly. Dispose of the XV300 unit professionally. CAUTION DESTRUCTION The XV300 should only be opened by the manufacturer or by an authorized center. Operate the XV300 until only with the enclosure fully closed and sealed. CAUTION ELECTROSTATIC DISCHARGE Do not touch components (e.g., connector pins) that are elec-...
  • Page 33 CAUTION SAFELY DIVERTING ELECTRICAL INTERFERENCE CURRENTS HMI-PLC The XV300 must be connected to a central earth point with a conductor that is as short and has as low a resistance as possible.   Ground connection characteristics: Wire cross-sectional area ≧...
  • Page 34 Do not switch on the XV300 multi-touch display when it has con- densation in or on it. If the XV300 multi-touch display has condensation in or on it, or if the panel has been exposed to environmental fluctuations, let the panel settle into the existing ambient temperature before switching it on.
  • Page 35 Do not use any pointy or sharp objects (e.g., knives).   Do not use aggressive or abrasive cleaning products or solvents. Make sure that no liquids get into the XV300 unit (short-circuit haz- ard) and that the XV300 unit is not damaged in any way. CAUTION...
  • Page 36 Protect the RJ45 plug-in connection from tensile forces at the socket. WARNING XV300 units are products designed for use in industrial environments as defined in ICE/EN 6100−6-4. These products can cause radio inter- ference in domestic environments. In this case, the party operating the products must implement appropriate radio interference sup- pression measures.

  • Page 37: Installation

    3.1 Prerequisites for the location of use 3. Installation 3.1 Prerequisites for the location of use The XV300 must be used exclusively in locations for which HMI-PLC has been appro- ved/certified. A 24 VDC supply voltage must be ensured as per the specifications.

  • Page 38: Aeration And De-Aeration

    Do not block the ventilation openings when mounting the device: They are designed to allow air to circulate in order to cool the HMI-PLC.   The device uses natural convection-based passive cooling, i.e., it does not use fans. XV300  07/23 MN048017EN  Eaton.com...

  • Page 39: Criteria For The Installation Position

      The XV300 can be installed in landscape or portrait mode. If you are using your XV300 unit with an SD card, do not install it with the SD slot facing downwards, as the SD card may fall out otherwise.
  • Page 40 (panel) mounting XV-313-70-..: e = 182.7 mm ±0.1 (7.193" ±0.004), f = 126.8 mm ±0,1 (4.992"±0.004) XV-313-10-..: e = 255.7 mm ±0.1 (10.07"±0.004), f = 165.8 mm ±0.1 (6.528" ±0.004) α α √ √ Fig. 15: Mounting position XV300  07/23 MN048017EN  Eaton.com...

  • Page 41: Technical Conditions For Acceptance By Underwriters Laboratories Inc. (Ul)

    The torque used to tighten the screw terminals on the plug-in connection for the sup- ply voltage must not exceed 0.6 ... 0.8 Nm (5 ... 7 lb-in). Required only for XV300 SmartWire-DT units with a XV-3.3-..-.E.-...-.. connection. The supply voltage U...

  • Page 42: Conditions For Marine Approval

    Integrate a radio interference suppression filter into the wiring. Depending on the output, the following filters can be used:   XT-FIL-1 radio interference suppression filter for 24 V DC supply up to 2.2 A (Eaton article no. 285316)   XT-FIL-2 radio interference suppression filter for 24 V DC supply up to 12 A (Eaton article no.
  • Page 43 Earthing is ensured either by using   the filter's integrated contact fields onto a grounded metal plate or using   a separate line to the filer's PE connection. Depending on the current consumption or configuration, several filters may be used as well. XV300  07/23 MN048017EN  Eaton.com...

  • Page 44: Unpacking And Checking The Equipment Supplied

    10 x for XV-303-10-.., 12 x for XV-303-15-.. The XV300 is sturdily built, but the components inside it are sensitive to excessively strong vibrations and/or mechanical shock. Accordingly, make sure to protect the XV300 from mechanical loads that exceed the scope of the unit's intended use.

  • Page 45: Mounting

    Check the gasket for damage and make sure it is resting correctly inside the enclosure groove. Missing parts or damage If you notice anything wrong, please contact your distributor or Eaton Service +49 (0) 180 5 223822 (de,en) XV300  07/23 MN048017EN  Eaton.com...

  • Page 46: Front Mounting

    Together with the gasket, this holding bracket is the main element involved in achie- ving an IP65 (at front) degree of protection. The purpose of the holding brackets is to secure the XV300 onto a control panel, etc. To this end, the brackets must be hooked into the enclosure sideways and screwed against the control panel door, etc.
  • Page 47 6. Check that the device is in its correct, centered position and that the gasket is in contact all around; adjust if necessary. 7. Tighten the set screws in a criss-cross sequence: with a torque of ≦ 0.1Nm (0.86 lb-in) XV300  07/23 MN048017EN  Eaton.com...

  • Page 48: Rear (Wall) Mounting

    R 3.5 ±0.1 mm (R 0.14 ±0.004") M4 x 12 156 ±0.5 mm (6.14 ±0.02") 182.7 ±0.1 mm (7.19 ±0.004") 199 ±0.5 mm (7.83 ±0.02") Fig. 18: Dimensional drawing for mounting XV-313-70-.. XV300  07/23 MN048017EN  Eaton.com...
  • Page 49 2. Center the XV-313 in the mounting cutout. 3. Use washers and M4 nuts to fasten the XV-313 to all the weld studs on the sheet in such a way that there is zero clearance Fig. 20: Mounting XV-313 XV300  07/23 MN048017EN  Eaton.com...

  • Page 50: Preparing The Device For Operation

    Do not switch on the XV300 multi-touch display when it has con- densation in or on it. If the XV300 multi-touch display has condensation in or on it, or if the panel has been exposed to environmental fluctuations, let the panel settle into the existing ambient temperature before switching it on.
  • Page 51 The XV300 multi-touch display has an internal fuse and protection against polarity reversal. The power supply for the XV300 multi-touch display is not galvanically isolated. The XV300 multi-touch display requires a rated operating voltage of 24 VDC from an AC-to-DC converter with safe isolation (SELV/PELV). Power Supply...

  • Page 52: Functional Earthing Xv300

    3.4.1 Functional earthing XV300 CAUTION SAFELY DIVERTING ELECTRICAL INTERFERENCE CURRENTS HMI-PLC The XV300 must be connected to a central earth point with a conductor that is as short and has as low a resistance as possible.   Ground connection characteristics: Wire cross-sectional area ≧...

  • Page 53: Power Supply - Electrical Connection

    +24 V DC = 24 V DC (19.2 - 30 V DC SELV) = ... 0.6 - 0.8 Nm (5 - 7 lb-in) 0 V +24 V DC Fig. 22: Connecting the screw terminals on the Plug connector MSTB 2.5/3-ST-5.08 XV300  07/23 MN048017EN  Eaton.com...
  • Page 54 (SELV) set forth in IEC 60950 and – in connection with the UL listing – the requirements for a low-voltage source set forth in UL 61010-2-201. The XV300 is now ready to run on 24 V XV300  07/23 MN048017EN  Eaton.com...

  • Page 55: Commissioning

    Do not switch on the XV300 multi-touch display when it has con- densation in or on it. If the XV300 multi-touch display has condensation in or on it, or if the panel has been exposed to environmental fluctuations, let the panel settle into the existing ambient temperature before switching it on.

  • Page 56: Initial Commissioning

    4. Commissioning 4.1 Initial commissioning 4.1 Initial commissioning Carry out the following steps once: Configure the XV300 unit's system settings as necessary. Install the required software packages. XV300  07/23 MN048017EN  Eaton.com...

  • Page 57: Running The Xv300

    4.2 Running the XV300 4.2 Running the XV300 Once the XV300 has been initially commissioned, it will run whenever it is connected to the supply voltage. In other words, it does not have to be separately switched on and off.

  • Page 58: External Connections

    5. External connections 5. External connections With their ports, Eaton's XV300 multi-touch display make it possible to connect a vari- ety of peripheral devices and components. DANGER STRAY CURRENTS Large equalizing currents between the functional earthing system and the ground system of different devices may result in fire or in mal- functions due to signal interference.

  • Page 59: Layout Of Interfaces

    ⑤ COM2 RS-232, not galvanically isolated, SUB-D plug 9-pole, UNC nuts for interlocking ⑥ COM1 RS-485, not galvanically isolated, SUB-D plug 9-pole, UNC nuts for interlocking ⑦ CAN1, not galvanically isolated, SUB-D plug 9-pole, UNC nuts for interlocking XV300  07/23 MN048017EN  Eaton.com...

  • Page 60: Optional Interfaces

    5. External connections 5.1 Layout of interfaces 5.1.1 Optional interfaces Fig. 25: XV300 multi-touch display with all optional features ⑧ Ethernet 2 RJ-45 socket, 8-pole, 2 LEDs (CAT5e/6), LAN1, 10/100 Mbps ⑨ Profibus Profibus DP, not galvanically isolated, SUB-D socket 9-pole, UNC nuts for interlocking ⑩...

  • Page 61: Sd Card

    5. External connections 5.2 SD card 5.2 SD card The slot for the SD card is on the side of the XV300 unit. CAUTION DATA LOSS If the SD card is being written to and a voltage drop occurs or the card is removed, data may be lost or the SD card may be ruined.

  • Page 62: Usb Interfaces

    5. External connections 5.3 USB interfaces 5.3 USB interfaces Eaton's XV300 multi-touch display units feature ports that can be used to connect USB peripheral devices supported by the XV300 unit's hardware and operating sys- tem. CAUTION When using commercially available peripheral devices (e.g., with the...

  • Page 63: Ethernet 1, Ethernet

    5.4 Ethernet 1, Ethernet 2 5.4 Ethernet 1, Ethernet 2 The Ethernet 1 port on the XV300 can be used as a communication interface or as a real-time field bus interface. The Ethernet 2 port on the XV300 multi-touch display XV-3.3-..-C..-...-.. can only be used as a communication interface without real-time requirements.

  • Page 64: Serial Interfaces For Communication With Plcs Or Devices

    NON-GALVANICALLY-ISOLATED INTERFACES The XV300 may be damaged by potential differences. The GND terminals of all bus modules must be connected. Do not connect the connector to the XV300 or disconnect it without first de-energizing the system. Tab. 14: Pin assignment COM1...

  • Page 65: Com2

    NON-GALVANICALLY-ISOLATED INTERFACES The XV300 may be damaged by potential differences. The GND terminals of all bus modules must be connected. Do not connect the connector to the XV300 or disconnect it without first de-energizing the system. Tab. 16: Pin assignment COM2...
  • Page 66 The bus segment must be terminated at both ends. There must not be more than two terminations per bus segment. Running the bus segment without the right termination may result in transmission errors.   Fig. 29: Bus segment with four nodes XV300  07/23 MN048017EN  Eaton.com...

  • Page 67: Can1 Interface For The Canopen Protocol, J1939 Protocol, Etc

    The XV300 may be damaged by potential differences. The GND terminals of all bus modules must be connected. Do not connect the connector to the XV300 or disconnect it without first de-energizing the system. Tab. 18: PIN assignment for CAN interface as specified in CiA)
  • Page 68 The bus segment must be terminated at both ends. There must not be more than two terminations per bus segment. Running the bus segment without the right termination may result in transmission errors. Fig. 30: CAN bus segment with four nodes XV300  07/23 MN048017EN  Eaton.com...

  • Page 69: Profibus Interfaces

    NON-GALVANICALLY-ISOLATED INTERFACES The XV300 may be damaged by potential differences. The GND terminals of all bus modules must be connected. Do not connect the connector to the XV300 or disconnect it without first de-energizing the system. Tab. 20: Pin assignment for...
  • Page 70 No more than two terminations must be provided for each bus segment.   At least one of the two terminations must be fed by the bus sta- tion.   Operation without correct termination of the Profibus network can cause transfer errors. XV300  07/23 MN048017EN  Eaton.com...

  • Page 71: Xv300 Multi-Touch Display As A Smartwire-Dt Coordinator

    NON-GALVANICALLY-ISOLATED INTERFACES The XV300 may be damaged by potential differences. The GND terminals of all bus modules must be connected. Do not connect the connector to the XV300 or disconnect it without first de-energizing the system. Electrical connection Power supply SmartWire-DT POW/AUX Fig.

  • Page 72: Swd Power Supply Voltages

    5. External connections 5.8 XV300 multi-touch display as a SmartWire-DT coordinator Conditions for Underwriters Laboratories Inc. (UL) listing. The supply voltage U of the SmartWire-DT master interface must be externally protected against overcurrent and short circuit by means of:  ...
  • Page 73 5. External connections 5.8 XV300 multi-touch display as a SmartWire-DT coordinator Observe the following when assembling and terminating the wiring for the plug con- nector: Tab. 23: Wiring the plug connector   Description/Value Terminal type: spring-cage terminal Cross-section 0.2 - 1.5 mm...

  • Page 74: Smartwire-Dt Interface

    The XV300 may be damaged by potential differences. The GND terminals of all bus modules must be connected. Do not connect the connector to the XV300 or disconnect it without first de-energizing the system. SmartWire-DT uses an eight-conductor ribbon cable in control panels. In addition to communication wires, this ribbon cable carries the power supply for the SWD mod- ules, the switchgear, as well as control wires for assigning addresses.

  • Page 75: Commissioning The Smartwire-Dt Network

    The SmartWire-DT network's physical configuration must be stored in the 's retent- ive HMI-PLC as a target configuration. The SWD LED on the SmartWire-DT master interface must light up with a solid green light. Load the PLC project onto the XV300 multi-touch display. XV300  07/23 MN048017EN  Eaton.com...
  • Page 76 5. External connections 5.8 XV300 multi-touch display as a SmartWire-DT coordinator Configuration tests The configurations are compared every time the power supply is switched on.   The modules that are actually on the network will be compared with the target...
  • Page 77 5. External connections 5.8 XV300 multi-touch display as a SmartWire-DT coordinator Tab. 27: Config-LED Config-LED Indicates whether the SWD master project configuration defined in the PLC matches the SWD network target configuration stored in the . XV300   Description State  ...

  • Page 78: Faults

    6. Faults 6. Faults This section provides troubleshooting information for your XV300 in case it does not behave as expected. Fault Cause Remedy XV300 will not boot up Check the input wiring. No 24 VDC supply voltage Switch on XV300.

  • Page 79: Maintenance

      Do not use aggressive or abrasive cleaning products or solvents. Make sure that no liquids get into the XV300 unit (short-circuit haz- ard) and that the XV300 unit is not damaged in any way. Clean the Capacitive multi-touch technology (PCT) with a clean, soft, damp cloth.

  • Page 80: Repairs

    For repairs, please contact your vendor or Eaton's Technical Support. CAUTION DESTRUCTION The XV300 should only be opened by the manufacturer or by an authorized center. Operate the XV300 until only with the enclosure fully closed and sealed. Use the original packaging to ship the device.

  • Page 81: Storage, Transport And Disposal

    Do not switch on the XV300 multi-touch display when it has con- densation in or on it. If the XV300 multi-touch display has condensation in or on it, or if the panel has been exposed to environmental fluctuations, let the panel settle into the existing ambient temperature before switching it on.
  • Page 82 HMI-PLC until it is completely dry. Use the original packaging to ship the device. The XV300 is sturdily built, but the components inside it are sensitive to excessively strong vibrations and/or mechanical shock. Accordingly, make sure to protect the XV300 from mechanical loads that exceed the scope of the unit's intended use.

  • Page 83: Disposal

    Dispose of recyclables as required by your local recycling reg- ulations. XV300 no longer being used must be professionally disposed of as per local stand- ards or returned to the manufacturer or relevant sales department. Tab. 28: Materials used XV300 Assembly part  ...

  • Page 84: Appendix

    Appendix Appendix A.1 Technical data A.1.1 Data sheets A.1.2 Dimension and weight specifications A.1.3 General data A.1.4 Port and interface specifications A.1.5 Information on the power supply A.1.6 Approvals and declarations A.2 Further usage information XV300  07/23 MN048017EN  Eaton.com...

  • Page 85: Technical Data

    (1.70") (0.28") Fig. 35: Dimensions for 7.0" front mounting devices in mm (inches) Width x Height x Depth 196 mm x 135 mm x 51 mm (7.72" x 5.31" x 2.01") (without plug) Weight 0.74 kg (1.63 lbs) XV300  07/23 MN048017EN  Eaton.com...
  • Page 86 (1.97") (0.28") Fig. 36: Dimensions for 10.1" front mounting devices in mm (inches) Width x Height x Depth 269 mm x 174 mm x 58 mm (10.59" x 6.85" x 2.28") (without plug) Weight 1.13 kg (2.49 lbs) XV300  07/23 MN048017EN  Eaton.com...
  • Page 87 Fig. 37: Dimensions for 15.6" front mounting devices in mm (inches) Width x Height x Depth 401.7 mm x 254.9 mm x 67.6 mm ±0.2 (15.9" x 10.04" x 2.661" ±0.008 ) (without plug) Weight 3.25 kg (7.17 lbs) XV300  07/23 MN048017EN  Eaton.com...
  • Page 88 ⌀ 7.5 mm (⌀ 0.30") R 2.9 mm (R 0.11") x 1.5 mm (0.059") 156 mm (6.14") 156 mm (6.14") 181.5 mm (7.15") 209 mm (8.23") Fig. 38: Dimensions for 7.0" rear (panel) mounting devices in mm (inches)XV-313-..-...-A00-.. XV300  07/23 MN048017EN  Eaton.com...
  • Page 89 209 mm (8.23") Fig. 39: Dimensions for 7.0" rear (panel) mounting devices in mm (inches)XV-313-..-...-A11-.. Width x Height x Depth 209 mm x 151 mm x 51 mm (8.23" x 5.94" x 2.01") (without plug) Weight 0.8 kg (1.76 lbs) XV300  07/23 MN048017EN  Eaton.com...
  • Page 90 ⌀ 5.5 mm (⌀ 0.22") ⌀ 7.5 mm (⌀ 0.30") R 3.2 mm (R 0.13") x 1.5 mm (0.059") 170 mm (6.69") 254.4 mm (10.02") 282 mm (11.10") Fig. 40: Dimensions for 10.1" rear (panel) mounting devices in mm (inches)XV-313-..-...-A00-.. XV300  07/23 MN048017EN  Eaton.com...
  • Page 91 282 mm (11.10") Fig. 41: Dimensions for 10.1" rear (panel) mounting devices in mm (inches)XV-313-..-...-A11-.. Width x Height x Depth 282 mm x 190 mm x 58 mm (11.10" x 7.48" x 2.28") (without plug) Weight 1.21 kg (2.67 lbs) XV300  07/23 MN048017EN  Eaton.com...

  • Page 92: Mounting Surrounds For Rear (Panel) Mounting

    Fig. 42: Installation panel for XV-313-70-..   R 3.9 ±0.1 mm (R 0.15 ±0.004") M4 x 12 170 ±0.5 mm (6.69 ±0.02") 255.7 ±0.1 mm (10.07 ±0.004") 272 ±0.5 mm (10.71 ±0.02") Fig. 43: Installation panel for XV-313-10-.. XV300  07/23 MN048017EN  Eaton.com...

  • Page 93: General Data

    Appendix A.1 Technical data A.1.3 General data The following specifications apply to all XV300 units or to the specified part nos. where applicable. General Type     XV-303 Plastic enclosure and glass panel in plastic frame   XV-313 Plastic enclosure and glass panel in aluminum mounting frame...
  • Page 94 Appendix A.1 Technical data Display   XV-303-10-.., XV-313-10-.., normally 500:1 XV-303-15-.. Brightness Normally 400 cd/m2 Backlight dimmable via software Lifespan of backlight Normally 50000 h at 25 °C XV300  07/23 MN048017EN  Eaton.com...

  • Page 95: Port And Interface Specifications

    SUB-D plug, 9-pole, UNC   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   – not galvanically isolated, D-Sub Profibus DP – bus 9-pole, UNC   SmartWire-DT mas- – – – –   XV300  07/23 MN048017EN  Eaton.com...
  • Page 96   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   – not galvanically isolated, D- Profibus DP – Sub bus 9-pole, UNC   SmartWire-DT mas- – – – –   XV300  07/23 MN048017EN  Eaton.com...
  • Page 97   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   – not galvanically isolated, D- Profibus DP – Sub bus 9-pole, UNC   SmartWire-DT mas- – – – –   XV300  07/23 MN048017EN  Eaton.com...

  • Page 98: Front Mounting With Smartwire-Dt Connection

    SUB-D plug, 9-pole, UNC   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   – not galvanically isolated, D- Profibus DP – Sub bus 9-pole, UNC   SmartWire-DT mas-   XV300  07/23 MN048017EN  Eaton.com...
  • Page 99 SUB-D plug, 9-pole, UNC   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   – not galvanically isolated, D-Sub Profibus DP – bus 9-pole, UNC   SmartWire-DT mas-   XV300  07/23 MN048017EN  Eaton.com...
  • Page 100 SUB-D plug, 9-pole, UNC   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   – not galvanically isolated, D-Sub Profibus DP – bus 9-pole, UNC   SmartWire-DT mas-   XV300  07/23 MN048017EN  Eaton.com...

  • Page 101: Rear (Panel) Mounting

    USB 2.0, not galvanically isolated   not galvanically isolated, SUB-D plug, 9-pole, UNC RS-232   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   Profibus DP –   – SmartWire-DT master   XV300  07/23 MN048017EN  Eaton.com...
  • Page 102 1 x USB device,   RS-232 not galvanically isolated, SUB-D plug, 9-pole, UNC   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   Profibus DP –   SmartWire-DT – master   XV300  07/23 MN048017EN  Eaton.com...

  • Page 103: Rear (Panel) Mounting With Smartwire-Dt Connection

    USB 2.0, not galvanically isolated   RS-232 not galvanically isolated, SUB-D plug, 9-pole, UNC   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   Profibus DP –   SmartWire-DT mas-   XV300  07/23 MN048017EN  Eaton.com...
  • Page 104 USB 2.0, not galvanically isolated   RS-232 not galvanically isolated, SUB-D plug, 9-pole, UNC   RS-485 not galvanically isolated, SUB-D plug, 9-pole, UNC   not galvanically isolated, SUB-D plug, 9-pole, UNC   Profibus DP –   SmartWire-DT mas- XV300  07/23 MN048017EN  Eaton.com...

  • Page 105: Information On The Power Supply

    Appendix A.1 Technical data A.1.5 Information on the power supply The following specifications apply to all XV300 units. Power Supply Rated operating voltage + 24 VDC SELV (safety extra low voltage)/PELV (protective extra low voltage) Permissible Voltage range Effective: 19.2-30.0 V DC (rated operating voltage -20%/+25%) Absolute with ripple: 18.0-31.2 V DC...
  • Page 106 Appendix A.1 Technical data Applies only to XV300 units with a XV-3.3-..-.E.-...-.. SmartWire-DT connection. Supply voltage U Rated operating voltage 24 V DC Effective: 20.4-28.8 V DC (rated operating voltage -15/+20%) Residual ripple of input voltage max. 5% Protection against polarity reversal Max.

  • Page 107: Approvals And Declarations

    -XV-313-70-..: on each 8 x -XV-313-10-..: on each 10 x Marine approval Type approval for the XV300 7.0"and 10.1" – provided that a radio interference sup- (shipping clas- pression filter for the device is installed in the wiring DNVGL-CG-0039, from 11/2015...
  • Page 108 Inclination from vertical: ⍺ ≦ ± 45° at operating temperature ≦ 45°C (113°F) possible (if using natural convection) Storage / Transport -20 – + 60 °C (-4 – +140 °F) Humidity Relative humidity 10 - 95 % Condensation non-condensing XV300  07/23 MN048017EN  Eaton.com...

  • Page 109: Further Usage Information

    MN05006001Z Manual for SmartWire-DT IP67 modules MN120006 Download Center,Eaton Online Catalog Enter "XV300" into the search box and the catalog will take you directly to the cor- responding product group in the Automation, Control and visualization section. Eaton.com/documentation Eaton.com/ecat XV300  07/23 MN048017EN  Eaton.com...
  • Page 110 Appendix A.2 Further usage information Product information For up-to-date information, please consult the product page on the Internet. Eaton.com/xv300 XV300  07/23 MN048017EN  Eaton.com...
