Sharp Notevision XG-PH50X-NL Setup Manual page 48

Video Wall Projection
4
Turn on all of the projectors.
5
Access the projector 1 from the
computer via Internet Explorer.
(See "Controlling the Projector Using Internet
Explorer (Version 5.0 or later)" on page
the details.)
6
Click "Stack" on the menu.
7
Select "Master" on "Stack Setting".
• "Slave Address" display will appear.
8
Make the IP address for each pro-
jector as shown below.
• Slave 1 : 192.168.150.4
• Slave 2 : 192.168.150.5
• Slave 3 : 192.168.150.6
9
Click the "Apply" button.
10
Access the projector 2 from the
computer via Internet Explorer.
(See "Controlling the Projector Using Internet
Explorer (Version 5.0 or later)" on page
the details.)
11
Click "Stack" on the menu.
12
Select "Slave" on "Stack Setting".
-48
23 for
23 for
