  • Page 1 XSL8/XSL12 Manual 1.1 en...
  • Page 2 General information XSL8/XSL12 Manual Version: 1.1 en, 09/2021, Dnnnn.EN .01 Copyright © 2021 by d&b audiotechnik GmbH & Co. KG; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.

  • Page 3: Table Of Contents

    Contents Safety precautions.............. 4 1.1 d&b ArrayCalc................5 XSL8/XSL12 loudspeaker..........6 2.1 Intended use................6 2.2 Connections................7 2.3 Operation..................7 2.3.1 Controller settings..............8 2.4 Dispersion characteristics............8 2.5 Technical specifications............10 Manufacturer's declarations......... 12 3.1 Conformity of loudspeakers............. 12 3.2 WEEE Declaration (Disposal)..........

  • Page 4: Safety Precautions

    Safety precautions Potential risk of personal injury Never stand in the immediate vicinity of loudspeakers driven at a high level. Professional loudspeaker systems are capable of causing a sound pressure level detrimental to human health. Seemingly non-critical sound levels (from approx. 95 dB SPL) can cause hearing damage if people are exposed to it over a long period.

  • Page 5: D&B Arraycalc

    1.1 d&b ArrayCalc For both safety and acoustic reasons, d&b line arrays must be designed using the d&b ArrayCalc simulation software. The software is available as a native stand-alone application for both Microsoft Windows and Mac OS X operating systems and can be downloaded at www.dbaudio.com.

  • Page 6: Xsl8/Xsl12 Loudspeaker

    XSL8/XSL12 loudspeaker 2.1 Intended use NOTICE! Only operate d&b SL-Series loudspeakers with the specified and correctly configured d&b amplifiers, otherwise there is a risk of damaging the loudspeaker components and the directional characteristics of the system cannot be achieved. Applicable d&b amplifiers: D40 | D80 Product description The XSL8 is a line array loudspeaker for small to medium-scale sound reinforcement applications.

  • Page 7: Connections

    SL-Series rigging components and arrays The cabinets are mechanically connected using the rigging strands on both sides of the cabinet front and a central strand at the rear of the cabinet. All necessary rigging components are mounted on the cabinet and fold out or slide out when needed. A detailed description of the rigging components is given in the respective rigging manuals.

  • Page 8: Controller Settings

    2.3.1 Controller settings For acoustic adjustment the functions CUT, CPL and HFC can be selected. CUT mode Set to CUT, the low frequency level of the cabinets is reduced. The XSL8/XSL12 array is now configured for use with applicable d&b subwoofer.
  • Page 9 XSL8 isobar diagram horizontal XSL12 isobar diagram horizontal d&b XSL8/XSL12 Manual 1.1 en...

  • Page 10: Technical Specifications

    2.5 Technical specifications System data Frequency response (–5 dB standard) 60 Hz - 18 kHz Frequency response (–5 dB CUT mode) 90 Hz - 18 kHz Max. sound pressure (1 m, free field) XSL8 141 dB XSL12 140 dB (SPLmax: Broadband signal IEC 60268) XSL8: Frequency response*, Standard and CUT modes *single cabinet within array Loudspeaker data...
  • Page 11 XSL8/XSL12 cabinet dimensions in mm [inch] d&b XSL8/XSL12 Manual 1.1 en...

  • Page 12: Manufacturer's Declarations

    Manufacturer's declarations 3.1 Conformity of loudspeakers This declaration applies to: d&b Z0770 XSL8 loudspeaker d&b Z0772 XSL12 loudspeaker manufactured by d&b audiotechnik GmbH & Co. KG. All product variants are included, provided they correspond to the original technical version and have not been subject to any later design or electromechanical modifications.
  • Page 13 www.dbaudio.com...
