Item Description
1 4 Up to four optional PCIe 5.0 x8 or up to two PCIe 5.0 x16 full-height, full-length slots (CPU2)
to
5 8 Up to four optional PCIe 5.0 x8 or up to two PCIe 5.0 x16 full-height, full-length slots (CPU1)
to
PCIe 5.0 x16 AIOM slot (NCSI)
A1
Note: Some combinations of expansion slot options may not be available due to the limited
number of PCIe lanes reserved for expansion slots. See Section 3.12 for details.

Power Supply Indicators

LED Color and State
Solid Green
Blinking Green
Blinking Amber
Solid Amber
Off
Expansion Slot Locations
Power Supply Indicators
Power Supply Condition
Indicates that the power supply is on
Indicates that the power supply is plugged in and turned off by the system.
Indicates that the power supply has a warning condition and continues to operate.
Indicates that the power supply is plugged in, and is in an abnormal state. The
system might need service. Please contact Supermicro technical support.
No AC power to modules
