  • Page 1 A+ Server AS -2014CS-TR USER’S MANUAL Revision 1.0b...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................12 Drive Carrier Indicators ....................12 Rear Features ........................13 Power Supply Indicators ....................14 1.5 Motherboard Layout ......................15 Quick Reference Table ......................16 Chapter 2 Server Installation 2.1 Overview ..........................18...
  • Page 5 A+ Server AS -2014CS-TR User's Manual Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................27 3.2 Accessing the System ......................28 Removing the Top Cover ....................28 3.3 Motherboard Components ....................29 Processor and Heatsink Installation ..................29 Memory Support ........................36 Memory Support ......................36 DIMM Module Population ....................37 DIMM Installation ......................39 DIMM Module Removal .....................39...
  • Page 6 Preface Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................67 5.2 Driver Installation ........................69 5.3 SuperDoctor 5 ........................70 ® 5.4 BMC ............................71 BMC ADMIN User Password ....................71 Chapter 6 BIOS 6.1 Introduction .........................72 Starting the Setup Utility ....................72 6.2 Main Setup .........................73 6.3 Advanced ..........................75 6.4 IPMI ............................94 6.5 Event Logs .........................97...
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Overview

    A+ Server AS -2014CS-TR User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the AS -2014CS-TR. The AS -2014CS-TR is based on the H12SSW-AN6 motherboard and the CSE-LA26TS-R920AWP chassis. In addition to the motherboard and chassis, several important parts that are included with the system are listed below.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides you with an overview of the main features of the AS -2014CS-TR. Please refer to Appendix C for additional specifications. System Features Motherboard H12SSW-AN6 Chassis CSE-LA26TS-R920AWP Single AMD EPYC™ 7002/7003 Series Processor Socket Type Memory 16 DIMM slots to support up to 4TB ECC DDR4-3200MHz memory...

  • Page 10: Server Chassis Features

    A+ Server AS -2014CS-TR User's Manual 1.4 Server Chassis Features Control Panel Power buttons and status LEDs are located on the control panel at the front of the chassis. The locations and descriptions of these buttons and LEDs are provided below. See Chapter 4 for details on the control panel connections.
  • Page 11 Chapter 1: Introduction Information LED Color, Status Description Red, solid An overheat condition has occurred. Red, blinking at 1Hz Fan failure, check for an inoperative fan. Red, blinking at 0.25Hz Power failure, check for a non-operational power supply. Red, solid, with Power LED blinking green Fault detected Blue and red, blinking at 10 Hz Recovery mode...

  • Page 12: Front Features

    A+ Server AS -2014CS-TR User's Manual Front Features The CSE-LA26TS-R920AWP is a 2U chassis See the illustration below for the features included on the front of the chassis. Service/Asset Tag with BMC Password Control Panel Figure 1-2. System Front View Logical Storage Drive Numbers Item Description...

  • Page 13: Rear Features

    Chapter 1: Introduction Rear Features The illustration below shows the features included on the rear of the chassis. The power supply modules also have status LEDs (see Chapter 3 for details). IPMI LAN Port UID LED VGA Port USB Ports COM Port Power Supplies Drive Bays...

  • Page 14: Power Supply Indicators

    Indicates that the power supply has a warning condition and continues to operate. Indicates that the power supply is plugged in, and is in an abnormal state. The Solid Amber system might need service. Please contact Supermicro technical support. No AC power to modules...

  • Page 15: Motherboard Layout

    Chapter 1: Introduction 1.5 Motherboard Layout Below is a layout of the H12SSW-AN6 with jumper, connector and LED locations shown. See the table on the following pages for descriptions. For detailed descriptions, pinout information, and jumper settings, refer to Chapter 4. COM1 LED1 LED7...

  • Page 16: Quick Reference Table

    A+ Server AS -2014CS-TR User's Manual Quick Reference Table Jumper Description Default Setting UID SW Unit ID switch (push-button toggle switch ON/OFF) JBT1 Clear CMOS Open (Normal) JWD1 Watch Dog control Pins 1-2 (Reset) Description Status LED1 UID LED Blue: UID Activated LED7 Power LED On: Power On...
  • Page 17 Chapter 1: Introduction System Block Diagram – AS -2014CS-TR AMD EPYC AIOM Slot 1 WIO RH Riser Slot WIO LH Riser Slot AIOM Slot 2 (PCI-E 4.0 x 8 ) (16 PCI-E Lanes) (16 PCI-E Lanes) (PCI-E 4.0 x 16 ) JSLIMA3 JSLIM1 (NVMe x1)

  • Page 18: Chapter 2 Server Installation

    A+ Server AS -2014CS-TR User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components.

  • Page 19: Rack Precautions

    Chapter 2: Server Installation Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are extended to the floor so that the full weight of the rack rests on them. • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together.

  • Page 20: Mechanical Loading

    A+ Server AS -2014CS-TR User's Manual Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 21: Installing The Rails

    Chapter 2: Server Installation 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. This rail set fits a rack between 26.8" and 36.4" deep. The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided.

  • Page 22: Releasing The Inner Rail

    A+ Server AS -2014CS-TR User's Manual Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. Releasing Inner Rail from the Outer Rails 1.

  • Page 23: Installing The Inner Rails On The Chassis

    Chapter 2: Server Installation Installing the Inner Rails on the Chassis Installing the Inner Rails 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 24: Installing The Outer Rails Onto The Rack

    A+ Server AS -2014CS-TR User's Manual Installing the Outer Rails onto the Rack 1. Press upward on the locking tab at the rear end of the middle rail. 2. Push the middle rail back into the outer rail. 3. Hang the hooks on the front of the outer rail onto the square holes on the front of the rack.

  • Page 25: Installing The Server Into The Rack

    Chapter 2: Server Installation 2.4 Installing the Server into the Rack Once rails are attached to the chassis and the rack, you can install the server. 1. Pull the middle rail out of the front of the outer rail and make sure that the ball bearing shuttle is locked at the front of the middle rail.

  • Page 26: Removing The Chassis From The Rack

    A+ Server AS -2014CS-TR User's Manual Removing the Chassis from the Rack Caution! It is dangerous for a single person to off-load the heavy chassis from the rack without assistance. Be sure to have sufficient assistance supporting the chassis when removing it from the rack.

  • Page 27: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 28: Accessing The System

    A+ Server AS -2014CS-TR User's Manual 3.2 Accessing the System The system features a removable top cover, which allows access to the inside of the system. Removing the Top Cover 1. Press the two release buttons and slide the cover toward the rear. 2.

  • Page 29: Motherboard Components

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. Installing the Processor and Heatsink 1. Unscrew the screws holding down Force Frame in the sequence of 3-2-1. The screws are numbered on the force frame next to each screw hole.
  • Page 30 A+ Server AS -2014CS-TR User's Manual 2. The spring-loaded force frame will raise up after the last screw securing it (#1) is removed. Gently allow it to lift up to its stopping position. 3. Lift the rail frame up by gripping the lift tabs near the front end of the rail frame. While keeping a secure grip of the rail frame, lift it to a position so you can do the next step of removing the external cap.
  • Page 31 Chapter 3: Maintenance and Component Installation 4. Remove the external cap from the Rail Frame by pulling it upwards through the rail guides on the rail frame. External Cap PnP Cover Cap 5. The CPU package is shipped from the factory with the blue carrier frame pre-assembled. Grip the handle of the carrier frame/CPU package assembly from its shipping tray, and while gripping the handle, align the flanges of the carrier frame onto the rails of the rail frame so its pins will be at the bottom when the rail frame is lowered later.
  • Page 32 A+ Server AS -2014CS-TR User's Manual Note: You can only install the CPU inside the socket in one direction with the handle at the top. Make sure that it is properly inserted into the CPU socket before closing the rail frame plate.
  • Page 33 Chapter 3: Maintenance and Component Installation 9. Gently lower the force frame down onto the rail frame and hold it in place until it is seated in the Socket housing. Note that the force frame is spring loaded and has to be held in place before it is secured.
  • Page 34 A+ Server AS -2014CS-TR User's Manual 11. After the force frame is secured and the CPU package is in place, now you must install the heatsink to the frame. Lower the heatsink down till it rests securely over the four screw holes on CPU package on the socket frame.
  • Page 35 Chapter 3: Maintenance and Component Installation Un-installing the Processor and Heatsink 1. Remove the heatsink attached to the top of the CPU package by reversing the installation procedure. 2. Clean the Thermal grease left by the heatsink on the CPU package lid to limit the risk of it contaminating the CPU package land pads or contacts in the socket housing.

  • Page 36: Memory Support

    A+ Server AS -2014CS-TR User's Manual Memory Support Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The H12SSW-AN6 supports Up to 4 TB of ECC DDR4 3200 MHz speed, RDIMM/LRDIMM/3DS memory in sixteen (16) slots.

  • Page 37: Dimm Module Population

    Chapter 3: Maintenance and Component Installation JCOM1 UID-SW JRU1 JWD1 JUID1 JVRM1 JUART1 COM1 USB0/1 (3.0) JDBG1 JTPM2 DIMM Module Population IPMI_LAN JIPMB1 There is no specific order or sequence required when installing memory modules. However do keep the following in mind: LEDM1 BMC_HB •...
  • Page 38 A+ Server AS -2014CS-TR User's Manual DIMM Population Guide Channel DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM DIMM 1 DIMM (not recommended) ü 2 DIMMs (not recommended) ü ü 4 DIMMS (not recommended) ü...

  • Page 39: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation JCOM1 UID-SW JRU1 JWD1 JUID1 JVRM1 JUART1 COM1 USB0/1 (3.0) JDBG1 JTPM2 1. Follow the instructions given in the IPMI_LAN JIPMB1 memory population guidelines listed in LEDM1 BMC_HB JRWIO1 the previous sections to install memory modules on your motherboard.

  • Page 40: Pci Expansion Cards

    A+ Server AS -2014CS-TR User's Manual PCI Expansion Cards The system can accommodate six to eight PCIe 4.0 expansion cards (depending upon configuration) and two PCIe 4.0 AIOM networking cards. Limitations for Slots 1, 2, 4, and 5 Due to PCIe 4.0 requirements, riser card slots 1 and 2 are connected by cable to the NVMe 0/1 and NVMe 2/3 header and slots 4 and 5 are connected by cable to the NVMe 4/5/6/7 headers on the motherboard.
  • Page 41 Chapter 3: Maintenance and Component Installation Default Cable Routing MB/AOC Connector BP/Riser Connector Drive Qty/PCIe MC Cable P/N NVME0/1 PCIe x8 CBL-SAST-1297LP-85 PCIE1A (RSC-D2-666G4) NVME2/3 PCIe x8 CBL-SAST-1297LP-85 PCIE1B (RSC-D2-666G4) NVME4/5 PCIe x8 CBL-SAST-1296LP-85 PCIE2A/2B (RSC-D2R-666G4) NVME 6/7 PCIe x8 CBL-SAST-1296LP-85 PCIE2C/2D (RSC-D2R-666G4)

  • Page 42: Installing Expansion Cards

    A+ Server AS -2014CS-TR User's Manual Installing Expansion Cards 1. Power down the system and remove the cover. 2. Lift the riser card bracket(s) out of the chassis using the pull-tabs. 3. In the rear of the chassis, remove the blank PCI shields that covers the chassis slot. Left Riser Card Bracket Right Riser...

  • Page 43: Aiom Network Cards

    Chapter 3: Maintenance and Component Installation AIOM Network Cards The system provides network connection by means of two advanced I/O modules (AIOMs). Figure 3-6. AIOM Slots Installing AIOM Cards 1. Remove the blank cover plate from A1 or A2 by unscrewing the thumbscrew. 2.

  • Page 44: Motherboard Battery

    A+ Server AS -2014CS-TR User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 45: Chassis Components

    NVMe or SAS/SATA drives. Drive carrier status indicators are described in Section 1.2 Note: Enterprise level hard disk drives are recommended for use in Supermicro servers. For compatible storage drives, see https://www.supermicro.com/en/Aplus/system/2U/2014/...
  • Page 46 A+ Server AS -2014CS-TR User's Manual Removing a Hot-Swap Drive Carrier from the System 1. Press the release button on the drive carrier, which will extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis. Handle Release Button Figure 3-10.
  • Page 47 Chapter 3: Maintenance and Component Installation Installing a 3.5" Drive 1. Position the drive above the carrier with the PCB side facing down and the connector end toward the rear of the carrier. 2. Tilt the drive to insert it onto the two posts on the left inside of the carrier. Post Insert this side first Post...
  • Page 48 A+ Server AS -2014CS-TR User's Manual Insert this side second Figure 3-12. Installing a 3.5" Drive into a Carrier Installing a 2.5" Drive 1. Install the drive directly into the tray with four screws underneath. 2. Insert the drive carrier into its bay, keeping the release button on the right. When the carrier reaches the rear of the bay, the release handle will retract.

  • Page 49: Hot-Swap For Nvme Drives

    Chapter 3: Maintenance and Component Installation Hot-Swap for NVMe Drives Supermicro servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using IPMI. Ejecting a Drive 1. IPMI > Storage > Physical View 2.

  • Page 50: System Cooling

    A+ Server AS -2014CS-TR User's Manual System Cooling Three 8-cm fans provide the cooling for the system. Make sure the chassis top cover makes a good seal so the cooling air circulates properly through the chassis Changing a System Fan 1.

  • Page 51: Checking The Server Air Flow

    Some backplanes allow the overheat temperature to be set at 45, 50, or 55 degrees by changing a jumper setting. For more information, consult the backplane user manual at www. supermicro.com. (Click Support, then the Manuals link.) Responses If the server overheats: 1.

  • Page 52: Power Supply

    Power Supply The chassis features redundant power supplies. The power modules can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors. These power supplies are auto-switching capable. This feature enables them to automatically sense the input voltage and operate at a 100-120v or 180-240v.
  • Page 53 Chapter 3: Maintenance and Component Installation Release Tab Handle Figure 3-16. Installing/Removing a Power Supply Module...

  • Page 54: Power Connections

    A+ Server AS -2014CS-TR User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 55: Headers And Connectors

    Chapter 4: Motherboard Connections 12V 8-pin Auxilliary Power Connector (JPWR2) JPWR2 is an 8-pin ATX power input to provide auxiliary power to the processor. Refer to the table below for pin definitions. 12V 8-pin Power Connector Pin Definitions Pins Definition 1 through 4 Ground 5 through 8...
  • Page 56 It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Please go to the following link for more information on TPM: http://www.supermicro.com/ manuals/other/TPM.pdf. Trusted Platform Module Header...
  • Page 57 Chapter 4: Motherboard Connections USB Ports (USB 0/1, USB7/8) There are a total of four USB ports (USB 0/1, USB 7/8) supported on the motherboard. Two are located on the front panel, and two are located on the back panel. Back Panel USB 3.0 Pin Definitions Pin#...

  • Page 58: Control Panel

    A+ Server AS -2014CS-TR User's Manual Control Panel FP1 contains header pins for various control panel connections. See the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All FP1 wires have been bundled into a single cable to simplify this connection. Make sure the red wire plugs into pin 1 as marked on the motherboard.
  • Page 59 Chapter 4: Motherboard Connections Reset Button The Reset Button connection is located on pins 3 and 4 of FP1. Attach the hardware reset switch from the computer case to this header to reset the system. Refer to the table below for pin definitions.
  • Page 60 A+ Server AS -2014CS-TR User's Manual HDD LED The HDD LED connection is located on pins 13 and 14 of FP1. Attach a hard drive LED cable here to display disk activity detected on the motherboard's built-in disk controllers. See the table below for pin definitions.

  • Page 61: Ports

    Chapter 4: Motherboard Connections 4.3 Ports Rear I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the rear of the motherboard. Figure 4-2. Rear I/O Ports Rear I/O Ports Description Description VGA Port USB 1 (3.0) IPMI LAN Port COM Port...
  • Page 62 See 2.6 for the front panel UID LED header location on FP1. Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com UID Switch Pin Definitions...

  • Page 63: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 64 A+ Server AS -2014CS-TR User's Manual Watch Dog JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.

  • Page 65: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN Port LEDs The motherboard's Ethernet ports has one LED indicators. The Activity LED is green and indicates connection and activity. The Link LED may be green, orange/amber, or off to indicate the speed of the connection. Refer to the tables below for more information. Link LED, Connection Link, Speed Activity LED Indicator...
  • Page 66 A+ Server AS -2014CS-TR User's Manual Onboard Power OK LED (LED7) LED6 is an onboard power OK LED. When this LED7 is lit, it means the system is turned on, and all the system power rails are ready. When the system is turned off, or any one of the system power rails fail, this LED will turn off.

  • Page 67: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 68 A+ Server AS -2014CS-TR User's Manual 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner.

  • Page 69: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD.

  • Page 70: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 71: Bmc

    There are several BIOS settings that are related to BMC. For general documentation and information on BMC, visit our website at: www.supermicro.com/en/solutions/management-software/bmc-resources BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 72: Chapter 6 Bios

    A+ Server AS -2014CS-TR User's Manual Chapter 6 BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the H12SSW-AN6 motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 73: Main Setup

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2015 after RTC reset. Supermicro H12SSW-AN6 BIOS Version This item displays the version of the BIOS ROM used in the system.
  • Page 74 A+ Server AS -2014CS-TR User's Manual CPLD Version This item displays the CPLD version of the BIOS ROM used in the system. Memory Information Total Memory This item displays the total size of memory available in the system.

  • Page 75: Advanced

    Chapter 6: BIOS 6.3 Advanced Use the arrow keys to select Boot Setup and press <Enter> to access the submenu items. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.
  • Page 76 A+ Server AS -2014CS-TR User's Manual Bootup NumLock State Use this feature to set the Power on state for the <Numlock> key. The options are On and Off. Wait For "F1" If Error Use this feature to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled.
  • Page 77 Chapter 6: BIOS Trusted Computing Configuration Security Device Support Enables or disables BIOS support for secuirty device. OS will not show Security Device. TCG EFI protocol and INT1A interface will not be available. The options are Disabled and Enabled.
  • Page 78 A+ Server AS -2014CS-TR User's Manual PSP Firmware Versions This section displays the Platform Security Processor (PSP) firmware versions. PSP Directory Level 1 (Fixed) • PSP Recovery BL Ver • SUM FW Version • ABL Version PSP Directory Level 2 (Updateable) •...
  • Page 79 Chapter 6: BIOS Super IO Configuration The following Super IO information will display: • Super IO Chip AST2600 Serial Port 1 Configuration Serial Port Select Enabled to enable the selected onboard serial port. The options are Disabled and Enabled. Device Settings This item displays the status of a serial part specified by the user.
  • Page 80 A+ Server AS -2014CS-TR User's Manual Serial Port Console Redirection COM1 Console Redirection Select Enabled to enable console redirection support for a serial port specified by the user. The options are Enabled and Disabled. *If the item above set to Enabled, the following items will become available for user's configuration: Console Redirection Settings Terminal Type...
  • Page 81 Chapter 6: BIOS Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 82 A+ Server AS -2014CS-TR User's Manual Bits per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 83 Chapter 6: BIOS Putty KeyPad This feature selects the settings for Function Keys and KeyPad used for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SC0, ESCN, and VT400. Legacy Console Redirection Legacy Console Redirection Settings Legacy Serial Redirection Port For this setting, select a COM port to display redirection of Legacy OS and Legacy OPROM...
  • Page 84 A+ Server AS -2014CS-TR User's Manual UTF8 encoding to map Unicode characters into one or more bytes. The options are VT100, VT100+, VT-UTF8, and ANSI. Bits per Second This item sets the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer.
  • Page 85 Chapter 6: BIOS Core Control Sets the number of cores to be used. Once this option has been used to remove any CCDs, a POWER CYCLE is required in order for future selections to take effect. Options inlcude Auto, ONE (1+0), TWO (2+0), THREE (3+0), FOUR (4+0), FIVE (5+0), SIX (6+0), and SEVEN (7+0). L1 Stream HW Prefetcher / L2 Stream HW Prefetcher This setting is used to enable or disable the L1/L2 Stream Hardware Prefetcher.
  • Page 86 A+ Server AS -2014CS-TR User's Manual • L2 Data Cache (Size/Method) • L3 Cache per Scoket (Size/Method) NB Configuration Determinism Control Use this setting to configure the Determinism Slider. Options include Manual and Auto. cTDP Control Use this setting to configure the cTDP Control. Options include Auto and Manual. IOMMU Use this setting to enable or disable IOMMU.
  • Page 87 Chapter 6: BIOS Chipset Interleaving This setting controls interleave memory blocks across the DRAM chip for node 0. Options include Disabled and Auto. BankGroupSwap This setting controls the Bank Group Swap. Options include Enabled, Disabled and Auto DRAM Scrub Time This setting provides a value that is the number of hours to scrub memory.
  • Page 88 A+ Server AS -2014CS-TR User's Manual PCIe ARI Enumeration ARI Forwarding Enable for each downstream port. The options are Disabled, Enabled and Auto. PCIe Ten Bit Tag Support Use this setting to enable PCIe ten bit tags for supported devices. The options are Disabled, Enabled and Auto.
  • Page 89 Chapter 6: BIOS CPU RWIO PCI-E 4.0 X16 OPROM Use this setting to enable or disable CPU LWIO PCI-E 4.0 X16 OPROM option. The options are Disabled and EFI. M.2-C1 OPROM Use this setting to enable or disable M.2-C1 OPROM option. The options are Disabled and EFI.
  • Page 90 A+ Server AS -2014CS-TR User's Manual Network Configuration Network Stack This setting allows you to Enable or Disable the UEFI Network Stack. IPv4 PXE Support This setting allows you to Enable or Disable IPv4 PXE boot support. If disabled, IPv4 PXE boot support will not be available.
  • Page 91 Chapter 6: BIOS SATA Information Use this setting to view SATA devices information. KMIP Server Configuration KMIP Server IP address Enter IP4 address in dotted-decimal notation KMIP TCP Port number Enter KMIP TCP Port number 100 ... 9999. Default is 5696. TimeZone Enter current time zone.
  • Page 92 A+ Server AS -2014CS-TR User's Manual HTTB Boot Configuration HTTP Boot Configuration HTTP Boot Policy Sets the HTTP boot policy to Appply to all LANs, Apply to each LAN, and Boot Priority #1 instantly. Priority of HTTP Boot Instance of Priority 1: Default to 1.
  • Page 93 Chapter 6: BIOS Delete Attempts Change Attempt Order TLS Authenticate Configuration This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Press <Enter> to enroll cert. Enroll Certification Using File Use this feature to enroll certification from a file. Certification GUID Use this feature to input the certification GUID.

  • Page 94: Ipmi

    A+ Server AS -2014CS-TR User's Manual 6.4 IPMI This tab allows you to configure the following IPMI settings for the system. Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system.
  • Page 95 Chapter 6: BIOS Erasing Settings Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset.
  • Page 96 A+ Server AS -2014CS-TR User's Manual Station IP Address This item displays the Station IP address for this computer. This should be in decimal and in dotted quad form. Subnet Mask This item displays the sub-network that this computer belongs to. The value of each three- digit number separated by dots should not exceed 255.

  • Page 97: Event Logs

    Chapter 6: BIOS 6.5 Event Logs This tab allows the user to configure the following event logs settings for the system. Change SMBIOS Event Log Settings This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 98 A+ Server AS -2014CS-TR User's Manual When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full.

  • Page 99: Security

    Chapter 6: BIOS 6.6 Security This tab allows you to configure the following security settings for the system. Administrator Password Press Enter to create a new, or change an existing Administrator password. Note that if the Administrator Password is erased, the User Password will be cleared as well. User Password Press Enter to create a new, or change an existing User password.
  • Page 100 A+ Server AS -2014CS-TR User's Manual Secure Boot This option allows you specify when the Platform Key (PK) is enrolled. When enabled, the System Mode is user deployed, and the CSM function is disabled. Options include Enabled and Disabled. Secure Boot Mode Use this item to select the secure boot mode.
  • Page 101 Chapter 6: BIOS This feature allows you to decide if all secure boot variables should be saved. Platform Key (PK) This feature allows you to configure the settings of the platform keys. Set New Key Select Yes to load the new platform keys (PK) from the manufacturer's defaults. Select No to load the platform keys from a file.

  • Page 102: Boot

    A+ Server AS -2014CS-TR User's Manual 6.7 Boot Use this tab to configure Boot Settings: Boot Mode Select Use this item to select the type of device that the system is going to boot from. The options are Legacy, UEFI, and Dual. The default setting is DUAL. Legacy to EFI Support This option Enables or Disables the system to boot to an EFI OS after the boot failed from the legacy boot order.
  • Page 103 Chapter 6: BIOS Use this feature to remove a pre-defined boot device from which the system will boot during startup. The settings are [any pre-defined boot device]. UEFI Application Boot Priorities This feature allows the user to specify which UEFI devices are boot devices. •...

  • Page 104: Save & Exit

    A+ Server AS -2014CS-TR User's Manual 6.8 Save & Exit Select the Save & Exit tab to enter the Save & Exit BIOS Setup screen. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration, and reboot the computer.
  • Page 105 Chapter 6: BIOS Default Options Restore Optimized Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>.

  • Page 106: Appendix A Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 107 Appendix A: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 108 A+ Server AS -2014CS-TR User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 109 Appendix A: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 110 A+ Server AS -2014CS-TR User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 111 Appendix A: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 112 A+ Server AS -2014CS-TR User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 113 Appendix A: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 114 A+ Server AS -2014CS-TR User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 115 Appendix A: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 116 A+ Server AS -2014CS-TR User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가...
  • Page 117 Appendix A: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 118 A+ Server AS -2014CS-TR User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 119 Appendix A: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 120 A+ Server AS -2014CS-TR User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 121 Appendix A: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 122 A+ Server AS -2014CS-TR User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 123 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 124 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 125 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 126: Appendix B System Specifications

    A+ Server AS -2014CS-TR User's Manual Appendix B System Specifications Processor Support Single AMD EPYC™ 7002/7003 Series Processor in an SP3 type socket Notes: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset System on Chip BIOS 256Mb SPI AMI BIOS...
  • Page 127 Appendix B: System Specifications Regulatory Compliance FCC, ICES, CE, UKCA, VCCI, RCM, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 Subpart B ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN 55032 BS/EN 55035 CISPR 32 CISPR 24/CISPR 35 BS/EN 61000-3-2...
  • Page 128 Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.

  • Page 129: Appendix C Uefi Bios Recovery And Ipmi Crash Dump

    USB flash drive with FAT16 or FAT32 format and rename the file to SUPER.ROM. Note: If you cannot locate the "SUPER.ROM" file in your driver disk, visit our website at www.supermicro.com to download the correct BIOS image into a USB flash device and rename it "SUPER.ROM".
  • Page 130 SUPERMICO BIOS Update: https://www.youtube.com/watch?v=S8z6iOEHGwY * If the BIOS flash recovery fails, contact our RMA Department to have the BIOS chip reprogrammed. This will require shipping the board to Supermicro for repair. Submit your RMA request at https://www.supermicro.com/support/rma Please make sure to follow all instructions when returning the motherboard.
  • Page 131 In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using IPMI. The IPMI manual is available at https://www.supermicro.com/solutions/IPMI.cfm. Check IPMI Error Log 1.

Table of Contents
