Installation Manual
SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM RS1600
Edition
01/2021
https://www.siemens.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIMATIC NET RUGGEDCOM RS1600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Siemens SIMATIC NET RUGGEDCOM RS1600

  • Page 1 All manuals and user guides at all-guides.com Installation Manual SIMATIC NET Rugged Ethernet Switches RUGGEDCOM RS1600 Edition 01/2021 https://www.siemens.com...
  • Page 2 All manuals and user guides at all-guides.com Preface Introduction Installing Device SIMATIC NET Device Management Rugged Ethernet Switches RUGGEDCOM RS1600 Communication Ports Technical Specifications Installation Manual Certification 01/2021 C79000-G8976-1013-03...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 4: Table Of Contents

    Accessing Documentation ....................... v Registered Trademarks ......................v Warranty ..........................v Training ..........................vi Customer Support ........................vi Contacting Siemens ....................... vii Introduction ........................... 1 Feature Highlights ....................1 Description ......................2 Decommissioning and Disposal ................4 Cabling Recommendations ..................4 1.4.1...
  • Page 5 All manuals and user guides at all-guides.com Table of Contents Operating Environment ..................22 Mechanical Specifications ..................22 Dimension Drawings ................... 23 Certification ......................... 27 Approvals ......................27 6.1.1 CSA ........................27 6.1.2 European Union (EU) ..................27 6.1.3 FCC ........................28 6.1.4 FDA/CDRH ......................
  • Page 6: Preface

    Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
  • Page 7: Training

    Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request...
  • Page 8: Contacting Siemens

    All manuals and user guides at all-guides.com Preface Contacting Siemens • Ask questions or share knowledge with fellow Siemens customers and the support community Contacting Siemens Address Siemens AG Industry Sector 300 Applewood Crescent Concord, Ontario Canada, L4K 5C7 Telephone...
  • Page 9 All manuals and user guides at all-guides.com Preface Contacting Siemens viii RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
  • Page 10: Introduction

    All manuals and user guides at all-guides.com Introduction The RUGGEDCOM RS1600 provides substation hardened, fully managed, Ethernet switches specifically designed to operate reliably in electrically and environmentally harsh environments. The RUGGEDCOM RS1600’s Zero-Packet-Loss™ technology provides a high level of immunity to electromagnetic interference (EMI) and heavy electrical surges typical of environments found in electric utility substations, industrial plant floors or in curb side traffic control cabinets.
  • Page 11: Description

    All manuals and user guides at all-guides.com Introduction 1.2 Description Rated for Reliability in Harsh Environments • Immunity to EMI and heavy electrical surges • Zero-Packet-Loss™ Technology • Meets IEEE 1613 Class 2 (electric utility substations) • Exceeds IEC 61850-3 (electric utility substations) •...
  • Page 12 All manuals and user guides at all-guides.com Introduction 1.2 Description Front Rear Port Status LED 10Base-FL Fiber Optic Ethernet Ports RESET Button 100Base-FX Fiber Optic Ethernet Ports 10/100Base-TX Copper Ethernet Ports Power LEDs Power Terminal Block Chassis Ground Connection Failsafe Alarm Relay RS232 Serial Console Port (DB9) Figure 1.1 Front and Rear Panels...
  • Page 13: Decommissioning And Disposal

    Siemens also does not recommend using copper Ethernet ports to interface with devices in the field across distances that could produce high levels of ground potential rise (i.e. greater than 2500 V), during line-to-ground fault conditions.
  • Page 14: Supported Fiber Optic Cables

    All manuals and user guides at all-guides.com Introduction 1.4.1 Supported Fiber Optic Cables 1.4.1 Supported Fiber Optic Cables The following fiber optic cable types are supported under the stated conditions. Cable Type Wavelength (nm) Modal Bandwidth Distance (m) (MHz·km) 100Base-FX 1000Base-SX 10GBase-SR OM1 (62.5/125) —...
  • Page 15 All manuals and user guides at all-guides.com Introduction 1.4.1 Supported Fiber Optic Cables RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
  • Page 16: Installing Device

    This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void. Changes or modifications not expressly approved by Siemens AG could invalidate specifications, test results, and agency approvals, and void the user's authority to operate the equipment.
  • Page 17: Mounting The Device To A Rack

    All manuals and user guides at all-guides.com Installing Device 2.1.1 Mounting the Device to a Rack Note For detailed dimensions of the device with either rack, DIN rail or panel hardware installed, refer to "Dimension Drawings (Page 23)". 2.1.1 Mounting the Device to a Rack For rack mount installations, the RUGGEDCOM RS1600 can be equipped with rack mount adapters pre-installed.
  • Page 18: 2.1.2 Mounting The Device On A Din Rail

    All manuals and user guides at all-guides.com Installing Device 2.1.2 Mounting the Device on a DIN Rail 2.1.2 Mounting the Device on a DIN Rail For DIN rail installations, the RUGGEDCOM RS1600 can be equipped with panel/DIN rail adapters pre-installed on each side of the chassis. The adapters allow the device to be slid onto a standard 35 mm (1.4 in) DIN rail.
  • Page 19: Connecting Power

    All manuals and user guides at all-guides.com Installing Device 2.2 Connecting Power To mount the device to a panel, do the following: Place the device against the panel and align the adapters with the mounting holes. Screw Panel/DIN Rail Adapter Figure 2.3 Panel Mounting Install the supplied screws to secure the adapters to the panel.
  • Page 20: Connecting Ac Power

    All manuals and user guides at all-guides.com Installing Device 2.2.1 Connecting AC Power • For 100-240 VAC rated equipment, an appropriately rated AC circuit breaker must be installed. • For 88-300 VDC rated equipment, an appropriately rated DC circuit breaker must be installed.
  • Page 21: Connecting Dc Power

    All manuals and user guides at all-guides.com Installing Device 2.2.2 Connecting DC Power Connect the positive wire from the power source to the positive/hot (+/H) terminal on the terminal block. For more information, refer to "Wiring Examples (Page 13)". Positive/Hot (+/H) Terminal Negative/Neutral (-/N) Terminal Surge Ground Terminal Braided Ground Cable...
  • Page 22: 2.2.3 Wiring Examples

    All manuals and user guides at all-guides.com Installing Device 2.2.3 Wiring Examples Connect the positive wire from the power source to the positive/hot (+/H) terminal on the terminal block. For more information, refer to "Wiring Examples (Page 13)". Positive/Hot (+/H) Terminal Negative/Neutral (-/N) Terminal Surge Ground Terminal Chassis Ground Terminal...
  • Page 23 All manuals and user guides at all-guides.com Installing Device 2.2.3 Wiring Examples THIS DEVICE COMPLIES WITH PART 15 OF FAILSAFE THE FCC RULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS RS232 PORT DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
  • Page 24: Connecting The Failsafe Alarm Relay

    All manuals and user guides at all-guides.com Installing Device 2.3 Connecting the Failsafe Alarm Relay Figure 2.10 Dual AC/DC Power Supply Connecting the Failsafe Alarm Relay The failsafe relay can be configured to latch based on alarm conditions. The NO (Normally Open) contact is closed when the unit is powered and there are no active alarms.
  • Page 25 All manuals and user guides at all-guides.com Installing Device 2.3 Connecting the Failsafe Alarm Relay RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
  • Page 26: Device Management

    All manuals and user guides at all-guides.com Device Management This section describes how to connect to and manage the device. Connecting to the Device The following describes the various methods for accessing the RUGGEDCOM RS1600 console and Web interfaces on the device. For more detailed instructions, refer to the RUGGEDCOM RS1600 User Guide for the RUGGEDCOM RS1600.
  • Page 27: Resetting The Device

    All manuals and user guides at all-guides.com Device Management 3.2 Resetting the Device address. For more information about available ports, refer to "Communication Ports (Page 19)". Resetting the Device The RUGGEDCOM RS1600 can be reset (rebooted) using the RESET button. The RESET button is recessed and can only be reached using a pin or small screwdriver.
  • Page 28: Communication Ports

    All manuals and user guides at all-guides.com Communication Ports The RUGGEDCOM RS1600 can be equipped with various types of communication ports to enhance its abilities and performance. To determine which ports are equipped on the device, refer to the factory data file available through RUGGEDCOM RS1600 .
  • Page 29: Fiber Optic Ethernet Ports

    All manuals and user guides at all-guides.com Communication Ports 4.2 Fiber Optic Ethernet Ports State Description The port is operating at 10 Mbps Link Yellow (Solid) Link established Yellow (Blinking) Link activity No link detected The following is the pin-out for the RJ45 male connector:  ...
  • Page 30: Technical Specifications

    All manuals and user guides at all-guides.com Technical Specifications The following sections provide important technical specifications related to the device and available modules: Power Supply Specifications Input Range Maximum Power Internal Fuse Isolation Power Supply Type Rating Minimum Maximum Consumption 12–24 VDC 10 VDC 36 VDC...
  • Page 31: Fiber Optic Ethernet Port Specifications

    All manuals and user guides at all-guides.com Technical Specifications 5.4 Fiber Optic Ethernet Port Specifications Shielded or unshielded. Auto-crossover and auto-polarity. Typical distance. Dependent on the number of connectors and splices. RMS 1 minute. Fiber Optic Ethernet Port Specifications The following details the specifications for fiber optic Ethernet ports that can be ordered with the RUGGEDCOM RS1600.
  • Page 32: Dimension Drawings

    All manuals and user guides at all-guides.com Technical Specifications 5.7 Dimension Drawings Dimension Drawings Note All dimensions are in millimeters, unless otherwise stated. 438.2 Figure 5.1 Overall Dimensions RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
  • Page 33 All manuals and user guides at all-guides.com Technical Specifications 5.7 Dimension Drawings 464.6 479.4 Figure 5.2 Rack Mount Dimensions RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
  • Page 34 All manuals and user guides at all-guides.com Technical Specifications 5.7 Dimension Drawings 486.4 476.3 Figure 5.3 Panel and DIN Rail Mount Dimensions RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
  • Page 35 All manuals and user guides at all-guides.com Technical Specifications 5.7 Dimension Drawings RUGGEDCOM RS1600 Installation Manual, 01/2021, C79000-G8976-1013-03...
  • Page 36: Certification

    Information Technology Equipment - Safety - Part 1: General Requirements The device is marked with a CSA symbol that indicates compliance with both Canadian and U.S. requirements. A copy of the CSA Certificate of Compliance is available via Siemens Industry Online Support at https://support.industry.siemens.com/cs/ww/en/view/109476557. 6.1.2...
  • Page 37: Fcc

    Products with Respect to the Restriction of Hazardous Substances The device is marked with a CE marking and can be used throughout the European community. A copy of the CE Declaration of Conformity is available from Siemens AG. For contact information, refer to "Contacting Siemens (Page vii)".
  • Page 38: 6.1.4 Fda/Cdrh

    Title 21 Code of Federal Regulations (CFR) – Chapter I – Sub-chapter J – Radiological Health 6.1.5 ISED This device is declared by Siemens AG to meet the requirements of the following ISED (Innovation Science and Economic Development Canada) standard: • CAN ICES-3 (A)/NMB-3 (A) 6.1.6...
  • Page 39: Rohs

    Certification 6.1.8 RoHS 6.1.8 RoHS This device is declared by Siemens AG to meet the requirements of the following RoHS (Restriction of Hazardous Substances) directives for the restricted use of certain hazardous substances in electrical and electronic equipment: • China RoHS 2...
  • Page 40 All manuals and user guides at all-guides.com Certification 6.2 EMC and Environmental Type Tests Test Description Test Levels Severity Levels IEC 61000-4-11 100% for 5 Periods,   100% for 50 Periods IEC 61000-4-12 Damped Signal Ports 2.5 kV Common, 1 kV Oscillatory Differential Mode @ 1 MHz DC Power Ports...
  • Page 41 All manuals and user guides at all-guides.com Certification 6.2 EMC and Environmental Type Tests Description Test Levels AC Power Ports 2 kVAC Environmental Type Tests Test Description Test Levels Severity Levels IEC 60068-2-1 Cold Temperature Test Ad -40 °C (-40 °F), 16 Hours IEC 60068-2-2 Dry Heat Test Bd...
  • Page 42 All manuals and user guides at all-guides.com Further Information Siemens RUGGEDCOM https://www.siemens.com/ruggedcom Industry Online Support (service and support) https://support.industry.siemens.com Industry Mall https://mall.industry.siemens.com Siemens AG Digital Industry Process Automation Postfach 48 48 90026 NÜRNBERG GERMANY...
