- Page 1 HPSBOC 2512B v.1.1 HPSBOC 13,8V/2A/7Ah/OC Buffer, switch mode power supply unit with automatic operation control. Edition: 4 from 30.10.2013 Supercedes edition: 3 from 05.06.2013...
-
Page 2: Table Of Contents
HPSBOC2512B Features: DC 13,8V/2A uninterruptible power supply FPS technical output indicating PSU failure – OC and relay type fitting battery: 7Ah/12V FLB technical output indicating battery low wide range of mains supply: 176÷264V voltage – OC and relay type high efficiency 74% ... -
Page 3: Block Diagram
HPSBOC2512B 1.2 Block diagram (fig.1). Fig.1. The block diagram of the PSU. 1.3 Description of the module’s components and connectors Table 1. Elements of the PSU (tab.1, fig.2). Element no. Description LED indicating presence of AC power LED indicating presence of DC power LED indicating correct battery voltage FAC- AC absence technical output –... - Page 4 HPSBOC2512B Fig. 2. The view of the PSU. Description of PSU components and connectors (tab.2, fig.3). Part no. Description [Fig. 3] PSU module TAMPER, contact, sabotage protection (NC) Tab.2. The components of the PSU. Fig.3. The view of the PSU.
-
Page 5: Specifications
HPSBOC2512B 1.4 Specifications: - electrical parameters (tab.3) - mechanical parameters (tab.4) - operation safety (tab.5) - operating parameters (tab.6) (tab. 3) Electrical parameters Mains supply 176÷264V AC Current up to 0,45A@230VAC Supply power 35W max. Efficiency Output voltage 11V÷ 13,8V DC – buffer operation 9,5V÷13,8V DC –... -
Page 6: Installation
HPSBOC2512B Operation safety (tab.5) Protection class PN-EN 60950-1:2007 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Electrical strength of insulation: - between input and output circuits of the PSU (I/P-O/P) 3000 V/AC min. - between input circuit and PE protection circuit (I/P-FG) 1500 V/AC min. -
Page 7: Operating Status Indication
HPSBOC2512B The shock protection circuit shall be performed with a particular care, i.e. the yellow and green wire coat of the power cable shall stick to one side of the terminal - marked with ‘ ‘ symbol on the PSU enclosure. Operation of the PSU without the properly made and fully operational shock protection circuit is UNACCEPTABLE! It can cause a device failure or an electric shock. -
Page 8: Operation And Use
HPSBOC2512B FPS – technical output indicating absence of DC voltage at the PSU: - OC type output indicating the PSU failure. In normal state (during correct operation) the output is connected to ground (L level – 0V). In case of absence of DC voltage at the output (e.g. short circuit), the output is switched into high impedance state –... - Page 9 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (the manufacturer) grants a two-year warranty for the equipment, counted from the device’s production date. 2. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (the selection is at the manufacturer’s discretion) if the malfunction is due to the manufacturer, includes manufacturing or material defects, unless such...
