Toto EA TX471KEAV1 Quick Start Manual

SPECIFICATIONS

150±10
G½
G½

OPERATING CONDITIONS

1. Water supply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).

MAINTENANCE

All Finishes : Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as
ammonia, chlorine, toilet cleaner etc. which could adversely
affect the finish and are not recommended for cleaning
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and
fittings.
2. As the product model is constantly updated, the actual
product may not look the same as it shown in the diagram,
but the basic installation principles are the same.
3. The hot water supply side of the faucets is in a condition
of high temperature. Do not allow skin to contact with the
hardware surface directly. Otherwise,
scalding may occur.
S060459-1S

INSTALLATION

1
MOUNT CONNECTORS PARALLEL WITH
Hot
Water
Supply
Leg
2
0
164.5
-7
Body
*Tig the n the nut b y wrench.
"EA" SINGLE LEVER BATH & SHOWER MIXER
W/O HAND SHOWER SET
THE WALL
Cold
Water
150±10
Supply
Use Seal tape
(Not Include)
150
Cover
Packing
Nut *
TX471KEAV1

TROUBLESHOOTING

CHECK
PROBLEM
POINT
Flow rate unsatisfactory
Water leaks around the handle
Handle is loose
2. CONNECTING NUT
3. BOLT
1. AERATOR
SOLUTION
Clean
1
2 Tighten
3 Tighten
R2
