Summary of Contents for Sena TUFFTALK LITE
- Page 1 Industrial Bluetooth Communication System ® User’s Guide www.senaindustrial.com...
- Page 2 ® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sena is under license. iPhone, iPod touch are registered trademarks of Apple Inc. Zumo™ is a trademark of Garmin Ltd. or its subsidiaries. TomTom™ is the trademark or registered trademark owned...
-
Page 3: Table Of Contents
3.6 Checking the Battery Level ....................10 3.7 Volume Adjustment .......................11 11 FM RADIO ......................28 PAIRING THE TUFFTALK LITE WITH BLUETOOTH DEVICES ......11 11.1 FM Radio On and Off ......................28 11.2 Preset Stations........................28 4.1 Mobile Phone Pairing - Mobile Phone, Bluetooth Stereo Device .........12 11.3 Seek and Save ........................29... - Page 4 Tufftalk Lite 13 HEADSET CONFIGURATION SETTINGS ............31 13.1 Mobile Phone Pairing ......................32 13.2 Second Mobile Phone Pairing ....................32 13.3 Phone selective pairing ......................32 13.4 Media Selective Pairing ......................32 13.5 Delete All Bluetooth Pairing Information ................33 13.6 Universal Intercom Pairing ....................33 13.7 Factory Reset ........................33...
-
Page 5: Package Contents
1.1 Over-the-Head Earmuff Type • Headset • USB Power & Data Cable • USB Power & Data Cable • Microphone Sponge (2) • Rubber Pad (2) • Microphone Sponge (2) • Type B Hard Hat Adapter for Tufftalk Lite (2) -
Page 6: Installing The Tufftalk Lite
2.1 Installing the Headset (Hard Hat Mount Earmuff Type) 2. Organize the cables under the hard hat suspensions. Left Speaker Cover Type A Hard Hat Adapter for Tufftalk Lite Tufftalk Lite Headset... -
Page 7: Replacing The Ear Pads
Tufftalk Lite 2.2 Replacing the Ear Pads Note: 1. Use your fingers to remove the ear pads. • If the rubber pad on the inner surface of the bracket-top begins to fray, 2. Insert the included ear pads. replace it with the included pad. -
Page 8: Getting Started
Status LED Center Button (+) Button (-) Button Right Ear Cup Right Ear Cup Left Ear Cup Left Ear Cup Microphone Microphone DC Power Charging & DC Power Charging & Firmware Upgrade Port Firmware Upgrade Port Tufftalk Lite Headset Buttons... -
Page 9: Sena Softwares
3.2.1 Sena Industrial App Button for 1 second at the same time while hearing ascending beeps By simply pairing your phone with your headset, you can use the Sena and a voice prompt, “Hello”. To power off the headset, tap the Center Industrial App for quicker and easier set up and management. -
Page 10: Low Battery Warning
Note: 4 flashes = High, 70 ~ 100% • Any 3rd party USB charger can be used with Sena products if the 3 flashes = Medium, 30 ~ 70% charger is approved by either the FCC, CE, IC or other locally approved 2 flashes = Low, 0 ~ 30% agencies that Sena accepts. -
Page 11: Volume Adjustment
Bluetooth devices for the first time, you will need to pair them together. 3.7 Volume Adjustment You can pair the Tufftalk Lite with Bluetooth mobile phones, Bluetooth You can easily adjust the volume by tapping the (+) Button or the (-) stereo devices such as MP3 players and with other Sena Bluetooth Button. -
Page 12: Mobile Phone Pairing - Mobile Phone, Bluetooth Stereo Device
4. The mobile phone confirms that pairing has been completed and phone pairing”. the Tufftalk Lite is ready to use. You will hear a voice prompt, 3. Search for Bluetooth devices on your mobile phone. Select the “Your headset is paired”. -
Page 13: Advanced Selective Pairing - A2Dp Stereo Or Handsfree
Tufftalk Lite. To clear the pairing list on the Tufftalk Lite, please do a factory reset or following the pairing list clearing procedure described in section 13.7, “Factory Reset”... -
Page 14: Intercom Pairing - Other Tufftalk Lite Headsets
Center Button for 10 seconds until you hear the voice prompt, “Configuration menu”. 1. Turn on the two Tufftalk Lite headsets (A and B) that you would like to pair with each other. 2. Tap the (+) Button four times and you will hear the voice prompt, “Media selective pairing”. -
Page 15: Mobile Phone
Tufftalk Lite 4. You can make other pairing between headsets A and C, and 5 MOBILE PHONE between headsets A and D by following the same procedure as above. 5. The intercom pairing queue is ‘Last-Come, First-Served ’. If a headset has multiple paired headsets for intercom conversations, 5.1 Mobile Phone Call Making and Answering... -
Page 16: Speed Dialing
Center Button. If you do not press any button within 15 seconds, You can quickly make a phone call by using the voice speed dial the Tufftalk Lite will exit the voice speed dial menu and go back menu. to stand-by mode. -
Page 17: Stereo Music
Audio/Video Remote Control Profile (AVRCP), so if your Bluetooth Button for 1 second. audio device also supports the AVRCP, you can use the Tufftalk Lite to remotely control music playback. Not only can you adjust the volume but you can also use functions such as play, pause, next track and previous track. -
Page 18: Intercom
Please make sure your intercom devices are paired as described in you can go back to the intercom conversation. To start or terminate section 4.4, “Intercom Pairing - Other Tufftalk Lite headsets” . sharing music, press the Center Button for 1 second during an intercom conversation. -
Page 19: Three-Way Intercom
7.2.1 Starting Three-way Intercom You (A) can have a three-way conference intercom with two other Tufftalk Lite friends (B & C) by establishing two intercom connections simultaneously. While a three-way conference intercom is in progress, mobile phone connection of all three participants is temporarily... - Page 20 Second Friend example, by single tapping the Center Button, you can terminate 4. Now you (A) and two Tufftalk Lite intercom friends (B & C) are the intercom connection with just the first intercom friend (B). having a three-way conference intercom.
-
Page 21: Four-Way Intercom
Tufftalk Lite 7.3 Four-way Intercom 2. Tap or double tap the Center Button to disconnect the intercom connection with one of the two intercom friends accordingly. 7.3.1 Starting Four-way Intercom However, when you disconnect the second friend (C) by double... -
Page 22: Three-Way Conference Phone Call With Intercom Participant
Tufftalk Lite 3. You can have a three-way conference phone call by adding 8 THREE-WAY CONFERENCE PHONE CALL an intercom friend to the mobile phone conversation. During a mobile phone conversation, tap the Center Button to invite one WITH INTERCOM PARTICIPANT of the intercom friends to the mobile phone line. -
Page 23: Universal Intercom
Bluetooth headset, the previous pairing will be removed. headsets using the Universal Intercom function. Non-Sena Bluetooth 1. Turn on the Tufftalk Lite and a non-Sena Bluetooth headset that headsets can be connected to the Sena Bluetooth headset if they you want to pair with. -
Page 24: Two-Way Universal Intercom
Non-Sena Bluetooth headsets may initiate the Universal Intercom connection, by activating the voice dialer or using the redialing 1. You (A) need to be paired with a non-Sena Bluetooth headset (B) operation. You may also disconnect the existing connection by using and another Tufftalk Lite headset (C) for the three-way conference the operation to end a call (refer to the User’s Guide of the headsets... - Page 25 5. You may disconnect three-way Universal Intercom using the same way as you do in normal three-way intercom. Please refer to section 7.2.2, “Ending Three-way Intercom”. 3. The other Tufftalk Lite (C) may join the intercom by making an intercom call to you (A).
-
Page 26: Four-Way Universal Intercom
Tufftalk Lite 9.4 Four-way Universal Intercom 2. The other Tufftalk Lite (C) may join the intercom by making an intercom call to you (A). You may make a four-way Universal Intercom connection with a couple of different configurations, 1) three Tufftalk Lite headsets and one non- Sena Bluetooth headset or 2) two Tufftalk Lite headsets and two non- Sena Bluetooth headsets. - Page 27 Tufftalk Lite 9.4.2 Four-way Universal Intercom Case 2 4. Now two Tufftalk Lite headsets (A & C) and two non-Sena Bluetooth headsets (B & D) are connected with the four-way Universal Three Tufftalk Lite headsets (A, C and D) and one non-Sena Bluetooth Intercom.
-
Page 28: Group Intercom
“FM off”. When you power it off, the Intercom. The LED will flash green and you will hear a voice Tufftalk Lite will remember the last station frequency. When you power prompt, “Group intercom connected”. -
Page 29: Seek And Save
• You can save FM stations to presets before using FM radio. Connect the To use the “Seek” function, please follow the procedure below: Tufftalk Lite to your PC and open the Sena Device Manager. It allows you 1. Double tap the (+) Button or the (-) Button to search down or up to save up to 10 FM station frequency presets on the Tufftalk Lite settings the station dial. -
Page 30: Temporary Preset
11.6 Region Selection (lowest) Bluetooth stereo music You can select the proper FM frequency region from the Sena Device Manager. With the region setting, you may optimize the seek function A lower priority function is always interrupted by a higher priority to avoid unnecessary frequency ranges. -
Page 31: Headset Configuration Settings
Center Button. (-) Button Media selective pairing 4. If no button is pressed within 10 seconds, the Tufftalk Lite will exit the configuration and go back to stand-by mode. Delete all pairings 5. If you want to exit the configuration immediately, tap the (+) Button or the (-) Button until you hear a voice prompt, “Exit... -
Page 32: Mobile Phone Pairing
Tufftalk Lite 13.1 Mobile Phone Pairing 13.3 Phone selective pairing Voice Prompt “Phone pairing” Voice Prompt “Phone selective pairing” Factory Default Factory Default To go into mobile phone pairing mode, tap the (+) Button or the (-) To go into phone selective pairing mode, tap the (+) Button or the (-) Button until you hear the voice prompt, “Phone pairing”. -
Page 33: Delete All Bluetooth Pairing Information
Tap the Center Button To delete all Bluetooth pairing information of the Tufftalk Lite, tap the To restore factory default settings on the Tufftalk Lite, tap the (+) Button (+) Button or the (-) Button until you hear a voice prompt, “Delete all or the (-) Button until you hear a voice prompt, “Factory reset”, and... -
Page 34: Software Configuration Settings
Second Mobile Phone Pairing None In addition to the headset configuration menu, you can change the Phone Selective Pairing None settings of the Tufftalk Lite through the Sena Device Manager or the Sena Industrial App. Media Selective Pairing None Delete All Pairings Execute 14.1 Assigning Speed Dial... -
Page 35: Enabling/Disabling Voice Activated Phone Answering (Default: Enable)
In this case, you have to tap the Center Button to restart the intercom. This is to prevent repeated unintentional intercom connections by strong wind noise. After rebooting the Tufftalk Lite, you can start intercom by voice again. -
Page 36: Enabling/Disabling Voice Prompts (Default: Enable)
Tufftalk Lite 14.7 Enabling/Disabling Voice Prompts (Default: Enable) 14.10 Enabling/Disabling Sidetone (Default: Disable) You can disable voice prompts by software configuration settings, but Sidetone is audible feedback of your own voice. It helps you to the following voice prompts are always on. -
Page 37: Firmware Upgrade
If your intercom friend goes out of range while having an intercom conversation, you may hear static noise and eventually the intercom will be disconnected. In this case, the Tufftalk Lite automatically tries to reconnect the intercom every 8 seconds and you will hear high- toned double beeps until the intercom is reestablished. -
Page 38: Fault Reset
Tufftalk Lite 16.3 Fault Reset When the Tufftalk Lite is not working properly or is in faulty status for any reason, you may reset by pushing the pin-hole reset button located below the Center Button. Separate the left ear cup and insert a paper clip into the reset pin-hole and press the reset button for a second with light pressure. - Page 39 1.3.0 www.senaindustrial.com...
