Summary of Contents for iSinwheel X3
-
Page 2: Table Of Contents
Contents Package Contents Product Overview Instructions for Dashboard Assembly Product Safety Notice Charging Riding Basics Safety Instructions Dangerous Actions (No Attempting!) Safety Instructions Specification Limited Warranty Statement Question & Answer Contact Us... -
Page 3: Package Contents
Package Contents When unboxing your X3 or X3 Pro electric scooter, please verify that the below items are included in the package. If anything is missing or damaged, please contact isinwheel customer service for support: support@isinwheel.com. Keep the package box to ship back the scooter when necessary. -
Page 4: Product Overview
Product Overview Grips Front Brake Throttle LCD Dashboard lock Rear Brake Folding Mechanism Front Light Charging Port Taillight Kickstand Motor... -
Page 5: Instructions For Dashboard
Instructions for Dashboard Battery Speed Light On / Off Cruise Control Control Panel Insert the key into the lock hole, then turn right to power on, turn left to off. Click to switch the power mode. One-click to turn on/off the front light. Long press the front light for 5 seconds to turn on/off cruise control. -
Page 6: Assembly
Assembly 1. Push up the black button to open the 2. Connect all of the wires coming from the folding lever, and lift up the stem until you stem according to the connector pins. align it. Twist the knob clockwise to tighten the folding mechanism. -
Page 7: Product Safety Notice
Product Safety Notice Don't Ride Until You Read This: Always wear a helmet, elbow pads, and knee pads when riding your electric scooter. Make sure your electric scooter has a full charge, and all screws are closely tightened before riding. Always be aware of local road laws, and follow them. - Page 8 Abuse --- We do not cover physical damage due to negligent care and extreme riding. Safety Ride --- Whenever you ride the isinwheel electric scooter, you risk severe injury or even death from loss of control, collisions, and falls.
-
Page 9: Charging
Charging Your scooter will be fully charged when the LED indicator on the charger changes to green from red. With charging protection, it will cut off charging automatically after fully charge. Even so, we still don't recommend charging your scooter for a long time more than 24 hours at one time. Do not connect the charger if the charging port is wet. -
Page 10: Riding Basics
Riding Basics Wear a helmet, elbow pads, and knee pads in 1. Turn the power on, and check the battery case of falls and injuries either you are a level indicator. beginner learning to ride or you are a seasoned rider. 2. -
Page 11: Safety Instructions
Safety Instructions Do not ride in the rain. Please keep a medium or low speed (5mph) when you ride across speed bumps, elevator door sills, bumpy roads or other uneven surfaces. Slightly bend your knee to better adjust mentioned surfaces. Look out for doors, elevators and other Do not accelerate when you go downhill. -
Page 12: Dangerous Actions (No Attempting!)
Do not hang bags or other heavy stuff on the Keep both feet on the deck all time. handlebar. Dangerous Actions (No Attempting!) Do not ride in traffic lanes or residential areas Do not turn the handlebar violently during where vehicles and pedestrians are both high-speed riding. - Page 13 Keep your feet off the rear mudguard. Always keep your hands on the handlebar. Do not touch the disc brake. Do not try riding up or down stairs, and jumping over obstacles. ...
-
Page 14: Safety Instructions
Safety Instructions Cleaning and Storage If you see stains on the scooter's body, wipe them off with a damp cloth. If you cannot scrub off the stain, put on some toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth. Notes: •... -
Page 15: Specification
Specification X3 Pro Type Specification Motor 48V 1200W BLDC Hub Motor Unfolded Size 50*19.6*47 (in) / 127*50*120 (cm) Folded Size 50*19.6*20 (in) / 127*50*52 (cm) Battery Lithium Ion Battery, 48V 12.5Ah Lithium Ion Battery, 48V 15Ah Charging Time 6-7 Hours... -
Page 16: Limited Warranty Statement
5. All accessories originally included with your purchase must be included with your return. 6. If you return a product to isinwheel, (a) without an RMA from isinwheel(b) without all parts included in the original package, isinwheel retains the right to refuse delivery of such return. - Page 17 • If a hardware defect is found and a valid claim is received by isinwheel within the Warranty Period, isinwheel will, at its option and to the extent permitted by law, either (1) repair the product at no charge, using new or refurbished replacement parts or, (2) replace the product with a new or refurbished product. In the event of a defect, to the extent permitted by law, these are your sole and exclusive remedies.
-
Page 18: Question & Answer
Adjustment page. If you still have problem, please contact us for help. 5. Why does the screen display an error code? A: If you see any error code below, please contact isinwheel support team to remove the error code. Throttle failure Replace the throttle.
