- Page 1 ELECTRIC SCOOTER USER MANUAL The manufacturer reserves the right to make changes to the product, and update this manual at any time.
-
Page 2: Table Of Contents
Contents 1. Package Contents 2. Product Overview 3. Assembly 4. Charging 5. First Riding 6. Riding Basics 7. Safety Instructions 8. Dangerous Actions (No Attempting!) 9. Riding Notice 10. Folding and Carrying 11. Disc Brake Adjustment 12. Daily Care and Maintenance 13. -
Page 3: Package Contents
Package Contents When unboxing your I9 electric scooter, please verify that the below items are included in the package. If anything is missing or damaged, please contact iSinwheel customer service for support: vip.support@iSinwheelglobal.com Charger 4 x Screws 2 x Allen Wrench... -
Page 4: Product Overview
Product Overview Folding Clip Handlebar Display Brake Folding Latch Front Light Platform Brake Light Kickstand Disc Brake... - Page 5 Tips When the scooter starts to coast, put both feet on the deck and press the accelerator (the accelerator initiates once the coasting speed exceeds 3 mph). Or you can connect the "MiniRobot" APP, then, turn on the zero start. Control Panel Power Button Click to turn on.
-
Page 6: Assembly
Assembly 2. Install the 4PCS screws (two on each side) into 1. Unfold the stem and colse the folding latch until the holes, then tighten the each screws properly you hear a click. Then unfold the kickstand to with the included hex wrench. support the scooter. -
Page 7: Charging
Charging Your scooter will be fully charged when the LED light on the charger changes to green from red. The scooter has charging protection and charging will cut off automatically after fully charge. Even so, we still don't recommend charging your scooter for a long time more than 24 hours at one time. -
Page 8: Riding Basics
Riding Basics Wear helmets and knee pads in case of falls 1. Turn the power on, and check the electricity and injuries when you learn to ride the scooter, indicator. as shown in the figure. 2. Stand on the base with one foot and propel 3. -
Page 9: Safety Instructions
Safety Instructions Do not ride in the rain. Please keep a medium or low speed (5mph) when you ride through speed bumps, elevator door sills, bumpy roads or other uneven surfaces Slightly bend your knee to better adjust mentioned surfaces. Look out for doors, elevators and other Do not accelerate when you go downhill. -
Page 10: Dangerous Actions (No Attempting!)
Do not hang bags or other heavy stuff on the Keep both feet on the deck all time. handlebar. Dangerous Actions (No Attempting!) Do not turn the handlebar violently Do not ride in traffic lanes or residential areas during high-speed riding where vehicles and pedestrians are both allowed. -
Page 11: Riding Notice
Riding Notice The iSinwheel I9 electric scooter is a leisure device. But once they're in a public area, they'll be seen as vehicles, subject ing to any risks faced by vehicles. For your safety, please follow instructions in the manual and traffic laws and regulations set forth by government and regulatory agencies. -
Page 12: Folding And Carrying
● Closely follow the safety instructions in the manual. iSinwheel shall not be liable for any financial losses, physical injuries, accidents, legal disputes and other interest conflicts resulted from actions that violate user instructions. ● Do not lend your scooter to whoever doesn't know the operations. And when you do lend it to your friends, please take the responsibility to ensure he/she knows the operation and wears the safety gear. -
Page 13: Disc Brake Adjustment
Disc Brake Adjustment To adjust the disc brake sensitivity: You need the Allen wrench to loosen the screw on the rocker. • When the disc brake is too sensitive, rotate the disc brake rocker down a bit. Then, reinstall the screw back to the brake cable core to tighten. •... -
Page 14: Daily Care And Maintenance
Daily Care and Maintenance Cleaning and storage If you see stains on the scooter's body, wipe them off with a damp cloth. If the stains won't scrub off, put on some toothpaste, and brush them with a toothbrush, then wipe them off with a damp cloth. -
Page 15: Specifications
Specifications ltem Electric Scooter Unfolded (Length. x Width x Height) 42*17*44 inch/108*43*112 cm Dimensions Folded (Length. x Width x Height) 42*17*19 inch/108*43*50 cm weight 26.4 lbs/12 kg Net Weight Load 264 lbs/120 kg User Recommended Age Max.Speed 15.5 mph/25 km/h Max.Range 14-17.5 miles/22-28 km Max. -
Page 16: Limited Warranty Statement
REMEDIES If a hardware defect is found and a valid claim is received by iSinwheel within the Warranty Period, iSinwheel will, at its option and to the extent permitted by law, either (1) repair the product at no charge, using new or refurbished replacement parts or, (2) replace the product with a new or refurbished product. -
Page 17: Question & Answer
Question & Answer 1. What if the E-Scooter arrived missing accessory or broken part? A: Please take a photo and send to iSinwheel Support Team by sending email: vip.support@iSinwheelglobal.com. And iSinwheel Support Team will reply you soon and send correct accessory or part replacement.
