- Page 1 20227110250 3/22 Lionel Lionel 21" Passenger Cars 21" Passenger Cars Owner's Manual Owner's Manual...
- Page 2 O-36 switches or curves. Note! Baggage cars measure 18" in length, these are correct, per scale length of the prototype. The following Lionel marks are used throughout this Owner’s Manual and are protected under law. All rights reserved. Lionel ®...
-
Page 3: Table Of Contents
Table of Contents Passenger Car operations Uncoupling your 21" Passenger Cars Installing scale couplers (optional) Switching the interior lights on and off Lamp replacement Replacing the lamps Removing the car body Limited Warranty/Lionel Service... -
Page 4: Passenger Car Operations
Passenger Car operations Uncoupling your 21" Passenger Cars our 21" Passenger Cars are equipped with a Kinematic coupler system which allows the couplers to extend when the train enters a curve. This provides a closer car spacing on straight track. To manually uncouple the cars, pull down on the small tab on the right side of the coupler. You can also use a Remote Uncoupling Track (available separately, 6-65149 or 6-12746 for O-27 gauge;... -
Page 5: Switching The Interior Lights On And Off
Passenger Car operations Switching the interior lights on and off ach Passenger Car is equipped with a switch that turns the lights on and off. As illustrated in Figure 2, the switches are located between the trucks on the underside of the cars. Interior lights ON/OFF switch body screws body screws body screws... -
Page 6: Lamp Replacement
In the event you need to replace an LED please con- tact a Lionel Factory Trained Authorized Service Station or Lionel Customer Service. Note! Because the capacitor must be charged at initial power up, your LED lighting will not be at full intensity immediately upon powering your train. -
Page 7: Removing The Car Body
Lamp replacement Removing the car body f you would like to access the interior of the car to add figures or other details to the interior, the body can be removed with just three or four screws. Body screws are located in each cor- ner of the car. -
Page 8: Limited Warranty/Lionel Service
Authorized Lionel Retailer*, will at the discretion of Lionel LLC, be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a suitable replacement is not available, Lionel will offer to replace the product with a comparable model (determined by Lionel LLC), if available.
