Summary of Contents for ICT ELT-KLCS

  • Page 1 ELT-KLCS EliteSuite Touch Sense LCD Keypad User Manual...
  • Page 2 Protege® Logo are registered trademarks of Integrated Control Technology Limited. All other brand or product names are trademarks or registered trademarks of their respective holders. Copyright © Integrated Control Technology Limited 2003-2023. All rights reserved. Last Published: 04-Jul-23 11:06 AM ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 3: Table Of Contents

    Fast Arming Alarm Memory Trouble Display Trouble Conditions User Setup User Options User Card Numbers Deleting a User Card Special Features Chime Zones Disabling the Audible Output Messages Panic Alarm ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 4 Fire Alarm Your EliteSuite System Zone Description Fire Zone One Key Arming Panic Keys Timers Users ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 5: Introduction

    The elegant and user-friendly EliteSuite keypad maintains complete control of your residence and provides easy to understand information. Before using your EliteSuite system we highly recommend you read this manual carefully and have your security professional or property manager explain basic system operation to you. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 6: Operation

    Armed/Alarm Indicator When the armed/alarm indicator is ON, the system is armed. When FLASHING the system is in alarm and your user code needs to be entered to silence the alarm. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 7: Audible Tone

    The [BYPASS] key can be pressed when a zone is breached during an arming process to bypass the displayed zone (see page 13). The [CLEAR] key will log off the user currently logged in to the keypad. When pressed while not logged in the display will be refreshed. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 8 The arrow keys are used to scroll the menu, move the focus of a program window to the next screen, KEYS and move the cursor when programming or editing values. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 9: User Codes

    Enter the new four-digit code for the user and then press the [ENTER] key. Select PIN [****] When prompted, repeat the user code and press the [ENTER] key to confirm. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 10: Deleting User Codes

    To delete a user code, follow the same procedure to program the user code, but when the old user code is displayed press the [FORCE] key to clear the code. This user will no longer be able to log in to the keypad. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 11: Arming/Disarming

    Your system may also have panic, medical and fire alarms available (see page 21). To deactivate an alarm, enter your user code. This will also disarm the system. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 12: Stay Arming

    Press the [FORCE] key, then enter your user code. The exit delay will start. To fast force arm your system without a user code, press and hold the [FORCE] key for two seconds. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 13: Bypassing Zones

    You can use the feature to allow service staff (e.g. cleaners) to arm the system without giving them access to any other alarm system operations. This feature must be enabled by your property manager or installation company. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 14: Alarm Memory

    Press and hold the [MEMORY] key for 2 seconds, or press [MEMORY] and enter your user code. The alarm memory can also be accessed from the main menu. Use the [UP] and [DOWN] keys to scroll the alarm memory messages. Press the [CLEAR] key to exit. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 15: Trouble Display

    ⦁ security installation company to arrange for your system to be serviced. Fire zones and fire loop trouble detection must be enabled by your property manager or security installation company. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 16: User Setup

    Code Can Arm System Only: N Enabled: Allows the user code to be used only for arming the system. ⦁ Disabled: Allows the user code to arm and disarm the system. ⦁ ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 17 Enabled: Allows the selected user to unlock or lock the door by presenting their card at the card reader three times in quick succession. Disabled: Does not allow toggling the door by presenting a card three times. ⦁ ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 18: User Card Numbers

    Press [ENTER] twice to confirm and save the new card. If you cannot present the card to the card reader, you can enter the facility and card numbers manually. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 19: Deleting A User Card

    Deleting a User Card To delete a user card, follow the same procedure as adding or changing a card number and press the [FORCE] key to clear the facility and card numbers. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 20: Special Features

    Press the [ENTER] key to acknowledge each message. Any new messages will overwrite the oldest message that has not been acknowledged. Alternatively, you can press the [FORCE] key to delete a message. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 21: Panic Alarm

    A delayed fire zone will be automatically canceled if the smoke detector is reset within 30 seconds. Pressing any key on the keypad during the first 30 seconds will silence the alarm for 90 seconds. ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 22: Your Elitesuite System

    To silence the fire alarm, log in to the keypad with your user code. ⦁ (Cross out if not relevant) To reset the smoke detector, press and hold [CLEAR] and [ENTER] on the keypad. ⦁ ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 23: One Key Arming

    The following table should be used to keep a record of the users programmed in your system. Record the name of the user only. Do not write the user code. User Name Master Duress Only ELT-KLCS | EliteSuite Touch Sense LCD Keypad | User Manual...
  • Page 24 In accordance with the ICT policy of enhanced development, design and specifications are subject to change without notice.
